DAP15PTK1NS-R datasheet, PDF - EEWORLD Datasheet

DAP15PTK1NS-R: DescriptionD Type Connector, 15 Contact(s), Male, 0.109 inch Pitch, Press Fit Terminal, #4-40, Receptacle; CategoryThe connector The connector; File Size84KB，1 Pages; ManufacturerGTK UK Ltd

Download Datasheet Parametric View All

DAP15PTK1NS-R Overview

D Type Connector, 15 Contact(s), Male, 0.109 inch Pitch, Press Fit Terminal, #4-40, Receptacle

Parameter Name	Attribute value
Objectid	304016563
Reach Compliance Code	compliant
ECCN code	EAR99
Other features	ROHS COMPLIANT
body width	0.494 inch
subject depth	0.236 inch
body length	1.541 inch
Body/casing type	RECEPTACLE
Contact point gender	MALE
Contact material	PHOSPHOR BRONZE
contact mode	STAGGERED
Contact resistance	30 mΩ
Contact style	RND PIN-SKT
Dielectric withstand voltage	1000VAC V
Insulation resistance	1000000000 Ω
insulator material	POLYAMIDE
Plug contact pitch	0.109 inch
Match contact row spacing	0.112 inch
Installation option 1	#4-40
Installation option 2	THREADED
Installation method	STRAIGHT
Installation type	BOARD
PCB row number	2
Number of rows loaded	2
Maximum operating temperature	235 °C
Minimum operating temperature	-55 °C
Options	GENERAL PURPOSE
PCB contact pattern	STAGGERED
PCB contact row spacing	2.8448 mm
Rated current (signal)	5 A
Guideline	UL
Shell surface	TIN
Shell material	STEEL
Terminal length	0.134 inch
Terminal pitch	2.7686 mm
Termination type	PRESS FIT
Total number of contacts	15
