BLY8SMD32BTR datasheet, PDF - EEWORLD Datasheet

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > The connector> The connector> BLY8SMD32BTR

Preview

BLY8SMD32BTR: DescriptionBoard Connector, 32 Contact(s), 2 Row(s), Female, Straight, Surface Mount Terminal; CategoryThe connector The connector; File Size94KB，1 Pages; ManufacturerFischer Elektronik; Environmental Compliance

Download Datasheet Parametric View All

BLY8SMD32BTR Overview

Board Connector, 32 Contact(s), 2 Row(s), Female, Straight, Surface Mount Terminal

BLY8SMD32BTR Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Objectid	1305285448
Reach Compliance Code	compliant
Country Of Origin	Germany
YTEOL	8.4
Connector type	BOARD CONNECTOR
Contact to complete cooperation	GOLD
Contact completed and terminated	GOLD
Contact point gender	FEMALE
Contact material	NOT SPECIFIED
DIN compliance	NO
Filter function	NO
IEC compliance	NO
JESD-609 code	e4
MIL compliance	NO
Mixed contacts	NO
Installation method	STRAIGHT
Installation type	BOARD
Number of connectors	ONE
Number of rows loaded	2
Options	GENERAL PURPOSE
Terminal pitch	2 mm
Termination type	SURFACE MOUNT
Total number of contacts	32

Preview

Download Datasheet

View All

2.00

High-precision female headers in SMD mounting

for

0.5 mm and up to 0.56 mm Ø

art. no.

2

Ø 0,5

4,2

5

nx2

2

A

B

2,54

5,7

0,76

BLY 5 SMD ...

please indicate:

4,6

Pin 1

4

C

... no. of contacts

one row 4-20

... packing (option)

B SM =pick and place pad and bar magazine

art. no.

D

7,2

Ø 0,5

nx2

2

2,54

2

4,2

2

1,9

0,76

E

BLY 6 SMD ...

please indicate:

... no. of contacts

one row 2-20

... packing (option)

TR =tape and reel (2.400 pcs/reel)

F

art. no.

4

2

n/2 x 2,0

2

4,2

2

Ø 0,5

5,7

7

BLY 8 SMD ...

please indicate:

6,8

Pin 1

2,54

G

0,76

... no. of contacts

two rows 4-40

... packing (option)

B SM =pick and place pad and bar magazine

B TR =pick and place pad and tape and reel

(650 pcs/reel)

H

contact shell surface:

tin-plated

contact spring:

gold-plated

I

No capilliary action when soldering due to protected contact insert.

V-notches permit breaking! Therefore any required number of contacts is available.

... packing (option) - additions:

BLY 6 SMD ... TR: 2-10 contacts

BLY 8 SMD ... B TR: 6-30 contacts

For further informations please see "for automatic assembly" following this series!

K

L

M

Female header grid 2.00

Technical data

Female headers 2.00 solder

Female headers 2.54 SMD

➔

H 10

G 75 - 80

G 60

G 46 - 49

Male headers 2.00 SMD

Female headers 2.00 SMD

Male headers 2.00 solder

➔

G 61 - 62

G 64
