PSEP1200U SERIES
100~200 Watts
AC/DC Open Frame Power Supplies
Single, Dual, Triple, Quad Outputs
FEATURES
•
•
•
•
Wide Input Voltage Range of 90-264VAC
High Minimum Efficiency of 85%
RoHS Compliant
Over Voltage, Over Current and Short Circuit
Protection
•
•
•
•
100% Burn-In
100% Hi-Pot Tested
Single, Dual, Triple, and Quad Outputs
UL/CUL, CB, CE, and FCC Safety
Approvals
DESCRIPTION
Size: 5in x 3.21in x 1.77in
(127mm x 81.5mm x 45.5mm)
The PSEP1200U series of AC DC open frame power supplies offers up to 200 watts of output
power in a 5” x 3.21” x 1.77” package. This series has a wide input voltage range of 90~264VAC
and single, dual, triple, and quad outputs are available. The PSEP1200U series has high minimum
efficiency of 85%, is RoHS compliant, and has over voltage, over current, and short circuit
protection. It has UL/CUL, CB, CE, and FCC safety approvals and has been 100% burn-in and hi-
pot tested. Please call factory for details.
MODEL SELECTION TABLE
Single Output Models
Model Number
PSEP11000500U
PSEP11501200U
PSEP11801200U
PSEP11501900U
PSEP11801900U
PSEP12001900U
PSEP11502400U
PSEP11802400U
PSEP12002400U
PSEP11503600U
PSEP11803600U
PSEP12003600U
PSEP11504800U
PSEP11804800U
PSEP12004800U
PSEP11505600U
PSEP11805600U
PSEP12005600U
90-264VAC
Input Voltage Range
Output Voltage
5
12
12
19
19
19
24
24
24
36
36
36
48
48
48
56
56
56
Output Current
20.00A
12.50A
15.00A
7.89A
9.47A
10.53A
6.25A
7.50A
8.33A
4.17A
5.00A
5.56A
3.13A
3.75A
4.17A
2.68A
3.21A
3.57A
Total Output Power
100
150
180
150
180
200
150
180
200
150
180
200
150
180
200
150
180
200
±3% Max.
2% Max.
≥85%
Load Regulation
Ripple & Noise
Efficiency
7/18/2019
Wall Industries, Inc. • Tel: 603-778-2300 • Toll Free: 888-597-9255 •
website:
www.wallindustries.com
• e-mail:
sales@wallindustries.com
Page 1 of 5
Rev C
PSEP1200U SERIES
100~200 Watts
AC/DC Open Frame Power Supplies
Single, Dual, Triple, Quad Outputs
Model Number
PSEP210005A0U
PSEP215012A0U
PSEP218012A0U
PSEP215019A0U
PSEP218019A0U
PSEP15024A0U
PSEP18024A0U
PSEP15036A0U
PSEP18036A0U
PSEP15048A0U
PSEP18048A0U
PSEP215056A0U
PSEP218056A0U
PSEP215012B0U
PSEP218012B0U
PSEP215019B0U
PSEP218019B0U
PSEP215024B0U
PSEP218024B0U
PSEP215036B0U
PSEP218036B0U
PSEP215048B0U
PSEP218048B0U
PSEP215056B0U
PSEP218056B0U
PSEP215012DAU
PSEP218012DAU
PSEP215019DAU
PSEP218019DAU
PSEP215019DBU
PSEP218019DBU
PSEP215024DAU
PSEP218024DAU
PSEP215024DBU
PSEP218024DBU
Input
Voltage
Range
90-
264VAC
Vo1
(V)
5
12
12
19
19
24
24
36
36
48
48
56
56
12
12
19
19
24
24
36
36
48
48
56
56
12
12
19
19
19
19
24
24
24
24
Main Power
Io1
Wo1
(I)
(W)
18.00A
90
11.67A
140
14.17A
170
7.37A
140
8.95A
170
5.83A
140
7.08A
170
3.89A
140
4.72A
170
2.92A
140
3.54A
170
2.50A
140
3.04A
170
12.00A
144
14.50A
174
7.58A
144
9.16A
174
6.00A
144
7.25A
174
4.00A
144
4.83A
174
3.00A
144
3.63A
174
2.57A
144
3.11A
174
10.42A
125
12.92A
155
6.58A
125
8.16A
155
4.74A
90
6.32A
120
5.21A
125
6.46A
155
3.75A
90
5.00A
120
Stand By Power
Vo2
Io2
Wo2
(V)
(I)
(W)
5
2
10
5
2
10
5
2
10
5
2
10
5
2
10
5
2
10
5
2
10
5
2
10
5
2
10
5
2
10
5
2
10
5
2
10
5
2
10
MODEL SELECTION TABLE
Dual Output Models
-12V Power
DC to DC Power
Vo3
Io3 Wo3( Vo4
Io4
Wo4
(V)
(I)
W)
(V)
(I)
(W)
-12
-12
-12
-12
-12
-12
-12
-12
-12
-12
-12
-12
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
6
6
6
6
6
6
6
6
6
6
6
6
5
5
5
5
12
12
5
5
12
12
5
5
5
5
5
5
5
5
5
5
25
25
25
25
25
25
25
25
25
25
Total
Output
Power
100
150
180
150
180
150
180
150
180
150
180
150
180
150
180
150
180
150
180
150
180
150
180
150
180
150
180
150
180
150
180
150
180
150
180
Load
Ripple
Regulation & Noise
Efficiency
±3% or
10% Max.
2%
Max.
≥85%
Model Number
PSEP315012C0U
PSEP317512C0U
PSEP315019C0U
PSEP317519C0U
PSEP315024C0U
PSEP317524C0U
PSEP315036C0U
PSEP317536C0U
PSEP315048C0U
PSEP317548C0U
PSEP315056C0U
PSEP317556C0U
PSEP315012AAU
PSEP317512AAU
PSEP315019AAU
PSEP317519AAU
PSEP315019ABU
PSEP317519ABU
PSEP315024AAU
PSEP317524AAU
PSEP315024ABU
PSEP317524ABU
Input
Voltage
Range
90-
264VAC
Main Power
Vo1
Io1
Wo1
(V)
(I)
(W)
12
11.17A 134
12
13.25A 159
19
7.05A
134
19
8.37A
159
24
5.58A
134
24
6.63A
159
36
3.72A
134
36
4.42A
159
48
2.79A
134
48
3.31A
159
56
2.39A
134
56
2.84A
159
12
9.58A
115
12
11.67A 140
19
6.05A
115
19
7.37A
140
19
4.21A
80
19
5.53A
105
24
4.79A
115
24
5.83A
140
24
3.33A
80
24
4.38A
105
Stand By Power
Vo2
Io2
Wo2
(V)
(I)
(W)
5
2
10
5
2
10
5
2
10
5
2
10
5
2
10
5
2
10
5
2
10
5
2
10
5
2
10
5
2
10
5
2
10
5
2
10
5
2
10
5
2
10
5
2
10
5
2
10
5
2
10
5
2
10
5
2
10
5
2
10
5
2
10
5
2
10
MODEL SELECTION TABLE
Triple Output Models
-12V Power
Vo3
Io3
Wo3
(V)
(I)
(W)
-12
0.5
6
-12
0.5
6
-12
0.5
6
-12
0.5
6
-12
0.5
6
-12
0.5
6
-12
0.5
6
-12
0.5
6
-12
0.5
6
-12
0.5
6
-12
0.5
6
-12
0.5
6
DC to DC Power
Vo4
Io4
Wo4
(V)
(I)
(W)
5
5
5
5
12
12
5
5
12
12
5
5
5
5
5
5
5
5
5
5
25
25
25
25
60
60
25
25
60
60
Total
Output
Power
150
175
150
175
150
175
150
175
150
175
150
175
150
175
150
175
150
175
150
175
150
175
Load
Regulation
Ripple
&
Noise
Efficiency
±3% or
10% Max
.
2%
Max.
≥85%
7/18/2019
Wall Industries, Inc. • Tel: 603-778-2300 • Toll Free: 888-597-9255 •
website:
www.wallindustries.com
• e-mail:
sales@wallindustries.com
Page 2 of 5
Rev C
PSEP1200U SERIES
100~200 Watts
AC/DC Open Frame Power Supplies
Single, Dual, Triple, Quad Outputs
Model Number
PSEP415012CAU
PSEP417512CAU
PSEP415019CAU
PSEP417519CAU
PSEP415019CBU
PSEP417519CBU
PSEP415024CAU
PSEP417524CAU
PSEP415024CBU
PSEP417524CBU
Input
Voltage
Range
90-
264VAC
Main Power
Vo1
Io1
Wo1
(V)
(I)
(W)
12
9.08A
109
12
11.17A 134
19
5.74A
109
19
7.05A
134
19
3.89A
74
19
5.21A
99
24
4.54A
109
24
5.58A
134
24
3.08A
74
24
4.13A
99
Stand By Power
Vo2
Io2
Wo2
(V)
(I)
(W)
5
2
10
5
2
10
5
2
10
5
2
10
5
2
10
5
2
10
5
2
10
5
2
10
5
2
10
5
2
10
MODEL SELECTION TABLE
Quad Output Models
-12V Power
Vo3
Io3
Wo3
(V)
(I)
(W)
-12
0.5
6
-12
0.5
6
-12
0.5
6
-12
0.5
6
-12
0.5
6
-12
0.5
6
-12
0.5
6
-12
0.5
6
-12
0.5
6
-12
0.5
6
DC to DC Power
Vo4
Io4
Wo4
(V)
(I)
(W)
5
5
25
5
5
25
5
5
25
5
5
25
12
5
60
12
5
60
5
5
25
5
5
25
12
5
60
12
5
60
Total
Output
Power
150
175
150
175
150
175
150
175
150
175
Load
Regulation
Ripple
&
Noise
Efficiency
±3% or
10% Max.
2%
Max.
≥85%
SPECIFICATIONS
SPECIFICATION
All specifications are based on 25°C, Nominal Input Voltage, and Maximum Output Current unless otherwise noted.
We reserve the right to change specifications based on technological advances.
INPUT SPECIFICATIONS
Input Voltage Range
Input Current
Inrush Current
OUTPUT SPECIFICATIONS
Output Voltage
TEST CONDITIONS
Min
90
Typ
≤3.0
≤120
Max
264
Unit
VAC
A
A
@220VAC, Cold start @25ºC
Single Output
Dual Output
Main Power
Main Power
Stand By or -12V
Main Power
Stand By Power
DC-DC or -12
Main Power
DC-DC Power
-12V Power
Stand By Power
Load Regulation
Triple Output
Quad Output
Single Output
Dual Output
Triple Output
Quad Output
Output Power
Output Current
Ripple & Noise (20MHz bandwidth)
(1)
Turn On Time
PROTECTION
Short Circuit Protection
Over Current Protection
Over Voltage Protection
ENVIRONMENTAL SPECIFICATIONS
Operating Temperature
Storage Temperature
Storage Humidity
MTBF
GENERAL SPECIFICATIONS
Efficiency
(2)
Efficiency Level
PHYSICAL SPECIFICATIONS
Weight
Dimensions (L x W x H)
SAFETY
Safety Approvals
(1)
100
100
150
150
See Table
±3
±3
±3 or 10
±3
±3
±3 or 10
±3
±3
±10
±3
200
180
170
170
See Table
2
≤3
%
W
%
s
Latch Off or Automatic Recovery
Latch Off or Automatic Recovery
Latch Off or Automatic Recovery
0
-20
5
30,000
≥85
50
85
95
ºC
ºC
%
hours
%
Meets CEC Level V
15.87oz (450g)
5in x 3.21in x 1.77in
(127mm x 81.5mm x 45.5mm)
UL/CUL
(3)
, CB, CE, FCC
Ripple & Noise is measured by using 20MHz bandwidth limited oscilloscope and terminated each output with a 0.1uF ceramic capacitor & parallel
with 47uF aluminum capacitor at full load and nominal line.
(2) Efficiency depends on models.
(3) This product is Listed to applicable standards and requirements by UL.
*Due to advances in technology, specifications subject to change without notice.
7/18/2019
Wall Industries, Inc. • Tel: 603-778-2300 • Toll Free: 888-597-9255 •
website:
www.wallindustries.com
• e-mail:
sales@wallindustries.com
Page 3 of 5
NOTES
Rev C
PSEP1200U SERIES
100~200 Watts
AC/DC Open Frame Power Supplies
Single, Dual, Triple, Quad Outputs
MECHANICAL DRAWINGS
Standard Model
AC Input Connector CON1: JST/B5P-VH Series or Equivalent
DC Output Connector CON2: JST/B13P-VH Series or Equivalent
DC Output CON3: Goldenconn/BB2009W4HT Series or Equivalent
Pin Assignment:
CON2:
P1-4
Vout3
P1
PG
P2-5
GND
P2
PS/ON
P6-9
Vout1
P10-11
GND
P12-13
Vout2
CON3:
P3-4
P5-6
5Vsb
GND
Dual Output Model
Please note: PS/ON (Pin 2) must be
connected to ground (Pin 5 or 6)
7/18/2019
Wall Industries, Inc. • Tel: 603-778-2300 • Toll Free: 888-597-9255 •
website:
www.wallindustries.com
• e-mail:
sales@wallindustries.com
Page 4 of 5
Rev C
PSEP1200U SERIES
100~200 Watts
AC/DC Open Frame Power Supplies
Single, Dual, Triple, Quad Outputs
MODEL NUMBER SETUP
PSEP
Series Name
2
Number of Outputs
1:
Single
2:
Dual
3:
Triple
4:
Quad
180
Total Power
100:
100W
150:
150W
175:
175W
180:
180W
200:
200W
12
05:
5V
12:
12V
18:
18V
19:
19V
24:
24V
36:
36V
48:
48V
50:
50V
D
0:
NA
A:
Stand By
B:
-12V
C:
Standby ±12V
D:
D/D Board
A
0:
NA
A:
5V/5A
B:
12V/5A
U
U Bracket
U:
U Bracket
Main Output Voltage Secondary Voltage Coding -12V/DC to DC Voltage Coding
COMPANY INFORMATION
Wall Industries, Inc. has created custom and modified units for over 50 years. Our in-house research and development
engineers will provide a solution that exceeds your performance requirements on-time and on budget. Our ISO9001: 2015
certification is just one example of our commitment to producing a high quality, well-documented product for our customers.
Our past projects demonstrate our commitment to you, our customer. Wall Industries, Inc. has a reputation for working closely
with its customers to ensure each solution meets or exceeds form, fit and function requirements. We will continue to provide
ongoing support for your project above and beyond the design and production phases. Give us a call today to discuss your
future projects.
Contact
Wall Industries
for further information:
Phone:
Toll Free:
Fax:
E-mail:
Web:
Address:
(603)778-2300
(888)597-9255
(603)778-9797
sales@wallindustries.com
www.wallindustries.com
37 Industrial Drive
Exeter, NH 03833
©2019 Wall Industries, Inc. Specifications subject to change without notice. Wall Industries is not responsible for typographical errors. The information contained herein is for
informational purposes only. This information is provided by Wall Industries and we make no representations or warranties of any kind, express or implied, about the completeness,
accuracy, reliability, suitability or availability with respect to the information contained in this document for any purpose. All product and manufacturer names are trademarks or
registered trademarks of their respective companies.
7/18/2019
Wall Industries, Inc. • Tel: 603-778-2300 • Toll Free: 888-597-9255 •
website:
www.wallindustries.com
• e-mail:
sales@wallindustries.com
Page 5 of 5
onsemi and Avnet IoT Innovation Design Competition
京公网安备 11010802033920号
EEWORLD
