KTC3199-O
KTC3199-Y
KTC3199-GR
KTC3199-BL
NPN General
Purpose Application
Features
•
•
•
•
High DC Current Gain: h
FE
=70~700
Excellent h
FE
Linearity: h
FE
(0.1mA)/h
FE
(2.0mA)=0.95(Typ)
Low Noise: NF=1.0dB(Typ.), 10dB(Max.)
Complementary to KTA1267
•
•
•
•
Marking: C3199
Epoxy meets UL 94 V-0 flammability rating
Moisture Sensitivity Level 1
Lead Free Finish/RoHS Compliant ("P" Suffix designates
RoHS Compliant. See ordering information)
Halogen
free available upon request by adding suffix "-HF"
TO-92S
B
Unit
V
V
V
mA
A
mW
O
C
O
C
Maximum Ratings
Symbol
V
CEO
V
CBO
V
EBO
I
C
I
E
P
C
T
J
T
STG
Rating
Collector-Emitter Voltage
Collector-Base Voltage
Emitter-Base Voltage
Collector Current
Emitter Current
Collector power dissipation
Junction Temperature
Storage Temperature
Rating
50
50
5.0
150
150
400
-55 to +150
-55 to +150
C
Electrical Characteristics @ 25
O
C Unless Otherwise Specified
Symbol
Parameter
Collector-Base Cutoff Current
(V
CB
=50Vdc,I
E
=0)
Emitter-Base Cutoff Current
(V
EB
=5.0Vdc, I
C
=0)
Min
---
---
Typ
---
---
Max
0.1
0.1
Units
uAdc
uAdc
1. GND
2. OUT
3. IN
OFF CHARACTERISTICS
I
CBO
I
EBO
ON CHARACTERISTICS
DC Current gain
(1)
70
---
700
(I
C
=2.0mAdc, V
CE
=6.0Vdc)
V
CE(sat)
Collector-Emitter Saturation Voltage
---
0.1
0.25
(I
C
=100mAdc, I
B
=10mAdc)
f
T
Transistor Frequency
80
---
---
(V
CE
=10Vdc, I
C
=1.0mAdc)
---
2.0
3.5
C
ob
Collector Output Capacitance
(V
CB
=10Vdc, I
E
=0, f=1.0MHz)
NF
Noise Figure
(V
CE
=6.0Vdc, I
C
=0.1mAdc, f=1.0kHz,
---
1.0
10
Rg=10KOHM)
(1) h
FE
Classification O: 70~140, Y: 120~240, GR: 200~400, BL: 300~700
h
FE
---
Vdc
1
1
2
3
2
D
MHz
pF
3
E
STRAIGHT LEAD BENT LEAD
BULK PACK
AMMO PACK
DIMENSIONS
dB
DIM
A
B
C
INCHES
MIN
MAX
.056
.064
.154
.161
.120
.128
MM
MIN
1.42
3.90
3.05
MAX
1.62
4.10
3.25
NOTE
.050
1.27
Straight Lead
.086
.110
2.20
2.80
Bent Lead
.096
.104
2.44
2.64
Straight Lead
E
.173
.220
4.40
5.60
Bent Lead
L
.594
.610
15.10
15.50
* For ammo packing detailed specification, click here to visit our website
of product packaging for details.
D
www.mccsemi.com
Revision:
C
1 of 4
2013/01/01
