SECTION
A-A
SECTION
B-B
8
±
0.25
3.2
0.8
1.3
1.8
C
NOTES
材料及び仕上げ(めっき仕様)：TABLE 1 参照
MATERIAL AND FINISHES : SEE TABLE 1
2. 適合ハウジング：51163シリーズ
APPLY MATE HOUSING：51163 SERIES
3. 適合リテーナー：51164シリーズ
APPLY MATE RETAINER：51164 SERIES
4. 圧着仕様書：507520000-CS PS 000
CRIMP SPECIFICATION:507520000-CS PS 000
1
B
A
2.45
C
B
B
A
B
2.4
2.48
1.3
1.42
2.9
2.51
1.9
2.05
1
Φ1.28-1.42mm
Φ1.5-1.8mm
AWG#24-26
AWG#20-22
リール
REEL
リール
REEL
507528400
507528200
連鎖状
CHAIN
連鎖状
CHAIN
TABLE 1
材質
MATERIAL
D
C
B
A
発注番号 端子½状
絶縁被覆外径範囲 適用電線範囲
梱包½態
INS. RANGE
WIRE RANGE PACKAGING
ORDER No.
FORM
SCALE
部品
PART
THIS DRAWING CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX ELECTRONIC TECHNOLOGIES, LLC AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION
DIMENSION UNITS
CURRENT REV DESC:
mm
ANGULAR TOL
±
±
±
±
±
±
NTS
3.0 °
A
りん青銅
PHOSPHOR BRONZE
ターミナル
錫めっき：0.9 MICRO METER MINIMUM
TERMINAL
MATTE TIN
リフロー処理(前めっき)
REFLOW TREATMENT (PRE-PLATING)
DOCUMENT STATUS
FORMAT: master-tb-prod-A3
REVISION: H
DATE: 2018/01/18
GENERAL TOLERANCES
(UNLESS SPECIFIED)
EC NO:
606178
4 PLACES
3 PLACES
2 PLACES
1 PLACE
0 PLACES
0.2
0.2
0.2
0.2
0.2
DRWN:
RWATANABE01
CHK'D: KOMURAKAMI
APPR:
TKANEKO
INITIAL REVISION:
DRWN:
RWATANABE01
APPR:
TKANEKO
THIRD ANGLE PROJECTION
DRAWING
2018/09/25
2018/10/22
2018/10/23
2018/03/14
2018/09/10
SERIES
MINI-LOCK 2.5 W/B
TERMINAL
A
PRODUCT CUSTOMER DRAWING
DOCUMENT NUMBER
DOC TYPE
DOC PART
REVISION
507520000-SD
MATERIAL NUMBER
CUSTOMER
PSD
001
B
P1
RELEASE DATE
2018/10/23
07:17:55
DRAFT WHERE APPLICABLE
MUST REMAIN
WITHIN DIMENSIONS
SHEET NUMBER
A3-SIZE
50752
SEE CHART
GENERAL
1 OF 1
