0805X393J201SW-A: DescriptionCeramic Capacitor, Multilayer, Ceramic, 200V, 5% +Tol, 5% -Tol, X7R, 15% TC, 0.039uF, Surface Mount, 0805, CHIP; CategoryPassive components capacitor; File Size179KB，1 Pages; ManufacturerCapax Technologies Inc; Websitehttp://www.capaxtechnologies.com/

Download Datasheet Parametric View All

0805X393J201SW-A Overview

Ceramic Capacitor, Multilayer, Ceramic, 200V, 5% +Tol, 5% -Tol, X7R, 15% TC, 0.039uF, Surface Mount, 0805, CHIP

0805X393J201SW-A Parametric

Parameter Name	Attribute value
Is Samacsys	N
package instruction	, 0805
Country Of Origin	USA
ECCN code	EAR99
Objectid	1325867304
Reach Compliance Code	Compliant
YTEOL	5
Rated (DC) voltage (URdc)	200 V
Temperature characteristic code	X7R
capacitance	0.039 µF
Installation features	SURFACE MOUNT
multi-layer	Yes
negative tolerance	5%
positive tolerance	5%
size code	0805
Capacitor type	CERAMIC CAPACITOR
dielectric materials	CERAMIC
high	1.143 mm
length	2.0828 mm
width	1.3208 mm
JESD-609 code	e0
Package form	SMT
method of packing	WAFFLE PACK
surface mount	YES
Terminal surface	Tin/Lead (Sn/Pb) - with Nickel (Ni) barrier
Terminal shape	WRAPAROUND
Number of terminals	2
Package shape	RECTANGULAR PACKAGE
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Temperature Coefficient	15% ppm/°C
Is it Rohs certified?	No
Is it lead-free?	No

Preview

Download Datasheet

View All

Surface Mount Capacitors:

0805 - X7R/ X5R, High Voltage

0805 SMT Capacitors feature:

•

0805 Case Size

•

High Voltage

•

High Capacitance

Mechanical Dimensions

Length (L):

.082”

±

.005”

Width (W):

.052”

±

.005”

Thickness (T):

.0450”

±

.010”

Bandwidth (bw):

.015”

Max.

Capacitance Value

Value (pF)

100

150

220

330

470

680

820

1000

1500

1800

2200

2700

3300

3900

4700

5600

6800

8200

10,000 (.01μF)

15,000 (.015μF)

18,000 (.018μF)

Cap. Code

101

151

221

331

471

681

821

102

152

182

222

272

332

392

472

562

682

822

103

153

183

Max Voltage

1000 VDC

Dielectric

X7R

Value (pF)

22,000 (.022μF)

39,000 (.039μF)

47,000 (.047μF)

56,000 (.056μF)

68,000 (.068μF)

82,000 (.082μF)

100,000 (.10μF)

150,000 (.15μF)

220,000 (.22μF)

330,000 (.33μF)

470,000 (.47μF)

680,000 (.68μF)

1,000,000 (1μF)

1,500,000 (1.5μF)

2,200,000 (2.2μF)

4,700,000 (4.7μF)

10μF

22μF

33μF

47μF

100μF

Cap. Code

223

393

473

563

683

823

104

154

224

334

474

684

105

155

225

475

106

226

336

476

107

Max Voltage

250 VDC

200 VDC

Dielectric

X7R

100 VDC

X7R

X7R, X5R

500 VDC

X7R

63 VDC

X7R, X5R

50 VDC

35 VDC

16 VDC

16VDC

6R3

X7R, X5R

X7R,X5R

X5R

300 VDC

250 VDC

X7R

** For Additional Capacitance Values and Working Voltages, Please Contact the Factory **

Ordering Information

Case Size

Dielectric

Capacitance

Tolerance

Voltage

Termination

Packaging

Hi-Reli Testing

0805

Mechanical

Dimensions

Shown

Above

X

X = X7R

B = X5R

103

First 2 digits are

Significant; Third

digit indicates #

of Zeros. Use

“R”

for decimal point

Examples:

201 = 200pF

2R2 = 2.2pF

K

G ±2%

J ±5%

K ±10%

M ±20%

501

SN

T

T = Tape and

Reel

W = Waffle Pack

-

A

(Optional)

A = Group A

B = Group B

C = Group C

Tested and

Screened

First 2 digits are

S Solder

Significant; Third

(90Sn/10Pb)

digit indicates

Plated

number of Zeros

Over Nickel

Examples:

SN Tin over

201 = 200V

Nickel Plated

(RoHS Compliant)

151 = 150V

202 = 2000V

G Gold over

Nickel Plated

(RoHS Compliant)

Capax Technologies, Inc

º

24842 Ave Tibbitts

º

Valencia, Ca

º

91355

º

661.257.7666

º

Fax: 661.257.4819

www.CapaxTechnologies.Com
