Feed-through terminal block - ST 1,5 OG - 3037012
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
Feed-through terminal block, nom. voltage: 500 V, nominal current: 17.5 A, connection method: Spring-cage
connection, number of connections: 2, cross section:0.08 mm² - 1.5 mm², AWG: 28 - 16, width: 4.2 mm, color:
orange, mounting type: NS 35/7,5, NS 35/15
Your advantages
As well as saving space, the compact design and front connection enable user-friendly wiring in a small amount of space
The consistent double function shaft offers every opportunity for time-saving potential distribution and accommodating test accessories
The large wiring space enables the use of conductors with ferrules and plastic collars within the nominal cross section
Key Commercial Data
Packing unit
GTIN
GTIN
4017918599454
50 pc
Technical data
General
Number of levels
Number of connections
Potentials
Nominal cross section
Color
Insulating material
Flammability rating according to UL 94
Rated surge voltage
Degree of pollution
Overvoltage category
Insulating material group
Maximum power dissipation for nominal condition
Maximum load current
1
2
1
1.5 mm²
orange
PA
V0
6 kV
3
III
I
0.56 W
17.5 A (with 1.5 mm² conductor cross section)
11/12/2018 Page 1 / 5
https://www.phoenixcontact.com/pi/products/3037012
Feed-through terminal block - ST 1,5 OG - 3037012
Technical data
General
Nominal current I
N
Nominal voltage U
N
Open side panel
17.5 A
500 V
Yes
Dimensions
Width
End cover width
Length
Height NS 35/7,5
Height NS 35/15
4.2 mm
2.2 mm
48.5 mm
36.5 mm
44 mm
Connection data
Connection method
Connection in acc. with standard
Conductor cross section solid min.
Conductor cross section solid max.
Conductor cross section AWG min.
Conductor cross section AWG max.
Conductor cross section flexible min.
Conductor cross section flexible max.
Min. AWG conductor cross section, flexible
Max. AWG conductor cross section, flexible
Conductor cross section flexible, with ferrule without plastic sleeve min.
Conductor cross section flexible, with ferrule with plastic sleeve min.
Conductor cross section flexible, with ferrule with plastic sleeve max.
2 conductors with same cross section, stranded, TWIN ferrules with
plastic sleeve, max.
Connection in acc. with standard
Conductor cross section solid min.
Conductor cross section solid max.
Conductor cross section AWG min.
Conductor cross section AWG max.
Conductor cross section flexible min.
Conductor cross section flexible max.
Stripping length
Internal cylindrical gage
Spring-cage connection
IEC 60947-7-1
0.08 mm²
1.5 mm²
28
16
0.08 mm²
1.5 mm²
28
16
0.14 mm²
0.14 mm²
1.5 mm²
0.5 mm²
IEC/EN 60079-7
0.08 mm²
1.5 mm²
28
16
0.08 mm²
1.5 mm²
8 mm ... 10 mm
A1
Conductor cross section flexible, with ferrule without plastic sleeve max. 1.5 mm²
Standards and Regulations
Connection in acc. with standard
Flammability rating according to UL 94
CSA
IEC 60947-7-1
V0
11/12/2018 Page 2 / 5
https://www.phoenixcontact.com/pi/products/3037012
Feed-through terminal block - ST 1,5 OG - 3037012
Technical data
Environmental Product Compliance
China RoHS
Environmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values
Approvals
Approvals
Approvals
DNV GL / CSA / PRS / BV / LR / KR / NK / UL Recognized / cUL Recognized / IECEE CB Scheme / VDE Gutachten mit Fertigungsüberwachung /
EAC / EAC / cULus Recognized
Ex Approvals
IECEx / ATEX / EAC Ex
Approval details
DNV GL
http://exchange.dnv.com/tari/
TAE00001CS
CSA
Nominal voltage UN
Nominal current IN
mm²/AWG/kcmil
B
300 V
15 A
26-14
http://www.csagroup.org/services-industries/product-listing/
C
300 V
15 A
26-14
13631
PRS
http://www.prs.pl/
TE/2156/880590/17
BV
http://www.veristar.com/portal/veristarinfo/generalinfo/
approved/approvedProducts/equipmentAndMaterials
13403/B0 BV
LR
http://www.lr.org/en
04/20034
11/12/2018 Page 3 / 5
https://www.phoenixcontact.com/pi/products/3037012
Feed-through terminal block - ST 1,5 OG - 3037012
Approvals
KR
B
300 V
15 A
26-14
http://www.krs.co.kr/eng/main/main.aspx
HMB17372-EL002
NK
http://www.classnk.or.jp/hp/en/
09 ME 140
UL Recognized
Nominal voltage UN
Nominal current IN
mm²/AWG/kcmil
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm
C
300 V
15 A
26-14
FILE E 60425
cUL Recognized
Nominal voltage UN
Nominal current IN
mm²/AWG/kcmil
B
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm
C
300 V
15 A
26-14
FILE E 60425
300 V
15 A
26-14
IECEE CB Scheme
Nominal voltage UN
mm²/AWG/kcmil
http://www.iecee.org/
DE1-51360
500 V
1.5
VDE Gutachten mit
Fertigungsüberwachung
Nominal voltage UN
Nominal current IN
mm²/AWG/kcmil
http://www2.vde.com/de/Institut/Online-Service/
VDE-gepruefteProdukte/Seiten/Online-Suche.aspx
500 V
17.5 A
1.5
40009031
11/12/2018 Page 4 / 5
https://www.phoenixcontact.com/pi/products/3037012
Feed-through terminal block - ST 1,5 OG - 3037012
Approvals
EAC
EAC-Zulassung
EAC
RU C-
DE.A*30.B.01742
cULus Recognized
Phoenix Contact 2018 © - all rights reserved
http://www.phoenixcontact.com
PHOENIX CONTACT GmbH & Co. KG
Flachsmarktstr. 8
32825 Blomberg
Germany
Tel. +49 5235 300
Fax +49 5235 3 41200
http://www.phoenixcontact.com
11/12/2018 Page 5 / 5
