F235-24-T3: DescriptionHCMOS Output Clock Oscillator, 24MHz Nom,; CategoryPassive components oscillator; File Size110KB，2 Pages; ManufacturerFOX [Fox Electronics]; Environmental Compliance

Download Datasheet Parametric View All

F235-24-T3 Overview

HCMOS Output Clock Oscillator, 24MHz Nom,

F235-24-T3 Parametric

Parameter Name	Attribute value
JESD-609 code	e4
surface mount	YES
Terminal surface	Gold (Au)
Installation features	SURFACE MOUNT
Maximum operating temperature	70 °C
Minimum operating temperature	-20 °C
physical size	2.6mm x 2.1mm x 1.0mm
Is it Rohs certified?	Yes
Objectid	8349904882
Reach Compliance Code	Compliant
Is Samacsys	N
YTEOL	0
maximum symmetry	55/45 %
Other features	STANDBY; ENABLE/DISABLE FUNCTION; TR, 7 INCH
maximum descent time	10 ns
Frequency Adjustment - Mechanical	NO
longest rise time	10 ns
Maximum supply voltage	3.465 V
Minimum supply voltage	3.135 V
frequency stability	50%
Nominal operating frequency	24 MHz
Oscillator type	HCMOS
Output load	15 pF
Nominal supply voltage	3.3 V

Preview

Download Datasheet

View All

HCMOS 2.5x2mm 3.3V Oscillator

Model: F230 SERIES

Page 1 of 2

RoHS Compliant / Pb Free

Rev. 12/2/2010

http://www.foxonline.com/need_a_sample.htm

FEATURES

• 3.3V Operation

• Standby Function

• Tape and Reel

(3,000 pcs. STD)

• PART nUMbER SELECTIOn

Learn More - Internet Required

Part Number

781-Frequency-xxxxx

781R-Frequency-xxxxx

782-Frequency-xxxxx

782R-Frequency-xxxxx

783-Frequency-xxxxx

Model Frequency

Operating

Number Stability

Temperature (ºC)

±100PPM

-20 ~ +70

F230

-40 ~ +85

F230R

±100PPM

±50PPM

-20 ~ +70

F235

±50PPM

-40 ~ +85

F235R

±25PPM

-20 ~ +70

F236

Frequency

Range (MHz)

0.750 ~ 50.000

2.6 Ma x

T op

V ie w

Dot de note s

p in 1 .

2.1 m a x

• ELECTRICAL CHARACTERISTICS

PARAMETERS

Frequency Range (F

)

Storage Temperature Range (T

stg

)

Supply Voltage

)

Input Current

)

0.750 ~ 19.999 MHz

19.999+ ~ 39.999 MHz

39.999+ ~ 50.000 MHz

Output Symmetry (50% V

)

Rise Time (10% ~ 90% V

) (T

)

Fall Time (90% ~ 10% V

) (T

)

Output Voltage

)

Output Current

)

Output Load

(HCMOS)

Standby Current

Start-up Time

)

Output Disable Time

Output Enable Time

Aging

(Ta=25ºC: per year)

Reflow Soldering Temp

Moisture Sensitivity Level (MSL)

Termination Finish

MAX

(unless otherwise noted)

0.750 ~ 50.000 MHz

-55ºC ~ +100ºC

3.3V ± 5%

7mA

13mA

19mA

45% ~ 55%

10nS

10% V

90% V

Min

5mA Min

-5mA Min

15pF

5µA

10mS

150nS

10mS

± 5 PPM

260ºC / 10 Seconds

1.0 Ma x

0.78

B ottom

V ie w

0.68

0.65

0.95

R e c om m e nde d

S o ld e r P a d L a y o u t

0.95

0.8

0.65

0.9

Inclusive of 25ºC tolerance, operating temperature range, input voltage change, load change, shock,

and vibration.

An internal pullup resistor from pin 1 to pin 4 allows active output if pin 1 is left open.

Note: A 0.01µF capacitor should be placed between V

(Pin 4) and GND (Pin2) to minimize

power supply noise. All specifications subject to change without notice.

Drawing is for reference to critical specifications defined by size measurements.

Certain non-critical visual attributes, such as side castellations, reference pin shape, etc. may

vary. All specifications subject to change without notice.

All dimensions are in millimeters.

P in C o n n e c t io n s

# 1 E /D

#2 GND

# 3 O u t pu t

# 4 V

• EnAbLE / DISAbLE FUnCTIOn

INH (Pin 1)

OUTPUT (Pin 3)

OPEN

ACTIVE

'1' Level V

≥

80% V

ACTIVE

'0' Level V

≤

20% V

High Z

FOXElectronics

5570 Enterprise Parkway Fort Myers, Florida 33905 USA +1.239.693.0099 FAX +1.239.693.1554

www.foxonline.com

EMEA

Tel: +44.11283.568153 |

Asia

Hong Kong Tel: +852.2854.4285 Fax +852.2854.4282

Japan

Tel: +81.3.3374/2079 Fax: +81.3.3374.5221
