1N6088 datasheet, PDF - EEWORLD Datasheet

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> 1N6088

Preview

1N6088: DescriptionZener Diode, 7.5V V(Z), 20%, 0.4W, Silicon, Unidirectional, DO-7, GLASS PACKAGE-2; CategoryDiscrete semiconductor diode; File Size33KB，1 Pages; ManufacturerCobham PLC

Download Datasheet Parametric View All

1N6088 Overview

Zener Diode, 7.5V V(Z), 20%, 0.4W, Silicon, Unidirectional, DO-7, GLASS PACKAGE-2

1N6088 Parametric

Parameter Name	Attribute value
Other features	LOW IMPEDANCE, LOW NOISE
Maximum dynamic impedance	50 Ω
Maximum voltage tolerance	20%
Terminal form	WIRE
Terminal location	AXIAL
Shell connection	ISOLATED
Number of terminals	2
Package body material	GLASS
Package shape	ROUND
Package form	LONG FORM
Terminal surface	TIN LEAD
Configuration	SINGLE
Diode component materials	SILICON
Diode type	ZENER DIODE
Number of components	1
Maximum power dissipation	0.4 W
Nominal reference voltage	7.5 V
polarity	UNIDIRECTIONAL
surface mount	NO
technology	AVALANCHE
Working test current	1 mA
JEDEC-95 code	DO-7
JESD-30 code	O-LALF-W2
JESD-609 code	e0
Certification status	Not Qualified
Maximum operating temperature	175 °C
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Maximum time at peak reflow temperature	NOT SPECIFIED
Is Samacsys	N
Objectid	8005901156
package instruction	GLASS PACKAGE-2
Reach Compliance Code	Unknown
ECCN code	EAR99

Preview

Download Datasheet

View All

LOW VOLTAGE AVALANCHE ZENER DIODES

HIGH PERFORMANCE: LOW NOISE, LOW LEAKAGE

1N6082 - 1N6091

LVA343A - LVA3100A

•

Designed for use at low current levels.

•

Features sharp knees, low leakage, low impedance, and low noise.

•

Available in the DO-7 glass package and in die form.

JEDEC

NUMBER

LVA

TYPE

(NOTE 1)

LVA343A

LVA347A

LVA351A

LVA356A

LVA362A

LVA368A

LVA375A

LVA382A

LVA391A

LVA3100A

1N6082

1N6083

1N6084

1N6085

1N6086

1N6087

1N6088

1N6089

1N6090

1N6091

NOMINAL

ZENER

VOLTAGE

Vz @ Izt

(VOLTS)

4.3

4.7

5.1

5.6

6.2

6.8

7.5

8.2

9.1

10.0

TEST

CURRENT

Izt

(mA)

20

10

5

1

MAX ZENER

IMPEDANCE

(NOTE 2)

Zzt @ Izt

(OHMS)

18

10

40

45

50

60

MAX REVERSE LEAKAGE

CURRENT

Ir

Vr

(µAdc)

2.0

0.5

0.05

0.01

(VOLTS)

1.5

2.0

3.0

4.5

5.6

6.2

6.8

7.5

8.2

9.1

MAX NOISE

DENSITY AT

(NOTE 3)

Iz = 250 µA

(ND µV /

√

Hz)

1.0

2.0

MAX REGULATION

FACTOR (NOTE 4)

∆

Vz

Iz

L

(VOLTS)

0.75

0.50

0.30

0.10

(mAdc)

2.0

1.0

0.25

0.05

0.01

1.

2.

3.

4.

5.

6.

7.

Suffix denotes Vz tolerance: non suffix for ±20%, A suffix for

±

10%.

Measures with 10%, 60 Hz AC superimposed on Izt.

Measured from 1000 to 3000 Hz.

Difference between Vz at Izt and Iz

L

.

V

F

@ 200mA = 1.2V Max.

Power rating is 400 mW @ 25°C, derate linearly to zero @ 175°C

Package Style

DO-7

P.O. BOX 609

•

ROCKPORT, MAINE 04856

•

207-236-6076

•

FAX 207-236-9558

Recommended Resources

Low Power Ethernet PHY Analysis

Bridge Measurement - 0 to 20mA Current Output Circuit

Step-down voltage regulator circuit diagram

call screening circuit

Two-phase half-wave four-coil 180° conduction brushless motor circuit

Provides a stable bias power supply example circuit diagram
