CY7C63823-PXC datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The embedded processor and controller> Microcontrollers and processors> CY7C63823-PXC

CY7C63823-PXC: DescriptionIC usb peripheral ctrlr 18dip; CategoryThe embedded processor and controller Microcontrollers and processors; File Size916KB，91 Pages; ManufacturerCypress Semiconductor; Environmental Compliance

Download Datasheet Parametric Compare View All

CY7C63823-PXC Overview

IC usb peripheral ctrlr 18dip

CY7C63823-PXC Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Parts packaging code	DIP
package instruction	0.300 INCH, PLASTIC, DIP-24
Contacts	24
Reach Compliance Code	unknown
Has ADC	NO
Other features	ALSO OPERATES AT 4V MINIMUM SUPPLY
Address bus width
bit size	8
CPU series	M8C
maximum clock frequency	24 MHz
DAC channel	NO
DMA channel	NO
External data bus width
JESD-30 code	R-PDIP-T24
JESD-609 code	e4
length	31.75 mm
Humidity sensitivity level	1
Number of I/O lines	20
Number of terminals	24
Maximum operating temperature	70 °C
Minimum operating temperature
PWM channel	NO
Package body material	PLASTIC/EPOXY
encapsulated code	DIP
Encapsulate equivalent code	DIP24,.3
Package shape	RECTANGULAR
Package form	IN-LINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
power supply	5 V
Certification status	Not Qualified
RAM (bytes)	256
rom(word)	8192
ROM programmability	FLASH
Maximum seat height	4.826 mm
speed	24 MHz
Maximum slew rate	40 mA
Maximum supply voltage	5.25 V
Minimum supply voltage	4.75 V
Nominal supply voltage	5 V
surface mount	NO
technology	CMOS
Temperature level	COMMERCIAL
Terminal surface	Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	7.62 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER
Base Number Matches	1

Preview

Download Datasheet

View All

CY7C63310, CY7C638xx

enCoRe™ II

Low Speed USB Peripheral Controller

enCoRe™ II Low Speed USB Peripheral Controller

Features

■

GPIO ports

❐

USB 2.0-USB-IF certified (TID # 40000085)

enCoRe™ II USB - ‘enhanced

Component Reduction’

❐

Up to 20 GPIO pins

2 mA source current on all GPIO pins. Configurable 8 or

50 mA/pin current sink on designated pins.

Each GPIO port supports high impedance inputs,

configurable pull-up, open drain output, CMOS/TTL inputs,

and CMOS output

Maskable interrupts on all I/O pins

Crystalless oscillator with support for an external clock. The

internal oscillator eliminates the need for an external crystal

or resonator.

Two internal 3.3 V regulators and an internal USB Pull-up

resistor

Configurable I/O for real world interface without external

components

Conforms to USB Specification, Version 2.0

Conforms to USB HID Specification, Version 1.1

Supports one low speed USB device address

Supports one control endpoint and two data endpoints

Integrated USB transceiver with dedicated 3.3 V regulator for

USB signalling and D– pull-up.

Harvard architecture

M8C CPU speed is up to 24 MHz or sourced by an external

clock signal

Up to 256 bytes of RAM

Up to eight Kbytes of flash including EEROM emulation

■

❐

■

❐

A dedicated 3.3 V regulator for the USB PHY. Aids in signalling

and D– line pull-up

125 mA 3.3 V voltage regulator powers external 3.3 V devices

3.3 V I/O pins

❐

USB Specification compliance

❐

4 I/O pins with 3.3 V logic levels

Each 3.3 V pin supports high impedance input, internal

pull-up, open drain output or traditional CMOS output

Master or slave operation

Configurable up to 4 Mbps transfers in the master mode

Supports half duplex single data line mode for optical sensors

SPI serial communication

❐

■

Enhanced 8-bit microcontroller

❐

2-channel 8-bit or 1-channel 16-bit capture timer registers.

Capture timer registers store both rising and falling edge times.

❐

■

Internal memory

❐

Two registers each for two input pins

Separate registers for rising and falling edge capture

Simplifies the interface to RF inputs for wireless applications

Periodic wakeup with no external components

■

Interface can auto configure to operate as PS/2 or USB

❐

Internal low power wakeup timer during suspend mode:

❐

No external components for switching between PS/2 and

USB modes

No General Purpose I/O (GPIO) pins required to manage

dual mode capability

Typically 10 mA at 6 MHz

A

sleep

Allows easy firmware update

■

12-bit Programmable Interval Timer with interrupts

Advanced development tools based on Cypress PSoC® tools

Watchdog timer (WDT)

Low-voltage detection with user configurable threshold

voltages

Operating voltage from 4.0 V to 5.5 V DC

Operating temperature from 0 °C–70 °C

Available in 18-pin PDIP; 16, 18, and 24-pin SOIC; 24-pin

QSOP, and 24-pin and 32-pin QFN Sawn packages

Industry standard programmer support

■

Low power consumption

❐

■

In system reprogrammability

❐

Cypress Semiconductor Corporation

Document Number: 38-08035 Rev. *Q

•

198 Champion Court

•

San Jose

CA 95134-1709

•

408-943-2600

Revised November 19, 2012
