881-001PA-J7W19N-MT205J5-24 Overview

Circular Connector

881-001PA-J7W19N-MT205J5-24 Parametric

Parameter NameAttribute value
Objectid1947359174
Reach Compliance Codecompliant
ECCN codeEAR99
Connector typeCIRCULAR CONNECTOR
A
B
C
D
E
F
G
H
5 Amp
Series 88 SuperFly
Series 88 SuperFly
Series 881 Threaded Coupling Connectors
881-001 Cable Plugs
CAblE PlUGS WITh PIGTAIl WIRES, 24 INChES OVERAll lENGTh
Series 881 threaded coupling plugs are pre-wired and sealed with epoxy. Integral shield termination
platform. Three contact sizes are available, 5A, 3A and 1A. Aluminum or stainless steel housings,
thermoplastic insulator, high-strength wire with crosslinked ETFE insulation. high performance
contacts, crimp termination to wires. Ultraminiature Superfly connectors are ideal for soldier systems
and other applications where reduced size and weight are critical.
Contact Arrangements
ComBo
5 Amp & 1Amp
3 Amp
ComBo
3 Amp & 1 Amp
1 Amp
(3) 5A
E3W
(7) 5A
G7W
(2) 5A, (2) 1A (4) 5A, (4) 1A
D2W2N
F4W4N
(3) 3A
D3M
(10) 3A
G10M
(2) 3A, (2) 1A (4) 3A, (4) 1A
C2M2N
E4M4N
(7) 1A
B7N
(10) 1A
C10N
(19) 1A
E19N
(10) 5A
H10W
(6) 5A, (14) 1A (7) 5A, (19) 1A
H6W14N
J7W19N
(19) 3A
K19M
(22) 3A
L22M
(6) 3A, (10) 1A (13) 3A, (19) 1A
G6M10N
K13M19N
(22) 1A
F22N
(37) 1A
H37N
(44) 1A
J44N
Description
Current Rating
Wire Size
Dielectric Withstanding Voltage
Contact Resistance
Temperature Range
Durability (mating cycles)
Corrosion (salt fog)
Water Immersion,Mated
Ingress Protection
Vibration
Shock
Product Specifications
5 Amp Contact
5A
#24 AWG
500Vac
20 milliohms
3A
3 Amp Contact
#26 AWG
600Vac
32 milliohms
1 Amp Contact
1A
#30 AWG
250Vac
80 milliohms
Materials and Finishes
Insulator
Shell
1A. Contact
3A. and 5A.
Contact
Encapsulant
Wire
Thermoplastic, glass-filled
Aluminum or stainless steel
Precious metal alloy pin, gold-
plated copper alloy socket
Copper alloy, 50 microinches
gold over nickel finish
Epoxy
High strength silver-coated
copper alloy, ETFE insulation
(M22759/33 or equiv.)
-55°C to +150°C
2000
Nickel finish 48 hours, other finishes 500 hours
MIL-STD-810 Method 512, 1 meter, 2 hours
IP 67
37g
300g
24.0 (610)
.853 (21.67)
.540 (13.72)
ØB
ØA
Dimensions
Shell Size
B
C
D
E
F
G
H
J
K
L
ØA
In.
mm.
.356
.375
.395
.415
.434
.454
.493
.533
.553
.592
9.04
9.53
10.03
10.54
11.02
11.53
12.52
13.54
14.05
15.04
ØB
In.
mm.
.199
.224
.237
.263
.282
.304
.341
.369
.391
.430
5.05
5.69
6.02
6.68
7.16
7.72
8.66
9.37
9.93
10.92
PIGTAIL WIRES
BAND-MASTER MICROBAND SHIELD
TERMINATION PLATFORM
© 2012 Glenair, Inc.
Dimensions in inches (millimeters) and are subject to change without notice.
CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912
www.glenair.com
May 2013
E-3
