max. (Cable length: 2 m max., Sink current: 10 mA)
1×10
−6
kg·m
2
max.; 3
×
10
−7
kg·m
2
max. at 600 P/R max.
30 N
20 N
Maximum
6,000 r/min
permissible speed
Protection circuits
Power supply reverse polarity protection, Load short-circuit protection
Ambient
Operating:
−10
to 70°C (with no icing), Storage:
−25
to 85°C (with no icing)
temperature range
Ambient humidity
range
Insulation
resistance
Vibration
resistance
Shock resistance
Degree of
protection
Connection
method
Materials
Weight
(packed state)
Accessories
Operating/Storage: 35% to 85% (with no condensation)
20 MΩ min. (at 500 VDC) between current-carrying parts and case
---
Dielectric strength
500 VAC, 50/60 Hz for 1 min between current-carrying parts and case
Destruction: 10 to 500 Hz, 150 m/s
2
or 2-mm double amplitude for 11 min 3 times each in X, Y, and Z directions
Destruction: 1,000m/s
2
3 times each in X, Y, and Z directions
IEC 60529 IP50
Pre-wired Models (Standard cable length: 500 mm)
Case: ABS, Main unit: Aluminum, Shaft: SUS420J2
Approx. 100 g
Coupling, Hexagonal wrench, Instruction manual
*1. An inrush current of approximately 9 A will flow for approximately 0.3 ms when the power is turned ON.
*2. The line driver output is a data transmission circuit compatible with RS-422A and long-distance transmission is possible with a twisted-pair cable. The quality is
equivalent to AM26LS31.
*3. The maximum electrical response speed is determined by the resolution and maximum response frequency as follows:
Maximum response frequency
×
60
Maximum electrical response speed (rpm) =
Resolution
This means that the E6B2-C Rotary Encoder will not operate electrically if its speed exceeds the maximum electrical response speed.
2
E6B2-C
I/O Circuit Diagrams
Model/Output Circuits
Output mode
Connection
E6B2-CWZ6C
Brown
5
VDC
-
5% to
24
VDC
+
15%
Black, white, orange
E6B2
main
circuit
3.3
Ω
NPN
transistor
35 mA
max. at
30
VDC
max.
Output signal
(Black: phase A, White:
phase B, Orange: phase
Z)
Blue
Shield
0
V
GND
E6B2-CWZ6C NPN Open-collector Output Model
E6B2-CWZ5B PNP Open-collector Output Model
Direction of rotation: CW
(as viewed from end of shaft)
T(360˚)
ON
OFF
ON
Phase B
OFF
ON
Phase Z
OFF
Phase A
CW
Phase A
Direction of rotation: CCW
(as viewed from end of shaft)
T(360˚)
CCW
E6B2-CWZ5B
Brown
3.3
Ω
E6B2
main
circuit
35 mA
max.
Black, white, orange
PNP
transistor
Output signal
(Black: phase A, White: phase B,
Orange: phase Z)
12
VDC
−
10%
to
24
VDC
+
15%
ON
OFF
ON
Phase B
OFF
1/4±1/8T (90˚±45˚)
ON
Phase Z
OFF
1/4±1/8T (90˚±45˚)
Color
Brown
Black
White
Orange
Blue
Note: Phase A is 1/4 T
±
1/8 T
faster than phase B.
Note: Phase A is 1/4 T
±
1/8 T
slower than phase B.
The ONs in the above timing chart mean that the
output transistor is ON and the OFFs mean that the
output transistor is OFF.
Blue
Shield
0
V
GND
Terminal
Power supply
(+Vcc)
Output phase
A
Output phase
B
Output phase
Z
0 V (common)
E6B2-CWZ3E
E6B2-CWZ3E Voltage Output Model
Direction of rotation: CW
(as viewed from end of shaft)
Brown
Direction of rotation: CCW
(as viewed from end of shaft)
T(360˚)
Phase A
H
CCW
2 kΩ
E6B2
main
circuit
3.3
Ω
NPN
transistor
20 mA
max.
Blue
Shield
5
VDC
−
5%
to
12
VDC
+
10%
T(360˚)
Phase A
H
L
H
Phase B
L
H
Phase Z
L
CW
Black, white, orange
Output signal
(Black: phase A, White: phase
B, Orange: phase Z)
L
H
Phase B
L
1/4±1/8T(90˚±45˚)
H
Phase Z
L
1/4±1/8T(90˚±45˚)
0
V
GND
Note: Phase A is 1/4 T
±
1/8 T
faster than phase B.
Note: Phase A is 1/4 T
±
1/8 T
slower than phase B.
“H” and “L” in the diagrams are the output voltage
levels of phases A, B, and Z.
E6B2-CWZ1X
E6B2-CWZ1X Line Driver Output Model
Direction of rotation: CW
(as viewed from end of shaft)
T(360˚)
5 VDC
±
5%
Color
Brown
Black
Direction of rotation: CCW
(as viewed from end of shaft)
T(360˚)
CCW
CW
H
Phase A
L
H
Phase B
L
1/4±1/8T (90˚±45˚)
H
Phase Z
L
H
Phase A
L
H
Phase B
L
H
Phase Z
L
Brown
Black,
white,
orange
E6B2
main
circuit
AM26
LS31
equivalent
Non-reversed output
(Black: phase A,
White:
phase B,
Black,
white,
orange
Orange: phase Z)
Reversed output
(Black/red: Phase A,
White/red:
Phase B, Orange/red: Phase Z)
(with red stripe)
Blue
Shield
0V
GND
H
Phase A
L
H
Phase B
L
H
Phase Z
L
H
Phase A
L
H
Phase B
L
H
Phase Z
L
Black/red
stripes
White
1/4±1/8T (90˚±45˚)
White/red
stripes
Orange
Orange/
red
stripes
Blue
Terminal
Power supply
(+Vcc)
Output phase
A
Output phase
A
Output phase
B
Output phase
B
Output phase
Z
Output phase
Z
0 V (common)
Note: Phase A is 1/4 T
±
1/8 T
faster than phase B.
Note: Phase A is 1/4 T
±
1/8 T
slower than phase B.
“H” and “L” in the diagrams are the output voltage
levels of phases A, B, and Z.
Note: 1. The shielded cable outer core (shield) is not connected to the inner area or to the case.
2. The phase A, phase B, and phase Z circuits are all identical.
3. Normally, connect GND to 0 V or to an external ground.
Note: Receiver: AM26LS32
equivalent
3
E6B2-C
Safety Precautions
Be sure to read the precautions for all models in the website at: http://www.ia.omron.com/.
WARNING
This product is not designed or rated for ensuring
safety of persons either directly or indirectly.
Do not use it for such purposes.
Precautions for Safe Use
Incorrect wiring may damage internal circuits.
Precautions for Correct Use
Do not use the Encoder under ambient conditions that exceed the
ratings.
●
Mounting
•
Origin Indication
It is easy to adjust the position of phase Z with the origin indication
function. The following illustration shows the relationship between
phase Z and the origin. Set cut face D to the phase Z origin as
shown in the illustration.
Phase Z origin
•
Do not extend the length of the cable to more than 2 m. If the cable
must be more than 2 m, use a Model with a Line-driver Output
(max. length: 100 m).
●
Wiring
Spurious pulses may be generated when power is turned ON and
OFF. Wait at least 0.1 s after turning ON the power to the Encoder
before using the connected device, and stop using the connected
device at least 0.1 s before turning OFF the power to the Encoder.
Also, turn ON the power to the load only after turning ON the power
to the Encoder.
Origin
120˚
120˚
Cut face D
30±
0.2
dia.
(Unit: mm)
Dimensions
Encoder
E6B2-C
Origin of phase Z
Tolerance class IT16 applies to dimensions in this datasheet unless otherwise specified.
Three, M3 holes;
Depth: 7 mm
15
10
0
6
-0.012
dia.
0
-0.021
5
39
120˚
120˚
40 dia. 20 dia.
1
30±
0.2
dia.
7.5
*E6B2-CWZ6C/5B/3E:
5-dia. vinyl-insulated round cable with 5 conductors
(Conductor cross section: 0.2 mm
2
, Insulation
diameter: 1.0 mm), Standard length: 0.5 m
E6B2-CWZ1X:
5-dia. vinyl-insulated round cable with 8 conductors
(Conductor cross section: 0.2 mm
2
, Insulation
diameter: 1.0 mm), Standard length: 0.5 m
*
8
Accessories (Order Separately)
Couplings
E69-C06B
E69-C68B
E69-C610B
E69-C06M
Flanges
E69-FBA
E69-FBA02
Servo Mounting Bracket
E69-2
Refer to
Rotary Encoders Accessories
on your OMRON website for details.
4
Terms and Conditions Agreement
Read and understand this catalog.
Please read and understand this catalog before purchasing the products. Please consult your OMRON representative if you
have any questions or comments.
Warranties.
(a) Exclusive Warranty.
Omron’s exclusive warranty is that the Products will be free from defects in materials and workmanship
for a period of twelve months from the date of sale by Omron (or such other period expressed in writing by Omron). Omron
disclaims all other warranties, express or implied.
(b) Limitations. OMRON MAKES NO WARRANTY OR REPRESENTATION, EXPRESS OR IMPLIED, ABOUT
NON-INFRINGEMENT, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE OF THE PRODUCTS. BUYER
ACKNOWLEDGES THAT IT ALONE HAS DETERMINED THAT THE
PRODUCTS WILL SUITABLY MEET THE REQUIREMENTS OF THEIR INTENDED USE.
Omron further disclaims all warranties and responsibility of any type for claims or expenses based on infringement by the
Products or otherwise of any intellectual property right. (c) Buyer Remedy.
Omron’s sole obligation hereunder shall be, at
Omron’s election, to (i) replace (in the form originally shipped with Buyer responsible for labor charges for removal or
replacement thereof) the non-complying Product, (ii) repair the non-complying Product, or (iii) repay or credit Buyer an amount
equal to the purchase price of the non-complying Product; provided that in no event shall Omron be responsible for warranty,
repair, indemnity or any other claims or expenses regarding the Products unless Omron’s
analysis confirms that the Products
were properly handled, stored, installed and maintained and not subject to contamination, abuse, misuse or inappropriate
modification. Return of any Products by Buyer must be approved in writing by Omron before shipment. Omron Companies shall
not be liable for the suitability or unsuitability or the results from the use of Products in combination with any electrical or
electronic components, circuits, system assemblies or any other materials or substances or environments. Any advice,
recommendations or information given orally or in writing, are not to be construed as an amendment or addition to the above
warranty.
See
http://www.omron.com/global/
or contact your Omron representative for published information.
Limitation on Liability; Etc.
OMRON COMPANIES SHALL NOT BE LIABLE FOR SPECIAL, INDIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGES,
LOSS OF PROFITS OR PRODUCTION OR COMMERCIAL LOSS IN ANY WAY CONNECTED WITH THE PRODUCTS,
WHETHER SUCH CLAIM IS BASED IN CONTRACT, WARRANTY, NEGLIGENCE OR STRICT LIABILITY.
Further, in no event shall liability of Omron Companies exceed the individual price of the Product on which liability is asserted.
Suitability of Use.
Omron Companies shall not be responsible for conformity with any standards, codes or regulations which apply to the
combination of the Product in the Buyer’s application or use of the Product. At Buyer’s request, Omron will provide applicable
third party certification documents identifying ratings and limitations of use which apply to the Product. This information by itself
is not sufficient for a complete determination of the suitability of the Product in combination with the end product, machine,
system, or other application or use. Buyer shall be solely responsible for determining appropriateness of the particular Product
with respect to Buyer’s application, product or system. Buyer shall take application responsibility in all cases.
NEVER USE THE PRODUCT FOR AN APPLICATION INVOLVING SERIOUS RISK TO LIFE OR PROPERTY OR IN LARGE
QUANTITIES WITHOUT ENSURING THAT THE SYSTEM AS A WHOLE HAS BEEN DESIGNED TO ADDRESS THE RISKS,
AND THAT THE OMRON PRODUCT(S) IS PROPERLY RATED AND INSTALLED FOR THE INTENDED USE WITHIN THE
OVERALL EQUIPMENT OR SYSTEM.
Programmable Products.
Omron Companies shall not be responsible for the user’s programming of a programmable Product, or any consequence
thereof.
Performance Data.
Data presented in Omron Company websites, catalogs and other materials is provided as a guide for the user in determining
suitability and does not constitute a warranty. It may represent the result of Omron’s test conditions, and the user must correlate
it to actual application requirements. Actual performance is subject to the Omron’s
Warranty and Limitations of Liability.
Change in Specifications.
Product specifications and accessories may be changed at any time based on improvements and other reasons. It is our
practice to change part numbers when published ratings or features are changed, or when significant construction changes are
made. However, some specifications of the Product may be changed without any notice. When in doubt, special part numbers
may be assigned to fix or establish key specifications for your application.
Please consult with your Omron’s representative at
any time to confirm actual specifications of purchased Product.
Errors and Omissions.
Information presented by Omron Companies has been checked and is believed to be accurate; however, no responsibility is
assumed for clerical, typographical or proofreading errors or omissions.
2017.7
In the interest of product improvement, specifications are subject to change without notice.
OMRON Corporation
Industrial Automation Company
http://www.ia.omron.com/
(c)Copyright OMRON Corporation 2017 All Right Reserved.
I am a teacher. Our major is going to switch to embedded development. I am a web developer and don't know much about embedded. My idea is to go for embedded software development (software-oriented) in...
Introducing a magic tool that can connect the power analyzer to the CAN bus network, the WT-CAN communication adapter: iDAQ-WTCAN. It is the small box in the picture below. With it, you can directly c...
Which fast charging reference design is the best? I believe everyone has a standard in mind, whether it is performance, cost, speed, or other. The fast charging reference designs are listed here, hopi...
I'm in Beijing now. I've been to Gongzhufen, Lize Bridge on Fengtai North Road on the West Third Ring Road, and Anhua Bridge on the North Third Ring Road. I want to go to Ginza to have a look @@...
I saw a method on the InternetThe leakage test is to connect a resistor and a test switch between the live wire under the leakage coil and the ground wire above the leakage coil . The leakage resistan...
1. Overview
Will passive devices
produce nonlinear intermodulation distortion? The answer is yes! Although there is no systematic theoretical analysis, it has been found in engineerin...[Details]
1. Introduction
Since the 1980s, with the continuous development of automotive electronic technology, there are more and more electronic control units in automobiles, such as electronic fuel i...[Details]
Analog engineers have traditionally struggled with complexity when designing power supplies that required multiple outputs, dynamic load sharing, hot-swap, or extensive fault-handling capabilities....[Details]
1 Introduction
With the acceleration of the pace of urban modernization, society has higher requirements for urban road lighting and urban lighting projects. The state has clearly required tha...[Details]
The reason for the light decay of white LEDs: the decline of phosphor performance
So far, the rapid decline of the luminous performance of white light LEDs, especially low-power white light LE...[Details]
Images in science fiction movies often break through the limits of reality, such as in the movie "Minority Report." Tom Cruise uses a multi-touch screen to browse information. Capacitive sensing te...[Details]
A multi-point temperature control heating control system was designed using the SST89E564RC single-chip microcomputer and a new temperature measuring device. The heating system can be controlled in...[Details]
1 Introduction
Intelligent control instruments are one of the most commonly used controllers in industrial control. They are mainly aimed at a specific parameter (such as pressure, tempera...[Details]
my country is a big country in agriculture, grain production and consumption. Grains are a necessary condition for our nation to survive and develop. The flour processing industry will exist forever w...[Details]
This week, Microsoft held its 2012 Microsoft Worldwide Partner Conference (WPC) in Toronto, Canada. At the conference, Microsoft showed its new products and services to partners around the world. A...[Details]
Xiaomi, a well-known Internet phone in mainland China, won a million-unit order contract from China Unicom on November 20 last year, which made Xiaomi famous in mainland China. In April this year...[Details]
This paper designs a 16x16LED Chinese character display bar based on single-chip dynamic scanning control, briefly analyzes the principle of Chinese character display, and studies how the LED displ...[Details]
Investment in
the
medical device
industry has been on the rise in recent years. In the past two years, venture capital for medical devices has almost doubled, reaching $4 billion in 2007. Fr...[Details]
Recently, news came from the certification department that the photovoltaic grid-connected inverter of Samil New Energy Co., Ltd. (hereinafter referred to as "Samil New Energy") has once again obta...[Details]
With the widespread application of new services and technologies in the communications industry, the scale and capacity of operators' network construction are getting larger and larger, and the ris...[Details]
Embedded System
京公网安备 11010802033920号
EEWORLD
