YAGeo CorPorATIoN
INDUCTORS / BEADS
PS Series
APPLICATIONS
Notebook Computers
PC Cards
Wireless Communication
Handheld Devices
SMD Wire Wound
Chip Inductors
OUTLINE
PRODUCT IDENTIFICATION
PS series is the newest shielding type ferrite wire wound chip inductors.
This wire wound ferrite construction provides extremely low DCr and high rating current.
PS
☐☐☐☐
-
☐☐☐☐
-
☐
Internal No.
Tolerance
Inductance
Dimensions
Product Symbol
FEATURES
Shielded power inductors
only 2.94 mm high
The specially designed ferrite cover provides magnetic shielding.
The best possible surface for pick and place handling.
■
Internal No.: N = Lead-Free
SHAPES AND DIMENSIONS
B
F
C
D
Unit: mm
A
E
G
H
I
Max.
PS1008
+0
Max.
3.81
Max.
2.94 / 3.05 2.20
+0
3.81
2.54
2.03
0.51
2.54
1.02
1.27
C = 2.94 mm at 1r0~331/ 561~102, C = 3.05 mm at 471
I
J
TYPE
A
B
C
D
E
F
G
H
I
J
Pad Layout
70
ELECTRICAL CHARACTERISTICS
PART NO.
INDUCTANCE TEST
(µH)
1.0
1.5
1.8
2.7
3.9
4.7
5.6
6.8
10
15
22
33
39
47
68
82
100
120
150
220
330
470
560
680
820
1,000
FREQUENCY
(MHz)
PS1008-1r0□-N
PS1008-1r5□-N
PS1008-1r8□-N
PS1008-2r7□-N
PS1008-3r9□-N
PS1008-4r7□-N
PS1008-5r6□-N
PS1008-6r8□-N
PS1008-100□-N
PS1008-150□-N
PS1008-220□-N
PS1008-330□-N
PS1008-390□-N
PS1008-470□-N
PS1008-680□-N
PS1008-820□-N
PS1008-101□-N
PS1008-121□-N
PS1008-151□-N
PS1008-221□-N
PS1008-331□-N
PS1008-471□-N
PS1008-561□-N
PS1008-681□-N
PS1008-821□-N
PS1008-102□-N
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
10 / 20
10 / 20
10 / 20
10 / 20
10 / 20
10 / 20
10 / 20
10 / 20
10 / 20
10 / 20
10 / 20
10 / 20
10 / 20
10 / 20
10 / 20
10 / 20
10 / 20
10 / 20
10 / 20
10 / 20
10 / 20
10 / 20
10 / 20
10 / 20
10 / 20
10 / 20
26
26
28
30
30
30
30
30
30
30
33
33
33
33
33
33
33
33
33
33
33
33
33
33
23
20
TOLERANCE Q
(±%)
TEST
(MHz)
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
344
260
225
185
172
157
150
110
95
75
30
21
18
15
12
10
8.0
8.0
5.8
5.5
3.8
3.1
2.8
2.5
2.0
1.5
SRF
DC
RESISTANCE
(Ω) Max.
0.05
0.08
0.09
0.14
0.29
0.35
0.39
0.58
0.75
1.15
1.40
1.61
1.85
2.20
3.80
4.30
4.80
5.00
6.50
12.0
17.0
19.0
18.4
24.0
26.0
29.2
3.00
2.80
2.10
1.50
1.20
1.10
1.10
0.90
0.82
0.70
0.65
0.52
0.46
0.43
0.33
0.32
0.31
0.25
0.24
0.22
0.20
0.16
0.13
0.12
0.10
0.10
IDC
(A)
TYPICAL FREQUENCY (MHz) Typ.
Note:
When ordering, please specify tolerance and packaging codes.
Tolerance: K = ± 10%, M = ± 20%
Packaging: Clear tape and reel (standard)
Test Instruments: L- Agilent/HP4285A (0.1 Vrms)
Q- Agilent/HP4291A+Agilent/HP16197A
SrF- Agilent/HP4291A
rDC- CH502BC/HP4338B
IDC- For Inductance drop 10% from its value without current
operating Temperature range: -25 °C to +85 °C
