FQD3N60TM datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> The transistor> FQD3N60TM

FQD3N60TM: DescriptionPower Field-Effect Transistor, 2.4A I(D), 600V, 3.6ohm, 1-Element, N-Channel, Silicon, Metal-oxide Semiconductor FET, TO-252, DPAK-3; CategoryDiscrete semiconductor The transistor; File Size573KB，9 Pages; ManufacturerFairchild; Websitehttp://www.fairchildsemi.com/; Environmental Compliance

Download Datasheet Parametric View All

FQD3N60TM Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	FQD3N60TM	-	-	View	Buy Now

FQD3N60TM Overview

Power Field-Effect Transistor, 2.4A I(D), 600V, 3.6ohm, 1-Element, N-Channel, Silicon, Metal-oxide Semiconductor FET, TO-252, DPAK-3

FQD3N60TM Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Fairchild
Parts packaging code	TO-252
package instruction	DPAK-3
Contacts	3
Reach Compliance Code	not_compliant
Avalanche Energy Efficiency Rating (Eas)	200 mJ
Shell connection	DRAIN
Configuration	SINGLE WITH BUILT-IN DIODE
Minimum drain-source breakdown voltage	600 V
Maximum drain current (Abs) (ID)	2.4 A
Maximum drain current (ID)	2.4 A
Maximum drain-source on-resistance	3.6 Ω
FET technology	METAL-OXIDE SEMICONDUCTOR
JEDEC-95 code	TO-252
JESD-30 code	R-PSSO-G2
JESD-609 code	e3
Humidity sensitivity level	1
Number of components	1
Number of terminals	2
Operating mode	ENHANCEMENT MODE
Maximum operating temperature	150 °C
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260
Polarity/channel type	N-CHANNEL
Maximum power dissipation(Abs)	50 W
Maximum pulsed drain current (IDM)	9.6 A
Certification status	Not Qualified
surface mount	YES
Terminal surface	Matte Tin (Sn)
Terminal form	GULL WING
Terminal location	SINGLE
Maximum time at peak reflow temperature	NOT SPECIFIED
transistor applications	SWITCHING
Transistor component materials	SILICON
Base Number Matches	1

Preview

Download Datasheet

View All

FQD3N60 / FQU3N60

April 2000

QFET

FQD3N60 / FQU3N60

600V N-Channel MOSFET

General Description

These N-Channel enhancement mode power field effect

transistors are produced using Fairchild’s proprietary,

planar stripe, DMOS technology.

This advanced technology has been especially tailored to

minimize on-state resistance, provide superior switching

performance, and withstand high energy pulse in the

avalanche and commutation mode. These devices are well

suited for high efficiency switch mode power supply.

Features

•

2.4A, 600V, R

DS(on)

= 3.6Ω @V

= 10 V

Low gate charge ( typical 10 nC)

Low Crss ( typical 5.5 pF)

Fast switching

100% avalanche tested

Improved dv/dt capability

! "

D-PAK

FQD Series

I-PAK

G D S

FQU Series

Absolute Maximum Ratings

Symbol

DSS

GSS

dv/dt

= 25°C unless otherwise noted

Parameter

Drain-Source Voltage

- Continuous (T

= 25°C)

Drain Current

- Continuous (T

= 100°C)

Drain Current

- Pulsed

(Note 1)

FQD3N60 / FQU3N60

600

2.4

1.5

9.6

±30

(Note 2)

(Note 1)

(Note 3)

Units

V/ns

W/°C

°C

Gate-Source Voltage

Single Pulsed Avalanche Energy

Avalanche Current

Repetitive Avalanche Energy

Peak Diode Recovery dv/dt

Power Dissipation (T

= 25°C) *

Power Dissipation (T

= 25°C)

200

2.4

5.0

4.5

2.5

0.4

-55 to +150

300

, T

STG

- Derate above 25°C

Operating and Storage Temperature Range

Maximum lead temperature for soldering purposes,

1/8from case for 5 seconds

Thermal Characteristics

Symbol

θJC

θJA

Parameter

Thermal Resistance, Junction-to-Case

Thermal Resistance, Junction-to-Ambient *

Thermal Resistance, Junction-to-Ambient

Typ

Max

2.5

110

Units

°CW

* When mounted on the minimum pad size recommended (PCB Mount)

Rev. A, April 2000
