REVISIONS
REV.
E
F
F
ECO. NO
2536
2740
DESCRIPTION
UPDATE PROCESSING TEMPERATURE
DATE
03/02/2012
BY
LH
LH
F
REPLACE NYLON 46 WITH NYLON 9T, UPDATED
NOTES, CARD SLOT WIDE 1.80mm(WAS 1.77mm) & 04/30/2013
DIMENSION TABLE TOLERANCES
1.73±0.08 .068±.003
11.65 .459
PIN A1
IDENTIFIER
1.50 .059
B
A
1.00 .039 TYP.
1.80±0.15 .071±.006
7.45 .293
E
E
PIN A1
PIN B1
C
L
14.50 .571
D
8.85 .348
1.50 .059
10.00±0.15 .394±.006
C
5.10 .201
D
0.90 .035
1.50 .059 MAX.
3.75 .148
7.85 .309
0.80 .031
4.40 .173
C
A
3.75 .148 MAX.
11.25 .443 MAX.
15.60 .614
3.40 .134
2.00 .079
1.25 .049
3.25 .128
SECTION A-A
0.34 .013
1.65 .065
A
1.35 .053
2X 1.20 .047
1.00 .039 TYP.
2X
2.15±0.05 .085±.002
C
TAIL LENGTH
(SEE PART NUMBER CODING)
+0.25
+.010
Tol. .XX - 0.13 .XXX - .005
B
NOTES:
1. INSULATOR MATERIAL: NYLON 9T, UL 94V-0.
14.65 .577
2. CONTACT MATERIAL: PHOSPHOR BRONZE.
3. CONTACT PLATING: SEE PART NUMBER CODING.
4. CURRENT RATING: 1.1 AMP PER CONTACT.
5. VOLTAGAE RATING 50 VAC.
6. INSULATOR RESISTANCE: 1000 MEGOHMS MIN.
7. CONTACT RESISTANCE: 30 MILLI OHMS MAX.
8. DIELECTRIC WITHSTANDING: 500 VAC.
9. INSERTION FORCE: 117.3gf (1.15 N) MAX PER CONTACT PAIR USING A 1.70 mm (.067") STEEL CARD.
10. WITHDRAWAL FORCE: 15.31gf (0.15 N) MIN PER CONTACT PAIR USING A 1.44 mm (.057") STEEL CARD.
11. OPERATING TEMPERATURE: -10° C TO +85° C.
12. PROCESSING TEMP: 260° C FOR 10 SEC. MAX.
B
D
DRAWN
DATE
03/09/2009
NAME
JH
TITLE
A
A
Pb
RoHS
COMPLIANT
4
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN MM[INCHES]
TOLERANCES:
ANGULAR:
3
DECIMALS
.X= 0.35 [.014]
.XX= 0.25 [.010]
.XXX= 0.08 [.0031]
3
THE INFORMATION HEREIN CONTAINS
PROPIETARY INFORMATION OF
SULLINS ELECTRONICS AND IS NOT
TO BE REPRODUCED, USED OR
DISCLOSED TO OTHERS FOR ANY
PURPOSE EXCEPT AS SPECIFICALLY
AUTHORIZED IN WRITING BY AN
OFFICER OF SULLINS ELECTRONICS.
PART NUMBER
SIZE
PCI EXPRESS, 1mm CC, DIP SOLDER(GEN 1)
_ _E_ _DHHN-T9_1
DWG. NO.
SCALE: 3.5:1
8
7
6
5
2
C
CAGE CODE
54453
11045
SHEET 1 OF 2
1
REV
F
FILE NAME: Z:\ECO PENDING\2740, PCI E -- REMOVE NYLON 46, DWG 11205, 11045, 11042, 11043, 11044\11045-F\11045, N(G)_E_ _DHHN-T9_ _ PRINT: 10/31/2013
8
7
6
5
4
3
2
1
1.90±0.06 .075±.002
1.50 .059
F
-X-
0.70 .028 TYP.
0.10[.004] W X
F
1.50 .059
B PIN #1
1.00 .039 TYP.
E
8.40 .331 MIN
5.60 .220
3.20 .126 REF.
2.40 .094 PIN "G" SEE TABLE
E
-W-
10.00 .394
12.15 .478
A
F
0.50[.020] X 45 TYP
D
1.57±0.13 .062±.005
I/O PANEL DIRECTION
PRIMARY (COMPONENT) SIDE
D
A PIN #1
10.00 .394
1.65 .065
D
A
1.35 .053
2X
2.35±0.05 .093±.002
0.10[.004]
C
4.20 .165
A PIN #1
1.25 .049
3.25 .128
C
B PIN #1
1.57 .062
B
I/O PANEL DIRECTION
SECONDARY (SOLDER) SIDE
.
1.00 .039 TYP
RECOMMENDED PCB LAYOUT
(TOLERANCE: 0.05[.002])
0.70±0.08 .028±.003
0.10[.004]
B
1.40 .055
20.0°±2°
DETAIL A
SCALE 10 : 1
ADD-IN CARD EDGE-FINGER DIMENSIONS
DRAWN
DATE
03/09/2009
NAME
JH
TITLE
A
A
Pb
RoHS
COMPLIANT
8
7
6
5
4
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN MM[INCHES]
TOLERANCES:
ANGULAR:
3
DECIMALS
.X= 0.35 [.014]
.XX= 0.25 [.010]
.XXX= 0.08 [.0031]
3
THE INFORMATION HEREIN CONTAINS
PROPIETARY INFORMATION OF
SULLINS ELECTRONICS AND IS NOT
TO BE REPRODUCED, USED OR
DISCLOSED TO OTHERS FOR ANY
PURPOSE EXCEPT AS SPECIFICALLY
AUTHORIZED IN WRITING BY AN
OFFICER OF SULLINS ELECTRONICS.
PART NUMBER
SIZE
PCI EXPRESS, 1mm CC, DIP SOLDER(GEN 1)
_ _E_ _DHHN-T9_1
DWG. NO.
SCALE: 2:1
2
C
CAGE CODE
54453
11045
SHEET 2 OF 2
1
REV
F
FILE NAME: Z:\ECO PENDING\2740, PCI E -- REMOVE NYLON 46, DWG 11205, 11045, 11042, 11043, 11044\11045-F\11045, N(G)_E_ _DHHN-T9_ _ PRINT: 10/31/2013
