SHANGHAI SUNRISE ELECTRONICS CO., LTD.
D3SB10 THRU D3SB80
SINGLE PHASE GLASS
PASSIVATED SIP BRIDGE RECTIFIER
VOLTAGE: 100 TO 800V CURRENT: 4.0A
FEATURES
• Glass passivated junction chip
• Ideal for printed circuit board
• Reliable low cost construction utilizing
molded plastic technique
• Surge overload rating: 120 A peak
• High temperature soldering guaranteed:
250
o
C/10sec/ 0.375" (9.5mm) lead length
at 5 lbs tension
TECHNICAL
SPECIFICATION
D3-SB
MECHANICAL DATA
• Terminal: Plated leads solderable per
MIL-STD 202E, method 208C
• Case: UL-94 Class V-O recognized flame
retardant epoxy
• Polarity: Polarity symbol marked on body
• Mounting position: Any
Dimensions in inches and (millimeters)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
(Single-phase, half-wave, 60Hz, resistive or inductive load rating at 25
o
C, unless otherwise stated, for
capacitive load, derate current by 20%)
RATINGS
Maximum Repetitive Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
(T
a
=50
o
C)
Peak Forward Surge Current (8.3ms single
half sine-wave superimposed on rated load)
Maximum Instantaneous Forward Voltage
(at forward current 2.0A DC)
Maximum DC Reverse Current
(at rated DC blocking voltage)
T
a
=25
o
C
o
T
a
=125 C
SYMBOL
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
V
F
I
R
T
STG
,T
J
D3SB
10
100
70
100
D3SB
20
200
140
200
D3SB
40
400
280
400
4.0
120
1.1
10
500
D3SB
60
600
420
600
D3SB
UNITS
80
800
V
560
V
800
V
A
A
V
µA
µA
o
Storage and Operating Junction Temperature
-55 to + 150
C
http://www.sse-diode.com
