Document 219-1
Power Chip Inductors - 1008PS Series
Coilcraft’s 1008PS Series is designed to be an economi-
cal alternative to larger and more costly shielded power
inductors.
Only 2.74 mm high, they are ideal for applications
requiring magnetic shielding, the smallest possible size
and lowest cost. Typical uses include notebook comput-
ers, PC cards, wireless communication and handheld
devices.
The specially designed ferrite cover provides magnetic
shielding and the best possible surface for pick and
place handling.
Coilcraft
Designer’s Kit C141
contains six samples each
of the standard parts shown. To order, contact Coilcraft or
visit
http://order.coilcraft.com.
DCR
4
Q min
max
@ 1 MHz (Ohms)
35
0.05
35
0.06
35
0.09
38
0.14
38
0.26
38
0.35
38
0.36
38
0.58
38
0.92
38
1.15
40
1.40
45
1.61
45
1.85
45
2.5
45
3.8
45
4.3
45
5.8
50
6.3
50
7.5
55
10.0
55
11.5
55
16.3
55
18.1
55
24.0
45
26.0
45
29.0
3
2
Part
L ±20%
number
1
(µH)
1008PS-102M_
1.0
1008PS-152M_
1.5
1008PS-182M_
1.8
1008PS-272M_
2.7
1008PS-392M_
3.9
1008PS-472M_
4.7
1008PS-562M_
5.6
1008PS-682M_
6.8
1008PS-103M_
10
1008PS-153M_
15
1008PS-223M_
22
1008PS-333M_
33
1008PS-393M_
39
1008PS-473M_
47
1008PS-683M_
68
1008PS-823M_
82
1008PS-104M_ 100
1008PS-124M_ 120
1008PS-154M_ 150
1008PS-224M_ 220
1008PS-334M_ 330
1008PS-474M_ 470
1008PS-564M_ 560
1008PS-684M_ 680
1008PS-824M_ 820
1008PS-105M_ 1000
1
2
2
2
SRF
5
typ
(MHz)
344
260
225
185
175
160
150
120
105
35
26
20
16
19
12
9.0
7.0
7.0
5.8
10.0
3.8
3.1
2.8
2.5
1.5
2.0
2
2
Isat
6
(A)
3.0
2.8
2.1
1.3
1.2
1.0
1.0
0.84
0.78
0.70
0.65
0.51
0.45
0.40
0.31
0.30
0.30
0.25
0.22
0.22
0.20
0.16
0.13
0.12
0.10
0.10
2
Irms
7
(A)
2.00
2.00
1.90
1.60
1.20
1.10
0.90
0.80
0.72
0.60
0.55
0.50
0.47
0.42
0.32
0.30
0.30
0.28
0.26
0.21
0.19
0.18
0.15
0.14
0.12
0.11
1. Specify
packaging
code:
1008PS-105MC
Packaging: C
= 7″ machine-ready reel. EIA-481 embossed plastic tape
(750 parts per full reel).
B
= Less than full reel. In tape, but not machine ready.
To have a leader and trailer added ($25 charge), use
code letter C instead.
D
= 13″ machine-ready reel. EIA-481 embossed plastic tape
(2500 parts per full reel).
2. Inductance measured at 100 kHz, 0.1 Vrms, using Coilcraft SMD-A fixture in
Agilent/HP 4263B impedance analyzer.
3. Q measured on Agilent/HP 4291 with Agilent/HP 16193 test fixture.
4. DCR measured on micro-ohmmeter and Coilcraft CCF840 test fixture.
5. SRF measured using Agilent/HP 8753D network analyzer and Coilcraft
SMD-D test fixture.
6. DC current at which the inductance drops 10% (typ) from its value without
current.
7. Average current for a 40°C rise above 25°C ambient.
8. Operating temperature range -40°C to +85°C.
9. Electrical specifications at 25°C.
See Qualification Standards section for environmental and test data.
Specifications subject to change without notice.
Document 219-1
Revised 10/4/02
