Thick Film Chip Resistors
Type CRG Series
Key Features
n
Thick film resistors with
a high power to size
ratio,ideally suited to
industrial and general
purpose use.
A range from 1 ohm to
10M and tolerances of
1% and 5%. Also
including zero ohm links.
Suitable for most
applications, including
high frequency
operation, owing to the
short lead structure and
low capacitance.
Seven Package Sizes
Terminal finish: Matte Sn
MSL Level 2
Precious metal terminations are screen printed onto a ceramic base and fired. The
resistive element is screen printed and fired and the passivation layer added. Each
resistor is trimmed to tolerance by laser. The pre-scribed tile is broken into strips, the end
plating is fired on and the strips broken into individual components. Final termination is
made by electroplating.
n
n
n
n
Characteristics – Electrical
0201
Rated Power @ 70 °C (W)
Resistance Range
(Ohms)
Tolerance (%)
Code letter
Selection Series
Temp. Coefficient (ppm/°C)
Min
Max
10
1M0
1
F
E24
E96
±200
±400
0.05
1
10
5
J
E24
11
1M0
5
J
E24
10
2M0
1
F
E24
E96
±200 ±100
±400
0402
0.063
1
10
5
J
E24
11
5
J
1
1
F
0603
0.1
101
1
F
E96
1
5
J
11
5
J
1
1
F
0805
0.125
101
1
F
E96
1
5
J
11
5
J
3M3 100 1M0 10 10M 100 1M0 10 10M
E24 E24 E24 E24 E24 E24 E24 E24 E24
±200 ±200 ±100 ±200 ±200 ±200 ±100 ±400 ±200
2010
0.5
2512
1
1
10
5
J
E24
±400
11
10M
5
J
E24
±200
1206
200
400
1
100
1
F
E24
±200
101
1M0
1
F
E24
E96
±100
2010
200
400
±400
±200
1
10
5
J
E24
11
10M
5
J
E24
1206
Rated Power @ 70 °C (W)
Resistance Range
Ohms
Tolerance (%)
Code letter
Selection Series
Temp. Coefficient (ppm/°C)
Min
Max
1
100
1
F
E24
±200
0.25
101
1M0
1
F
E24
E96
±100
±400
0402
50
100
1
10
5
J
E24
11
10M
5
J
E24
1
100
1
F
E24
101
1M0
1
F
E24
E96
±200 ±200 ±100
0603
50
100
0201
Working Voltage (V)
Max. Overload Voltage (V)
Operating Temp. Range (°C)
Climatic Category (°C)
Insulation Resistance Dry
Min (Mohms)
Stability (%)
Zerohm (A) Current Max
Resistance Max
0.5
<50 mOhm
25
50
0805
150
300
-55 to +125
55/125/56
1000
3
2512
200
400
1
1
2
2
2
2
<50 mOhm
1773204 CIS WR 03/2012
Dimensions are in millimeters
and inches unless otherwise
specified. Values in brackets
are standard equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
For email, phone or live chat, go to:
te.com/help
Thick Film Chip Resistors
Type CRG Series
Dimensions
a
L
W
t
b
Style
0201
0402
0603
0805
1206
2010
2512
L
0.6 ±0.03
1.0 ±0.1
1.6 ±0.1
2.0 ±0.15
3.1 ±0.15
5.0 ±0.1
6.35 ±0.1
W
0.3 ±0.03
0.5 ±0.05
0.8 ±0.15
1.25 ±0.15
1.55 ±0.15
2.5 ±0.15
3.2 ±0.15
t
0.23 ±0.03
0.35 ±0.05
0.45 ±0.1
0.55 ±0.1
0.55 ±0.1
0.55 ±0.1
0.55 ±0.1
a
0.10 ±0.05
0.2 ±0.1
0.3 ±0.2
0.4 ±0.2
0.45 ±0.2
0.6 ±0.25
0.6 ±0.25
b
0.15 ±0.05
0.25 ±0.1
0.3 ±0.1
0.4 ±0.2
0.45 ±0.2
0.5 ±0.2
0.5 ±0.2
Marking Codes - Case Sizes 0805 to 2512
IEC 4 Digit Marking
Resistance
Marking Code
100Ω
1000
2.2KΩ
2201
10KΩ
1002
49.9KΩ
4992
100KΩ
1003
Case Sizes 0603
E24 3 Digit Marking - Example: 101=100Ω 102=1KΩ
E24
10
33
11
36
12
39
13
43
15
47
16
51
18
56
20
62
22
68
24
75
27
82
30
91
E96 3 Digit Marking - Examples: 14C=13K7Ω, 13C=13K3Ω, 68B=4K99Ω, 68X=49.9Ω
14C
0603 E96 Marking Code Table
Code
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
Code
Multiplier
A
10
0
E96
100
102
105
107
110
113
115
118
121
124
127
130
133
137
140
143
147
150
154
158
162
165
169
174
B
10
1
Code
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
C
10
2
D
10
3
E96
178
182
187
191
196
200
205
210
215
221
226
232
237
243
249
255
261
267
274
280
287
294
301
309
E
10
4
Code
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
F
10
5
G
10
6
E96
316
324
332
340
348
357
365
374
383
392
402
412
422
432
442
453
464
475
487
499
511
523
536
549
H
10
7
Code
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
X
10
-1
Y
10
-2
E96
562
576
590
604
619
634
649
665
681
698
715
732
750
768
787
806
825
845
866
887
909
931
953
976
Z
10
-3
1773204 CIS WR 03/2012
Dimensions are in millimeters
and inches unless otherwise
specified. Values in brackets
are standard equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
For email, phone or live chat, go to:
te.com/help
Thick Film Chip Resistors
Type CRG Series
Derating Curve
100
Percent Rated Power
80
60
40
20
0
0
20
40
60
80
100
120
140
Ambient Temperature (°C)
Mounting
The resistors are suitable for processing on automatic insertion equipment.
Marking
CRG0805, CRG1206, CRG2010, CRG2512
E24 series resistors are marked with a three digit code.
E96 series resistors are marked with a four digit code.
Zerohm components are marked '0'.
CRG0603
E24 5% series are marked with a three digit code.
E24 1% series are marked with a three digit code.
E96 series are marked with the international alphanumeric three character code (available on request).
EXCEPT 10, 11, 13, 15, 20 & 75 decades which are marked as the E24 series.
CRG0201 & CRG0402 series unmarked.
Performance Characteristics
The evaluation of the performance characteristics is carried out with reference
to IECQ specifications QC 400 000 and QC 400 100.
TEST REF
4.23
4.24
4.25.1
4.25.3
TEST REF
4.13
4.32
4.33
4.19
4.18
Long Term Tests ±(3% + 0.1 ohm)
Climatic sequence
Damp heat, steady state
Endurance at 70 °C
Endurance at 125 °C
Short Term Tests ±(1% + 0.05 ohm)
Overload
Adhesion
Bond strength of end face plating
Rapid change of temperature
Resistance to soldering heat
Storage
Unopened reels should be stored within a temperature range of +5 °C to +25 °C, separated from any dust,
chemicals and solvent based materials. Non-adherence to this procedure could effect the solderability of
this product.
How to Order
CRG
Common Part
0603
Size
0201
0402
0603
0805
1206
2512
J
Tolerance
F - ±1%
J - ±5%
1K0
Resistance Value
1 ohm
(1 ohm) 1R0
1K ohm
(1000 ohms) 1K
100K ohm
(100000 ohms) 100K
1M ohm
(1000000 ohms) 1M
CRG - Thick Film
Chip Resistor
