INTERCONNECTS
SERIES 800 & 801 • 5,08 GRID (0,76 DIA. PINS),
STRAIGHT AND RIGHT ANGLE • SINGLE ROW STRIPS
•
Series 800 selectively loaded headers uses MM
#5005 pins. See page 215 for details
2,54
2,54
(Number of pins
X 5,08) - 2,54
(Number of pins X 5,08) - 2,54
•
Series 801 selectively loaded sockets use MM
#1303, #1304 and #1305 pins. See pages 177,
179 & 180 for details
2,54
3,2
4,95
2,79
•
Series 801 selectively loaded sockets use
Hi-Rel, 6-finger BeCu #47 contact rated at
3 amps. See page 256 for details
1,27
0,61 DIA.
0,76 DIA.
4,5
•
Insulators are high temperature thermoplastic,
suitable for all soldering operations
FIG. 1
7,01
6,1
2,24
(Number of pins
X 5,08) - 2,54
ORDERING INFORMATION
Series 800...20-201
Right Angle Header
02-32
For
Electrical, Mechanical
& Enviromental Data,
See page 264
FIG. 1
2,54
3,2
800-10-0_ _-20-201000
Specify number of pins
1,27
0,61 DIA.
2011/65/EU
8,31
RoHS - 2
XX=Plating Code
See Below
10
0,25μm
Au
FIG. 2
0,64-0,94
0,64 * 0,64
2,54
(Number of pins
X 5,08) - 2,54
SPECIFY PLATING CODE XX=
Pin Plating
Series 801...20-201
Right Angle Socket
02-25
2,24
FIG. 2
3,71 4,19
3,18
801-XX-0_ _-20-201000
Specify number of pins
0,56 DIA.
Series 801...10-212
Straight Socket
02-18
FIG. 3
801-43-0_ _-10-212000
Specify number of pins
FIG. 3
PAGE 64 | INTERCONNECTS
0,64-0,94
0,64 * 0,64
2,54
(Number of pins
X 5,08) - 2,54
Series 801...10-201
Straight Socket
02-25
For
Electrical, Mechanical
& Enviromental Data,
See page 264
FIG. 4
RoHS - 2
801-43-0_ _-10-201000
Specify number of pins
2,24
6,1
6,55 7,01
2011/65/EU
0,61 DIA.
3,0
XX=Plating Code
See Below
SPECIFY PLATING CODE XX=
Sleeve
(Pin)
Contact
(Clip)
41
43
FIG. 4
5,08μm
Sn
5,08μm
Sn
0,25μm
Au
0,76μm
Au
Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com
