1000XFR series
Single Output
DC/DC Converter
NEW
Approved for New Designs
www.martekpower.com
F
EATURES
•
•
•
•
•
Up to 87% Efficiency
Single Output, 10 watt converter
Available in 24 and 48 VDC Inputs
2 - 1 Input Range
Industry Standard 1.25” X 0.8” X 0.4” Package
Short Circuit Protection
D
ESCRIPTIONS
The 1000XFR series are low-profile dc-dc converters that
operate over input voltage ranges of 18 - 36 VDC and 36 - 75
VDC and provide precisely regulated output voltages of 2.5V,
3.3V, 5V and 12V.
The -40
o
C to +60
o
C operating temperature range makes it
ideal for data communication equipments, mobile battery
driven equipment, distributed power systems, telecommunication
equipment, mixed analog/digital subsystems, process/
machine control equipment, computer peripheral systems
and industrial robot systems.
I
NPUT
C
HARACTERISTICS
Min Typ Max Units/Comments
Input Voltage
24 VDC Input Models
48 VDC Input Models
Under Voltage Shut Down
24 VDC Input Models
48 VDC Input Models
Input Current at No Load
24 VDC Input Models
48 VDC Input Models
Full Load Input Current
24 VDC Input Models
48 VDC Input Models
Input Fuse Requirements
24 VDC Input Models
48 VDC Input Models
Efficiency by Model
1002V5S24XFR
1003V3S24XFR
1005S24XFR
1012S24XFR
1002V5S48XFR
1003V3S48XFR
1005S48XFR
1012S48XFR
Switching Frequency
Input - Output Capacitance
Input Filter
Isolation Voltage
Isolation Resistance
18
36
24
48
36
75
17
34
20
10
0.50
0.26
VDC
VDC
VDC
VDC
mA
mA
A
A
O
UTPUT
C
HARACTERISTICS
Min Typ Max Unit/Comments
±1
Output Voltage Set Point
% Output voltage at
nominal line & FL
+2 % Output voltage
-2
Total Band Error
including line/load
regulation setting
±0.3 ±1 Change /
Line Regulation
Percentage change
in Input
voltage
±1.5
Load Regulation
% Output voltage
measured from FL
to 10% load
(Balanced Loads)
±0.01 ±0.02 % per degree C
Temperature Coefficient
60 100 mV p-p measured
Ripple/Noise
at 20 MHz bandwidth
with external 1
µf
capacitor
Output Voltage and Current
Refer to model
selection chart
±3 ±5 % deviation of Vout
Load Transient Response
voltage for a 25%
load change for
500µS
Short Circuit Protection
Indefinite, Automatic
Recovery
1 Amps; Slow blow type
0.5 Amps; Slow blow type
83
85
87
87
83
85
87
87
400
1500
1000
%; FL Nominal Line
%; FL Nominal Line
%; FL Nominal Line
%; FL Nominal Line
%; FL Nominal Line
%; FL Nominal Line
%; FL Nominal Line
%; FL Nominal Line
kHz; Factory set
pF
1200
Pi type
VDC
MOhms
Martek Power reserves the right to change specifications without notice.
B-75
M
ODEL
S
ELECTION
C
HART
Input Voltage
Output
(VDC)
Voltage (VDC)
1002V5S24XFR
1003V3S24XFR
1005S24XFR
1012S24XFR
1002V5S48XFR
1003V3S48XFR
1005S48XFR
1012S48XFR
24
24
24
24
48
48
48
48
2.5
3.3
5.0
12.0
2.5
3.3
5.0
12.0
Full Load
Output
Current (A)
3.00
3.00
2.00
0.83
3.00
3.00
2.00
0.83
G
ENERAL
C
HARACTERISTICS
Operating Temp. Range
Operating Temp. Range
Storage Temp. Range
Material Flammability
Relative Humidity
Weight
Size
Case Material
Agency Approvals
Min
-40
-40
-40
5
Typ
Max
+60
+90
+125
95
17.3
Unit/Comments
°C; measured
at ambient
°C; measured
at case
°C
UL94V-0
% Humidity,
non-condensing
Grams
1.25” X 0.8” X 0.4”
Metal with
non-conductive
baseplate
UL/CUL1950,
TUV, EN60950
O
UTLINE
D
RAWING
1.25 (31.8)
0.40
(10.2)
0.16 (4.1)
0.020 (0.50)
PIN DIA. TYP.
0.100 (2.54)
0.18 (4.5)
0.10
(2.5)
2
3
9
11
0.600 0.80
(15.22) (20.3)
14
BOTTOM VIEW
23 22
16
P
IN
O
UT
C
HART
Pins
2
3
9
11
14
16
22
23
NC = No Connection
All specifications are typical at nominal input, nominal load and 25
°
C unless otherwise specified.
External, low ESR, 10 microfarad (minimum) capacitor across input is recommended for operation.
Single
- Vin
- Vin
NO PIN
NC
+ Vout
- Vout
+ Vin
+ Vin
Notes:
1. Unless otherwise specified dimensions are in inches (mm).
Tolerances: X.XX = ±0.02 (±0.5)
X.XXX = ±0.010 (±0.25)
