in a series of DOSA compliant, digitally controlled
DC-DC converters that are based on a 32-bit ARM
processor. The DSQ series provides a fully regu-
lated, digitally controlled DC output in a ¼-brick
format that will support the DOSA industry standard
footprint for isolated board mounted power mod-
ules. The DSQ series supports advances in power
conversion technology including a digital interface
supporting the PMBus protocol for communications
to power modules. The DSQ0150V2 is an isolated,
regulated, 600W-12Vout quarter brick that sup-
ports the TNV input voltage range of 36V–75V with
a typical efficiency of 96%. The DSQ series also
incorporates a “droop” load sharing option that
allows connecting two or more units together in
parallel for demanding power-hungry applications
or to provide redundancy in high reliability applica-
tions. The converter also offers high input to output
isolation of 2250 VDC as required for Power over
Ethernet (PoE) applications. The DSQ series is suit-
able for applications covering MicroTCA, servers
and storage applications, networking equipment,
Telecommunications equipment, Power over Ether-
net (PoE), fan trays, wireless networks, wireless pre-
amplifiers, and industrial and test equipment, along
with other applications requiring a regulated 12V.
DSQ
Applications
Distributed Power Architectures
Intermediate Bus Voltage Applications
Networking Equipment including POE applications
Servers & Storage Applications
Tray assemblies along with other applica-
Fan
tions requiring a regulated Voltage source
DAQ
DCQ
For full details go to
www.murata-ps.com/rohs
www.murata-ps.com/support
SDC_DSQ_DAQ_DCQ0150V2.A01
Page 1 of 19
DSQ/DAQ/DCQ Series
600W Quarter Brick
DOSA Digital PMBus Interface
PERFORMANCE SPECIFICATIONS SUMMARY AND ORDERING GUIDE [1]
Output
Regulation
(Typ.)
Line
Load
(mV)
(mV)
75
75
75
45
45
45
Input
Efficiency
V
in
(V, Nom.)
48
48
48
Root Model
DSQ0150V2
DAQ0150V2
DCQ0150V2
V
out
(V)
12
12
12
I
OUT
(A, max.)
50
50
50
Total Power
(W)
600
600
600
Ripple & Noise
(mVp-p)
120
120
120
Range
(V)
36-75
36-75
36-75
I
in
, full load@Vinmin
(A)
17.5
17.5
17.5
Typ.
96.00%
96.00%
96.00%
Notes:
[1] Typical at TA = +25°C under nominal line voltage and full-load conditions. All models are specified with an external 1μF multi-layer ceramic and 10μF capacitors across their
output pins.
Part Number Structurer
Product Family[1]
Form Factor
Vout
Output Current
Vin Range
Logic
Pin Length[2]
Mechanical Configuration
Load Sharing
Reflow Compliant[2]
Specific Customer Configuration
RoHS 6/6
D
S
Q
01
50
V2
N
X
B
S
R
X
X
X
DS = DOSA Standard Digital Quarter Brick W/Sense & Trim, W/PMbus
DA = DOSA Analog Quarter Brick W/Sense & Trim, No PMbus
DC = DOSA Analog Quarter Brick ( 5 pin IBC )
Q = Quarter Brick
01 = 12Vout , 02 = 5Vout , 03 = 3.3Vout
Max Iout in Amps
V2 = 36-75Vin
N = Negative Logic, P = Positive Logic
1 = 0.110"(2.79 mm), 2 = 0.145"(3.68mm), Omit for standard pin length( shown
in the mechanical drawings)
B = Baseplate
S = Load Sharing, Omit for standard
R = MSL-3 Compliant Packaging, Omit for Standard through hole processing
Customer Code, Omit for Standard
C RoHS 6/6 Compliant
Example Part Number DSQ0150V2N2BRSC DOSA Digital Quarter Brick, 12Vout@50A, Negative logic, 0.145” pin length, Baseplate, Reflow/MSL-3 compliant, Load Sharing, RoHS 6/6.
[1] Load Sharing on DSQ ( with PMbus ) will not include Sense & Trim pins. Loading Sharing is not available on DAQ.
[2] Minimum order quantity is required. Samples available with standard pin length only.
www.murata-ps.com/support
SDC_DSQ_DAQ_DCQ0150V2.A01
Page 2 of 19
DSQ/DAQ/DCQ Series
FUNCTIONAL SPECIFICATIONS
ABSOLUTE MAXIMUM RATINGS
Conditions [1]
Minimum
600W Quarter Brick
DOSA Digital PMBus Interface
Typical/Nominal
Maximum
Units
Input Voltage, Continuous
0
75
Vdc
Input Voltage, Transient
100 mS max. duration
100
Vdc
Isolation Voltage
Input to output
2250
Vdc
On/Off Remote Control
Power on, referred to -Vin
0
13.5
Vdc
Output Power
0
612
W
Output Current
Current-limited, no damage, short-circuit protected
0
50
A
Storage Temperature Range
Vin = Zero (no power)
-55
125
°C
Absolute maximums are stress ratings. Exposure of devices to greater than any of these conditions may adversely affect long-term reliability. Proper operation under conditions other than those
listed in the Performance/Functional Specifications Table is not implied nor recommended.
General Conditions for Device under Test unless otherwise specified:
Typical at TA = +25°C under nominal line voltage and nominal load conditions. All models are specified with an external 220μF input capacitor and 1μF & 10μf capacitors across their output pins.
INPUT
Operating voltage range (V2)
Start-up threshold
Undervoltage shutdown
Internal Filter Type
External Input fuse
Input current
Full Load Conditions
Low Line input current
Inrush Transient
Short Circuit input current
No Load input current
Shut-Down input currrent (Off, UV, OT)
Back Ripple Current
(Default, configurable via PMBus)
(Default, configurable via PMBus)
36
32
30
48
34
32
Pi
30
13.00
17.50
0.7
0.1
80
750
94.5
96
2250
1500
1500
Functional
10
1500
Certified to UL-60950-1, CSA-C22.2 No.60950-1,
IEC/EN60950-1, 2nd edition (pending)
Per Telcordia SR-332, Issue 3, Method 1, Class 1,
Ground Fixed, Tcase=+25°C
Yes
5000
Hours x
10
3
75
36
34
Vdc
Vdc
Vdc
A
13.50
18.00
1
0.2
110
30
1500
A
A
A
2
-Sec.
A
mA
mA
mAp-p
%
Vdc
Vdc
Vdc
MΩ
pF
Vin = nominal
Vin = minimum
Vin = 48V.
Vin = 48V, Iout = 0, unit=ON
No filtering
Vin = 48V, full load
Input to output
Input to Baseplate
Output to Baseplate
GENERAL and SAFETY
Efficiency
Isolation Voltage
Insulation Safety Rating
Isolation Resistance
Isolation Capacitance
Safety
Calculated MTBF
DYNAMIC CHARACTERISTICS
Switching Frequency (Configurable via PMBus)
Fixed Frequency Control
Variable Frequency Control (Default)
Turn On Time (Default, Configurable via PMBus)
Vin On to Vout Regulated
Remote On to Vout Regulated
Vout Rise Time (Default, Configurable via PMBus)
From 10%~90%
Vout Fall Time of Regulated Off (Default, Configurable via PMBus)
From 90%~10%
Dynamic Load Response
Dynamic Load Peak Deviation
Dynamic Load Response
Dynamic Load Peak Deviation
50-75-50%, 0.1A/us,within 1% of Vout (Vin=Vinnom, tested with a 1.0 μF
ceramic, 10 μF tantalum and 330μF low ESR polymer capacitor across the load.)
50-75-50%, 1A/us,within 1% of Vout (Vin=Vinnom, tested with a 1.0 μF
ceramic, 10 μF tantalum and 330μF low ESR polymer capacitor across the load.)
180
N/A
40
50
8
30
N/A
200
±250
300
±500
300
±350
750
±750
KHz
KHz
mS
mS
mS
mS
µSec
mV
µSec
mV
FEATURES and OPTIONS
Remote On/Off Control
Primary On/Off control (designed to be driving with an open collector logic, Voltages referenced to -Vin)
“P” Suffix:
Positive Logic, ON State
ON = pin open or external voltage
Positive Logic, OFF State
OFF = ground pin or external voltage
Control Current
Open collector / drain
“N” Suffix:
Negative Logic, ON state
ON = ground pin or external voltage
Negative Logic, OFF state
OFF = pin open or external voltage
Control Current
Open collector / drain
Remote Sense Compliance
Sense pins connected externally to respective Vout pins
90% of Vnom., after warmup, Configurable via PMBus
(Need check the OCP Inception of Vout is whether reasonable)
Hiccup technique, autorecovery within 1% of Vout
Output shorted to ground, no damage
Hiccup current limiting
Vin = 36-75, Vout = nom., full load
Iout = min. to max., Vin = nom.
|Vout @ min_load - Vout @ max_load|
5Hz-20MHz BW, Cout = 1µF
Vin=nom and Io=min to max, tested with a 1.0μF ceramic, 10 μF tantalum
and 330μF low ESR polymer capacitors across the load
At all outputs
Low ESR
330
-3
-2
-2
-5
L*W*H
56
50
65
1
75
45
120
0.01
150
0.02
10,000
3
2
2
5
2.3 x 1.45 x 0.52
58.4 x 36.80 x 13.21
2.35
66.8
0.04 & 0.062
1.016 & 1.575
0.02
0.5
Copper alloy
98.4-299
4.7-19.6
-40
-40
-55
128
B
RoHS-6
85
110
125
mV
mV
mV pk-pk
% of
Vnom./°C
μF
%
%
A
°C
Inches
mm
Ounces
Grams
Inches
mm
MECHANICAL
Outline Dimensions (with baseplate)
Weight (with baseplate)
Through Hole Pin Diameter
Digital Interface Pin Diameter
Through Hole Pin Material
TH Pin Plating Metal and Thickness
Nickel subplate
Gold overplate
With derating
Vin = Zero (no power)
Baseplate temperature measured in the center
External filter required; see emissions performance test.
µ-inches
µ-inches
°C
°C
°C
°C
Class
ENVIRONMENTAL
Operating Ambient Temperature Range
Operating Baseplate Temperature
Storage Temperature
Thermal Protection/Shutdown
(with "B" Suffix, default value, Con-
figurable via PMBus)
Electromagnetic Interference
Conducted, EN55022/CISPR22
RoHS Rating
Notes:
[1] Typical at TA=+25°C under nominal line voltage and full-load conditions. All models are specified with an external 1μF multi-layer ceramic and 10μF capacitors across their output pins.
[2] Over-current protection is non-latching with auto recovery (Hiccup).
[3] Regulation specifi cations describe the output voltage changes as the line voltage or load current is varied from its nominal or midpoint value to either extreme.
