1. PHYSICAL DIMENSIONS
0.945 ± 0.02
REVISION
REV.
B
DESCRIPTION
RoHS Compliancy
DATE
06-01-06
APPROVED
DP
ELECTRICAL CHARACTERISTICS:
1-1.
VOLTAGE RATING...................................115/250VAC
0.84MAX.
1-2.
CURRENT RATING
A. @ 115 VAC..........................................10 A RMS MAX
B. @ 250 VAC.........................................10 A RMS MAX
OPERATING FREQUENCY......................50/60Hz
LEAKAGE CURRENT: EACH LINE TO GROUND
A. @ 115 VAC 60Hz............................0.20 mA MAX
B. @ 250 VAC 50Hz.............................0.40 mA MAX
HIPOT RATING (FOR ONE MINUTE)
A. LINE TO GROUND...........................2250 VDC
B. LINE TO LINE.....................................1450 VDC
MINIMUM INSERTION LOSS IN dB: (AT 50 OHM SYSTEM)
.01
/
/
.05
1
1
.10
2
2
.15
4
4
.50
10
10
1.0
13
15
5.0
28
25
10
35
30
30
40
40
1-3.
1-4.
0.142 ±
0.04
0.02
1.22 ± 0.02
0.862 ± 0.004
1-5.
1.66MAX.
1-6.
FREQ. MHz
2.08MAX.
R0.08MAX.
1.12 ±
0.012
0
PANEL CUTOUT
0.04~0.063
COM. MODE dB
DIF. MODE dB
1-7.
1-8.
OPERATING TEMPERATURE.................-25° TO +85° C
SAFETY:
RoHS COMPLIANT
1.12MAX.
1-9.
2. ELECTRICAL SCHEMATIC
L:
C1:
C2:
R:
0.2mH
0.1uF
2200pF
1MΩ
Dim
range
(mm)
0-1
1-6
6-18
18-50
50-120
120-250
250-500
Tolerance
+/-
(mm)
0.15
0.20
0.30
0.50
0.70
0.90
1.20
CONTROLLED
Qualtek Electronics Corp.
Part Number:
Description:
PPC DIVISION
869-10/008
EMI FILTER
UNIT: in
REV. B
Approved / Date
JJH / 09-24-01
Drawn / Date
B.ZHANG
09-24-01
Checked / Date
09-24-01
