High-current terminal block - UKH 95 BU - 3010136
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
High-current terminal block, nom. voltage: 1000 V, nominal current: 232 A, connection method: Screw
connection, number of connections: 2, number of positions: 1, cross section:25 mm² - 95 mm², AWG: 4 - 3/0,
width: 25 mm, height: 90 mm, color: blue, mounting type: NS 35/15, NS 32, NS 35/15-2,3
Your advantages
Reliable cable connection is ensured by three-point centering of the conductor in the prismatic sleeve base
Low contact resistance of the contact surface due to ribbing
Screw locking by means of spring-loaded elements in the clamping part
Key Commercial Data
Packing unit
GTIN
GTIN
4017918091866
3 pc
Technical data
General
Note
Number of positions
Number of levels
Number of connections
Potentials
Nominal cross section
Color
Insulating material
Flammability rating according to UL 94
Rated surge voltage
Degree of pollution
Overvoltage category
Insulating material group
Screws with hexagonal socket
1
1
2
1
95 mm²
blue
PA
V0
8 kV
3
III
I
10/28/2018 Page 1 / 6
https://www.phoenixcontact.com/pi/products/3010136
High-current terminal block - UKH 95 BU - 3010136
Technical data
General
Maximum power dissipation for nominal condition
Maximum load current
Nominal current I
N
Nominal voltage U
N
Open side panel
Relative insulation material temperature index (Elec., UL 746 B)
Temperature index of insulation material (DIN EN 60216-1 (VDE
0304-21))
Static insulating material application in cold
Behavior in fire for rail vehicles (DIN 5510-2)
Flame test method (DIN EN 60695-11-10)
Oxygen index (DIN EN ISO 4589-2)
NF F16-101, NF F10-102 Class I
NF F16-101, NF F10-102 Class F
Surface flammability NFPA 130 (ASTM E 162)
Specific optical density of smoke NFPA 130 (ASTM E 662)
Smoke gas toxicity NFPA 130 (SMP 800C)
Calorimetric heat release NFPA 130 (ASTM E 1354)
Fire protection for rail vehicles (DIN EN 45545-2) R22
Fire protection for rail vehicles (DIN EN 45545-2) R23
Fire protection for rail vehicles (DIN EN 45545-2) R24
Fire protection for rail vehicles (DIN EN 45545-2) R26
7.54 W
232 A
232 A
1000 V
No
130 °C
130 °C
-60 °C
Test passed
V0
>32 %
2
2
passed
passed
passed
28 MJ/kg
HL 1 - HL 3
HL 1 - HL 3
HL 1 - HL 3
HL 1 - HL 3
Dimensions
Width
Length
Height
Height NS 35/15
Height NS 32
25 mm
83 mm
90 mm
97.5 mm
95 mm
Connection data
Note
Connection method
Connection in acc. with standard
Note
Conductor cross section solid min.
Conductor cross section solid max.
Conductor cross section AWG min.
Conductor cross section AWG max.
Conductor cross section flexible min.
Conductor cross section flexible max.
Screws with hexagonal socket
Screw connection
IEC 60947-7-1
Note: Product releases, connection cross sections and notes on
connecting aluminum cables can be found in the download area.
25 mm²
95 mm²
4
3/0
35 mm²
95 mm²
10/28/2018 Page 2 / 6
https://www.phoenixcontact.com/pi/products/3010136
High-current terminal block - UKH 95 BU - 3010136
Technical data
Connection data
Min. AWG conductor cross section, flexible
Max. AWG conductor cross section, flexible
Conductor cross section flexible, with ferrule without plastic sleeve min.
Conductor cross section flexible, with ferrule with plastic sleeve min.
Conductor cross section flexible, with ferrule with plastic sleeve max.
Cross section with insertion bridge, solid max.
Cross section with insertion bridge, stranded max.
2 conductors with same cross section, solid min.
2 conductors with same cross section, solid max.
2 conductors with same cross section, stranded min.
2 conductors with same cross section, stranded max.
2 conductors with same cross section, stranded, ferrules without plastic
sleeve, min.
2 conductors with same cross section, stranded, ferrules without plastic
sleeve, max.
Connection in acc. with standard
Conductor cross section solid min.
Conductor cross section solid max.
Conductor cross section AWG min.
Conductor cross section AWG max.
Conductor cross section flexible min.
Conductor cross section flexible max.
Stripping length
Screw thread
Tightening torque, min
Tightening torque max
2
3/0
35 mm²
35 mm²
95 mm²
95 mm²
70 mm²
25 mm²
35 mm²
25 mm²
35 mm²
16 mm²
35 mm²
IEC/EN 60079-7
25 mm²
95 mm²
4
3/0
35 mm²
95 mm²
33 mm
M8
15 Nm
20 Nm
Conductor cross section flexible, with ferrule without plastic sleeve max. 95 mm²
Standards and Regulations
Connection in acc. with standard
Flammability rating according to UL 94
Fire protection for rail vehicles (DIN EN 45545-2) R22
Fire protection for rail vehicles (DIN EN 45545-2) R23
Fire protection for rail vehicles (DIN EN 45545-2) R24
Fire protection for rail vehicles (DIN EN 45545-2) R26
CSA
IEC 60947-7-1
V0
HL 1 - HL 3
HL 1 - HL 3
HL 1 - HL 3
HL 1 - HL 3
Environmental Product Compliance
China RoHS
Environmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values
Drawings
10/28/2018 Page 3 / 6
https://www.phoenixcontact.com/pi/products/3010136
High-current terminal block - UKH 95 BU - 3010136
Circuit diagram
Dimensional drawing
11
15
Schematic diagram
90°
Connecting aluminum cables. Further notes can be found in the download area
Approvals
Approvals
Approvals
DNV GL / PRS / CSA / PRS / UL Recognized / KEMA-KEUR / cUL Recognized / EAC / cULus Recognized
Ex Approvals
IECEx / ATEX / UL Recognized / cUL Recognized / EAC Ex / cULus Recognized
Approval details
DNV GL
http://exchange.dnv.com/tari/
TAE00001CT
PRS
http://www.prs.pl/
15
TE/2156/880590/17
10/28/2018 Page 4 / 6
https://www.phoenixcontact.com/pi/products/3010136
High-current terminal block - UKH 95 BU - 3010136
Approvals
CSA
Nominal voltage UN
Nominal current IN
mm²/AWG/kcmil
B
600 V
200 A
2
http://www.csagroup.org/services-industries/product-listing/
C
600 V
200 A
2
13631
PRS
B
600 V
230 A
2
http://www.prs.pl/
TE/1824/880590/09
UL Recognized
Nominal voltage UN
Nominal current IN
mm²/AWG/kcmil
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm
C
600 V
230 A
2
FILE E 60425
KEMA-KEUR
Nominal voltage UN
mm²/AWG/kcmil
http://www.dekra-certification.com
1000 V
95
2183460.01
cUL Recognized
Nominal voltage UN
Nominal current IN
mm²/AWG/kcmil
B
2
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm
C
600 V
230 A
2
FILE E 60425
600 V
230 A
EAC
EAC-Zulassung
10/28/2018 Page 5 / 6
