MIL-DTL-38999, Series III TV
Receptacle Protection Cap
Amphenol
Aerospace
III
Series III TV
38999
II
I
SJT
A
.797 MAX
20.24 MAX
Matrix 2
26482
B
.578 MAX
14.68 MAX
A
.167 +.010
–.005
4.24 +.25
–.13
6.000 APPROX
152.40 APPROX
Matrix Pyle
83723 III
*10-552943-XXX
B
Crimp Rear
Release Matrix
*10-553310-XXX
A
.797 MAX
20.24 MAX
D
5015
*10-553970-XXX
B
6.000 APPROX
152.40 APPROX
Printed
26500 Pyle
Circuit Board
*10-553120-XXX
3.500 APPROX
88.90 APPROX
* To complete order number, add shell size and suffix number.
For example, shell size 11 with olive drab cadmium nickel
base, 10-552943-119
Inches
Shell
Size
9
11
13
15
17
19
21
23
25
A Thread Class 2B
0.1P-0.3L-TS
.6250
.7500
.8750
1.0000
1.1875
1.2500
1.3750
1.5000
1.6250
B Dia. Max.
.875
1.000
1.125
1.250
1.438
1.500
1.625
1.750
1.875
D Dia.
+.010
–.000
.703
.844
1.016
1.141
1.266
1.391
1.516
1.641
1.766
Millimeters
EMI Filter
Transient
Fiber Optics
Finish
Olive Drab, Cadmium,
Nickel base
Electroless Nickel
10-No Suffix
-XX9
-XXG
Consult Amphenol Aerospace for availability
of stainless steel protection caps.
All dimensions for reference only.
For MS protection caps, see page 95.
Shell
Size
9
11
13
15
17
19
21
23
25
MS Shell Size Code
A
B
C
D
E
F
G
H
J
B Dia. Max.
22.23
25.40
28.58
31.75
36.53
38.10
41.28
44.45
47.63
D Dia. +.25
–.00
High Speed
Contacts
17.86
21.44
25.81
28.98
32.16
35.33
38.51
41.68
44.86
Options
Others
91
