6
5
4
3
b
2
1
FILTER
TYPE 1
TYPE 2
TYPE 3
D
CAPACITANCE
180pF±20%
370pF±20%
830pF±20%
Part-no.
243
o
11730X
243
o
11770X
243
o
11810X
8,26
+0,22
- 0,03
39,22
+ 0,3
- 0,46
33,3
+ 0,15
- 0,1
24,74
+ 0,05
- 0,2
13,2
`
0,1
10°
6,13
+ 0,17
- 0,08
7,1
6
+ 0,18
-
0,12
(5:1)
D
8
+ 0,02
- 0,23
C
C
M3
b
243
o
11___X
CONEC ABC
M3
SEE NOTE 8
B
B
25,17
+ 0,2
- 0,05
b
NOTES:
1. METALSHELLS: STEEL; min. 315µin TIN over 40-80µin NICKEL
2. INSULATOR: PBT GF UL 94 V-0; BLACK
3. CONTACTS: COPPER ALLOY; PLATING (SEE PART NO):
o
PLEASE ADD A for GOLD FLASH over NICKEL (PREFERRED TYPE)
o
PLEASE ADD B for 20µin HARD GOLD over min. 50µin NICKEL
o
PLEASE ADD C for 30µin HARD GOLD over min. 50µin NICKEL
4. THREADED INSERTS: COPPER ALLOY; min 200µin TIN over 80µin NICKEL
5. JACK SCREWS: COPPER ALLOY; NICKEL PLATED
6. DIELECTRIC WITHSTANDING VOLTAGE: 300 VDC
7. MAXIMUM TORQUE VALUE FOR THREAD: 6 in.LB
8. CONNECTOR IS PART MARKED: 243
o
11___X CONEC ABC (see note 3 / see table)
THIS DRAWING MAY NOT BE COPIED OR
REPRODUCED IN ANY WAY, AND MAY NOT
BE PASSED ON TO A THIRD PARTY WITHOUT
WRITTEN PERMISSION.
OWNERSHIP AND COPYRIGHT OF CONEC GmbH
DO NOT ALTER CAD DRAWING BY HAND
tolerance
dim. in mm
date
drawn
appd.
norm
d-old
scale:
material:
name
2:1 (5:1)
see notes
A
A
title:
28.01.97
28.01.97
Barcinski
Mickenbecker
D-SUB HD C-FILTER ADAPTER
26pos. SOCKET / PLUG
dwg no:
R
24K1IP8A
4xb
a
Ä5639
Original
05.05.2015 K.H.
RoHS compliant
6
5
24K1A1587
part no:
b
DIN-
A3
sh:
1
rev. description
4
date
name
3
SEE TABLE
1
2
Robotics Development
