PART NUMBER CODING
SBH11-_BPC-D_ _-RA-_ _
INSULATOR MATERIAL
F
REVISIONS
REV.
A
ECO. NO
1682
1852
2103
2537
2912
DESCRIPTION
INITIAL RELEASE
UPDATE DIM "C", TABLE, NOTE 3 & TOLERANCE
BLOCK
ADD BOX INSIDE DEPTH 6.40mm, NOTE 10, MATED
COMPONENTS & HEIGHT ON SHEET 2
UPDATE NOTE 5 PROCESSING TEMPERATURE
ADD MATERIAL 'N' OPTION
DATE
05/08/2008
11/12/2008
04/09/2010
02/29/2012
1/30/2014
BY
VJ
JH
LH
LH
JHSU
F
COLOR
BK= BLACK
YE= YELLOW
RE= RED
BL= BLUE
GR= GREEN
GY= GREY
WH= WHITE
OR= ORANGE
B
C
D
E
N = NYLON 6T
PROCESSING TEMP.: 230°C FOR 60 SECONDS MAX
(260°C FOR 10 SECONDS MAX)
P = PBT
PROCESSING TEMP.: WAVE/MANUAL SOLDERING
NUMBER OF POSITIONS
(CONTACTS PER ROW)
PRELIMINARY
A
2X .045 1.15
.100 2.54
.039[1.00]
E
TERMINATION
E
RIGHT ANGLE
C .012[ 0.30]
.100 2.54
.256 6.50
.100 2.54
D
.177 4.50
( .098[2.50] FOR POSITION #3)
B .012[ 0.30]
.252 6.40 .126 3.20
.423 10.74
D
RECOMMENDED PCB LAYOUT
.346 8.80
PART NUMBER
SBH11-_BPC-D03-RA-_ _
SBH11-_BPC-D04-RA-_ _
SBH11-_BPC-D05-RA-_ _
SBH11-_BPC-D06-RA-_ _
SBH11-_BPC-D07-RA-_ _
SBH11-_BPC-D08-RA-_ _
SBH11-_BPC-D10-RA-_ _
SBH11-_BPC-D12-RA-_ _
SBH11-_BPC-D13-RA-_ _
SBH11-_BPC-D15-RA-_ _
SBH11-_BPC-D17-RA-_ _
SBH11-_BPC-D20-RA-_ _
SBH11-_BPC-D22-RA-_ _
SBH11_BPC-D25-RA-_ _
SBH11-_BPC-D30-RA-_ _
SBH11-_BPC-D32-RA-_ _
POSITIONS/
CONTACTS
INCH
A
0.200
0.300
0.400
0.500
0.600
0.700
0.900
1.100
1.200
1.400
1.600
1.900
2.100
2.400
2.900
3.100
MM
5.08
7.62
10.16
12.70
15.24
17.78
22.86
27.94
30.48
35.56
40.64
48.26
53.34
60.96
73.66
78.74
INCH
0.595
0.695
0.795
0.895
0.995
1.095
1.295
1.495
1.595
1.795
1.995
2.295
2.495
2.795
3.295
3.495
B
MM
15.12
17.66
20.20
22.74
25.28
27.82
32.90
37.98
40.52
45.60
50.68
58.30
63.38
71.00
83.70
88.78
INCH
0.505
0.605
0.705
0.805
0.905
1.005
1.205
1.405
1.505
1.705
1.905
2.205
2.405
2.705
3.205
3.405
C
MM
12.82
15.36
17.90
20.44
22.98
25.52
30.60
35.68
38.22
43.30
48.38
56.00
61.08
68.70
81.40
86.48
C
.358 9.10
.100 2.54
A
.025 0.64
.100 2.54
.346 8.80
B
.358 9.10
A
NOTES:
1. INSULATOR MATERIAL: SEE PART NUMBER CODING.
COLOR: SEE PART NUMBER CODING.
2. CONTACT MATERIAL: BRASS.
3. CONTACT PLATING: .000030"~.000050" NICKEL UNDERPLATE, GOLD FLASH OVERALL.
4. OPERATING TEMPERATURE: SEE PART NUMBER CODING.
5. PROCESSING TEMP.: SEE PART NUMBER CODING.
6. CONTACT RESISTANCE: 20 MILLIOHMS MAX.
7. CURRENT RATING: 3 AMPS PER CONTACT.
8. DIELECTRIC WITHSTANDING: 500 V AC.
9. INSULATOR RESISTANCE: 1000 MEGOHMS MIN.
10. MATES WITH SFH11, SFH210 & SFH213 SERIES.
03/06
04/08
05/10
06/12
07/14
08/16
10/20
12/24
13/26
15/30
17/34
20/40
22/44
25/50
30/60
32/64
DRAWN
C
B
DATE
NAME
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN INCHES [MM]
05/08/2008 VJ
THE INFORMATION HEREIN CONTAINS
PROPIETARY INFORMATION OF
SULLINS ELECTRONICS AND IS NOT
TO BE REPRODUCED, USED OR
DISCLOSED TO OTHERS FOR ANY
PURPOSE EXCEPT AS SPECIFICALLY
AUTHORIZED IN WRITING BY AN
OFFICER OF SULLINS ELECTRONICS.
Pb
RoHS
COMPLIANT
4
TOLERANCES:
ANGULAR:
DECIMALS
.XX= .012 [.3]
.XXX= .008 [.20]
.XXXX= .0040 [.100]
3
TITLE
A
BOX HEADER, .100[2.54] CC/RS, RA
PART NUMBER
SBH11-_BPC-D_ _-RA-_ _
SIZE
CAGE CODE
DWG. NO.
REV
C
2
54453
11092
SHEET 1 OF 2
1
E
SCALE: 4:1
8
7
6
5
FILE NAME: 11092, SBH11-_BPC-D_ _-RA-_ _
8
7
6
5
4
3
2
1
F
F
2
.441 11.20
1
E
2
2
E
FLAT CABLE
FLAT CABLE
.722 18.35 *
ITEM 1 SBH11-_BPC-D_ _-RA-_ _
SFH11-P_ _C-D_ _-ST-_ _
D
( with polarizing key )
ITEM 2
(MATES)
SFH11-P_ _C-D_ _-ST-_ _-M181
( without polarizing key )
.526 13.35 *
.380 9.65
1
.380 9.65
1
D
2
C
ITEM 1 SBH11-_BPC-D_ _-RA-_ _
.441 11.20
ITEM 1 SBH11-_BPC-D_ _-RA-_ _
SFH213-PP_C-D_ _-ID-BK
ITEM 2**
(MATES)
(with polarizing key & strain relief)
C
SFH210-PP_C-D_ _-ID-BK
1
ITEM 2**
(MATES)
(with polarizing key & without strain relief)
SFH210-PP_C-D_ _-ID-BK-M181
(without polarizing key & strain relief)
SFH213-PP_C-D_ _-ID-BK-M181
(without polarizing key & with strain relief)
** COMPONENTS FOR POSITION # 3-25 AS SHOWN
* APPROXIMATE FOR ALL AVAILABLE POSITION NUMBERS
B
** COMPONENTS FOR POSITION # 3-25 AS SHOWN
* APPROXIMATE FOR ALL AVAILABLE POSITION NUMBERS
B
ITEM 1 SBH11-_BPC-D_ _-RA-_ _
SFH11-P_ _C-D_ _-RA-_ _
( with polarizing key )
ITEM 2
(MATES)
SFH11-P_ _C-D_ _-RA-_ _-M181
( without polarizing key )
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN INCHES [MM]
A
DRAWN
DATE
NAME
05/08/2008 VJ
THE INFORMATION HEREIN CONTAINS
PROPIETARY INFORMATION OF
SULLINS ELECTRONICS AND IS NOT
TO BE REPRODUCED, USED OR
DISCLOSED TO OTHERS FOR ANY
PURPOSE EXCEPT AS SPECIFICALLY
AUTHORIZED IN WRITING BY AN
OFFICER OF SULLINS ELECTRONICS.
Pb
RoHS
COMPLIANT
8
7
6
5
4
TOLERANCES:
ANGULAR:
DECIMALS
.XX= .012 [.3]
.XXX= .008 [.20]
.XXXX= .0040 [.100]
3
TITLE
A
BOX HEADER, .100[2.54] CC/RS, RA
PART NUMBER
SBH11-_BPC-D_ _-RA-_ _
SIZE
CAGE CODE
DWG. NO.
REV
C
2
54453
11092
SHEET 2 OF 2
1
E
SCALE: 4:1
FILE NAME: 11092, SBH11-_BPC-D_ _-RA-_ _
