S70FL01GS
1 Gbit (128 Mbyte) 3.0V SPI Flash
Features
CMOS 3.0V Core
Serial Peripheral Interface (SPI) with Multi-I/O
– SPI Clock polarity and phase modes 0 and 3
– Double Data Rate (DDR) option
– Extended Addressing: 32-bit address
– Serial Command set and footprint compatible with
S25FL-A, S25FL-K, and S25FL-P SPI families
– Multi I/O Command set and footprint compatible with
S25FL-P SPI family
READ Commands
– Normal, Fast, Dual, Quad, Fast DDR, Dual DDR, Quad
DDR
– AutoBoot – power up or reset and execute a Normal or
Quad read command automatically at a preselected
address
– Common Flash Interface (CFI) data for configuration
information
Programming (1.5 Mbytes/s)
– 512-byte Page Programming buffer
– Quad-Input Page Programming (QPP) for slow clock
systems
Erase (0.5 Mbytes/s)
– Uniform 256-kbyte sectors
Cycling Endurance
– 100,000 Program-Erase Cycles, minimum
Data Retention
– 20 Year Data Retention, minimum
Security Features
One Time Program (OTP) array of 2048 bytes
Block Protection
– Status Register bits to control protection against program
or erase of a contiguous range of sectors.
– Hardware and software control options
– Advanced Sector Protection (ASP)
– Individual sector protection controlled by boot code or
password
Cypress
®
65 nm MirrorBit
®
Technology with Eclipse
Architecture
Core Supply Voltage: 2.7V to 3.6V
I/O Supply Voltage: 1.65V to 3.6V
Temperature Range / Grade:
– Industrial (40 °C to +85 °C)
– Industrial Plus (40 °C to +105 °C)
– Automotive, AEC-Q100 Grade 3 (40 °C to +85 °C)
– Automotive, AEC-Q100 Grade 2 (40 °C to +105 °C)
– Automotive, AEC-Q100 Grade 1 (40 °C to +125 °C)
Packages (all Pb-free)
– 16-lead SOIC (300 mils)
– BGA-24, 8
6 mm
– 5
5 ball (ZSA024) footprint
General Description
This document contains information for the S70FL01GS device, which is a dual die stack of two S25FL512S die. For detailed
specifications, refer to the discrete die datasheet provided in the
Affected Documents/Related Documents
table.
Affected Documents/Related Documents
Document Title
S25FL512S 512 Mbit (64 Mbyte) 3.0V SPI Flash Memory Datasheet
Publication Number
001-98284
Cypress Semiconductor Corporation
Document Number: 001-98295 Rev. *N
•
198 Champion Court
•
San Jose
,
CA 95134-1709
•
408-943-2600
Revised April 03, 2018
S70FL01GS
Contents
1.
2.
3.
4.
4.1
4.2
4.3
4.4
4.5
4.6
4.7
4.8
4.9
5.
6.
7.
8.
9.
Block Diagram..............................................................
3
Connection Diagrams..................................................
4
Input/Output Summary
................................................ 5
Device Operations
.......................................................
Programming .................................................................
Simultaneous Die Operation ..........................................
Sequential Reads...........................................................
Sector/Bulk Erase ..........................................................
Status Registers.............................................................
Configuration Register ...................................................
Bank Address Register ..................................................
Security and DDR Registers ..........................................
Block Protection .............................................................
6
6
6
6
6
6
6
6
6
6
10. SDR AC Characteristics
............................................. 10
10.1 DDR AC Characteristics ............................................... 11
10.2 Capacitance Characteristics ......................................... 11
11. Ordering Information
.................................................. 12
11.1 Valid Combinations — Standard................................... 13
11.2 Valid Combinations — Automotive Grade /
AEC-Q100 .................................................................... 13
12.
12.1
12.2
12.3
Other Resources
......................................................... 14
Cypress Flash Memory Roadmap ................................ 14
Links to Software .......................................................... 14
Links to Application Notes............................................. 14
Read Identification (RDID)...........................................
7
RESET#
......................................................................... 7
Versatile I/O Power Supply (V
IO
).................................
7
DC Characteristics.......................................................
8
AC Test Conditions......................................................
9
13. Physical Diagram
........................................................ 15
13.1 SOIC 16 Lead, 300-mil Body Width .............................. 15
13.2 24-Ball BGA 8 x 6 mm (ZSA024) .................................. 16
14. Revision History..........................................................
17
Sales, Solutions, and Legal Information .......................... 19
Worldwide Sales and Design Support ........................... 19
Products ........................................................................ 19
PSoC® Solutions .......................................................... 19
Cypress Developer Community ..................................... 19
Technical Support ......................................................... 19
Document Number: 001-98295 Rev. *N
Page 2 of 19
S70FL01GS
1. Block Diagram
SI/IO0
WP#/IO2
HOLD#/IO3
S I/IO 0
WP#/IO2
S O /IO 1
H O LD #/IO 3
SO/IO1
SCK
CS#1
SCK
CS#
FL512S
Flash
Memory
VSS
VSS
VCC
VCC
S I/IO 0
WP#/IO2
H O LD #/IO 3
S O /IO 1
SCK
CS#2
CS#
FL512S
Flash
Memory
VSS
VCC
Document Number: 001-98295 Rev. *N
Page 3 of 19
S70FL01GS
2.
Connection Diagrams
Figure 1. 16-Pin Plastic Small Outline Package (SO)
HOLD#/IO3
VCC
RESET#
DNU
DNU
CS2#
CS1#
SO/IO1
1
2
3
4
5
6
7
8
16
15
14
13
12
11
10
9
SCK
SI/IO0
VIO/RFU
NC
DNU
DNU
VSS
WP#/IO2
Figure 2. 24-Ball BGA, 5 x 5 Ball Footprint (ZSA024), Top View
1
A
DNU
B
DNU
C
DNU
D
DNU
E
DNU
DNU
DNU
VIO/RFU
DNU
SO/IO1
SI/IO0 HOLD#/IO3 DNU
CS1#
RFU
WP#/IO2
RFU
SCK
VSS
VCC
RFU
CS2#
RESET#
RFU
2
3
4
5
Note:
1. V
IO
is not supported in the S70FL01GS device and is RFU. Refer to
Section 7.
for more details.
Document Number: 001-98295 Rev. *N
Page 4 of 19
