SPECIFICATION OF FBCA SERIES
FEATURES
Use flat wire in it and could endure higher current
(6Amps).
It is mounted in the boards with surface mounting
equipment.
APPLICATIONS
1. Computer products.
(Mother board , Hard Disk , TV card..Etc.)
2. Communication products.
(like : PAGER , Cordless Phone..Etc.)
3. Modem , OA products , power supplier..Etc.
4. Countermeasures for complying with CE、
FCC、VDE or VCCl radialiated emissions.
ORDERING CODE
(1) PRODUCT TYPE CODE
(2) MATERIAL CODE
(3) SIZE CODE
(4) DESIGN CODE
(5) TAPING
SHAPE & DIMENSIONS
RDC
ORDERING CODE
FBCA-K5B-302340-L1-T
FBCA-A78-302385-L-T
FBCA-A78-302540-L-T
FBCA-K5B-302540-L1-T
FBCA-A78-302585-L-T
FBCA-78-302585-L1-T
FBCA-A78-473078-L-T
A
3.00±0.20
3.00±0.20
3.00±0.20
3.00±0.20
3.00±0.20
3.00±0.30
4.75±0.20
B
1.45±0.10
1.45±0.10
1.45±0.10
1.45±0.10
1.45±0.10
1.50±0.50
1.45±0.10
C
D
4
6
6
4
9
9
9
Z+/-25%(Ω)
(Average)
28
60
30
30
55
58
69
45
96
49
50
101
100
97
UNIT:mm
RATED
CURRENT
(mA)max
9000
6000
6000
9000
6000
13000
6000
(mΩ)max
25MHz
100MHz
4.00±0.30
2.3(+0.0/-0.4)
8.50±0.30
4.00±0.25
4.00±0.25
8.50±0.30
8.50±0.40
7.80±0.30
2.30±0.10
2.55±0.15
2.55±0.15
2.55±0.15
2.50±0.30
3.00±0.15
※All
the data listed in this catalogue are for reference only, King Core reserves the right to alter or revise the specifications without prior notification.
KING CORE ELECTRONICS INC.
Tel:886-3-4698855
Fax:886-3-4691395
No.269,Nanfong Rd.,Pingjhen City,Taoyuan County, Taiwan
E-mail:kc@mail.kingcore.com.tw
Web Site:http://www.kingcore.com.tw
1
FBCA.A01
WOUND CHIP BEADS
→
FBCA SERIES
FBCA-K5B-302340-L1-T
1000
FBCA-A78-302385-L-T
1000
FBCA-A78-302540-L-T
1000
FBCA-K5B-302540-L1-T
1000
IMPEDANCE
IMPEDANCE
100
100
IMPEDANCE
IMPEDANCE
100
100
10
10
10
10
1
1
10
100 1000
FREQ(MHZ)
1
1
10
100 1000
FREQ(MHZ)
1
1
10
100 1000
FREQ(MHZ)
1
1
10
100 1000
FREQ(MHZ)
FBCA-A78-302585-L-T
1000
FBCA-78-302585-L1-T
1000
FBCA-A78-473078-L-T
1000
IMPEDANCE
100
IMPEDANCE
IMPEDANCE
100
100
10
10
10
1
1
10
100 1000
FREQ(MHZ)
1
1
10
100 1000
FREQ(MHZ)
1
1
10
100 1000
FREQ(MHZ)
※All
the data listed in this catalogue are for reference only, King Core reserves the right to alter or revise the specifications without prior notification.
KING CORE ELECTRONICS INC.
Tel:886-3-4698855
Fax:886-3-4691395
No.269,Nanfong Rd.,Pingjhen City,Taoyuan County, Taiwan
E-mail:kc@mail.kingcore.com.tw
Web Site:http://www.kingcore.com.tw
2
FBCA.A01
