0603X475M250GT-B: DescriptionCeramic Capacitor, Multilayer, Ceramic, 25V, 20% +Tol, 20% -Tol, X7R, 15% TC, 4.7uF, Surface Mount, 0603, CHIP, ROHS COMPLIANT; CategoryPassive components capacitor; File Size87KB，1 Pages; ManufacturerCapax Technologies Inc; Websitehttp://www.capaxtechnologies.com/; Environmental Compliance

Download Datasheet Parametric View All

0603X475M250GT-B Overview

Ceramic Capacitor, Multilayer, Ceramic, 25V, 20% +Tol, 20% -Tol, X7R, 15% TC, 4.7uF, Surface Mount, 0603, CHIP, ROHS COMPLIANT

0603X475M250GT-B Parametric

Parameter Name	Attribute value
high	0.838 mm
length	1.524 mm
width	0.762 mm
JESD-609 code	e4
Terminal surface	Gold (Au) - with Nickel (Ni) barrier
Terminal shape	WRAPAROUND
Number of terminals	2
Package shape	RECTANGULAR PACKAGE
Package form	SMT
method of packing	TR, EMBOSSED, 7 INCH
surface mount	YES
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Temperature Coefficient	15% ppm/°C
Is it lead-free?	Yes
Is it Rohs certified?	Yes
package instruction	, 0603
Reach Compliance Code	Compliant
ECCN code	EAR99
YTEOL	7
Objectid	1325862552
Country Of Origin	USA
Is Samacsys	N
capacitance	4.7 µF
Capacitor type	CERAMIC CAPACITOR
positive tolerance	20%
size code	0603
dielectric materials	CERAMIC
Installation features	SURFACE MOUNT
multi-layer	Yes
negative tolerance	20%
Rated (DC) voltage (URdc)	25 V
Temperature characteristic code	X7R

Preview

Download Datasheet

View All

Surface Mount Capacitors:

0603 - X7R ( HX)

0603 SMT Capacitors feature:

•

0603 Case Size

•

High Voltage-Extended Range

•

Low ESR

•

X7R High Density Dielectric Materials

Mechanical Dimensions

Length (L): .060” ± .005”

Width (W): .030” ± .005”

Thickness (T): .033” max

Bandwidth (bw): .010” ± .005”

Capacitance Value

Value (pF)

100

150

220

330

470

680

820

1000

1500

1800

2200

2700

3300

3900

4700

5600

6800

8200

10,000 (.01μF)

15,000 (.015μF)

18,000 (.018μF)

Cap. Code

101

151

221

331

471

681

821

102

152

182

222

272

332

392

472

562

682

822

103

153

183

Max Voltage

250 VDC

Dielectric

X7R

Value (pF)

22,000 (.022μF)

27,000 (.027μF)

33,000 (.033μF)

39,000 (.039μF)

47,000 (.047μF)

56,000 (.056μF)

68,000 (.068μF)

100,000 (.10μF)

120,000 (.12μF)

150,000 (.15μF)

180,000 (.18μF)

220,000 (.22μF)

270,000 (.27μF)

330,000 (.33μF)

470,000 (.47μF)

560,000 (.56μF)

1,000,000 (1μF)

2,200,000 (2.2μF)

4,700,000 (4.7μF)

10μF

22μF

Cap. Code

223

273

333

393

473

563

683

104

124

154

184

224

274

334

474

564

105

225

475

106

226

Max Voltage

150 VDC

Dielectric

X7R

100 VDC

X7R

200 VDC

X7R

50 VDC

X7R

35 VDC

25 VDC

16 VDC

X7R

X7R,X7R

X5R,X7R

150 VDC

X7R

** For Additional Capacitance Values and Working Voltages, Please Contact the Factory **

O

Case Size

Dielectric

Capacitance

Tolerance

I

Voltage

Termination

Packaging

Hi-Reli Testing

0603

Mechanical

Dimensions

Shown

Above

X

X = X7R

B=X5R

103

First 2 digits are

Significant; Third

digit indicates #

of Zeros. Use “R”

for decimal point

Examples:

201 = 200pF

2R2 = 2.2pF

K

J ±5%

K ±10%

M ±20%

301

First 2 digits are

Significant; Third

digit indicates

number of Zeros

Examples:

201 = 200V

151 = 150V

202 = 2000V

SN

S Solder Plated

Over Nickel

SN Tin over

Nickel Plated

T

T = Tape and

Reel

W = Waffle Pack

- A

(Optional)

A = Group A

B = Group B

C = Group C

Tested and

Screened

(RoHS Compliant)

G Gold over

Nickel Plated

(RoHS Compliant)

P

Palladium-

Silver

CAPAX TECHNOLOGIES, INC

º

24842 AVE TIBBITTS

º

VALENCIA, CA

º

91355

º

661.257.7666

º

FAX: 661.257.4819

WWW.CAPAXTECHNOLOGIES.COM

REV. “S”
