Q33310F70036914 datasheet, PDF

Datasheet> All Categories > Passive components> oscillator> Q33310F70036914

Q33310F70036914: DescriptionCMOS Output Clock Oscillator,; CategoryPassive components oscillator; File Size263KB，5 Pages; ManufacturerSeiko Epson Corporation

Download Datasheet Parametric Compare View All

Q33310F70036914 Overview

CMOS Output Clock Oscillator,

Q33310F70036914 Parametric

Parameter Name	Attribute value
Maker	Seiko Epson Corporation
Reach Compliance Code	unknown
Other features	STANDBY; ENABLE/DISABLE FUNCTION; TR, 7 INCH
maximum descent time	4 ns
Frequency Adjustment - Mechanical	NO
frequency stability	50%
Installation features	SURFACE MOUNT
Nominal operating frequency	18.1 MHz
Maximum operating temperature	70 °C
Minimum operating temperature	-20 °C
Oscillator type	CMOS
Output load	15 pF
physical size	3.2mm x 2.5mm x 1.05mm
longest rise time	4 ns
Maximum supply voltage	3.6 V
Minimum supply voltage	2.7 V
Nominal supply voltage	3.3 V
surface mount	YES
maximum symmetry	55/45 %
Base Number Matches	1

Preview

Download Datasheet

View All

Clock OSC

SG-310SCF

SG-310SCF 18.100000 MHz B

Product name

Product Number / Ordering code

Q33310F700369xx

Please refer to the 8.Packing information about xx (last 2 digits)

Output waveform CMOS

Pb free / Complies with EU RoHS directive

Reference weight Typ. 26 mg

1.Absolute maximum ratings

Parameter

Symbol

Maximum supply voltage

Storage temperature

Input voltage

Min.

-0.3

-40

-0.3

Typ.

Max.

4.2

125

Vcc+0.3

Unit

ºC

Conditions / Remarks

Storage as single product

ST terminal

Vcc-GND

T_stg

Vin

2.Specifications(characteristics)

Parameter

Symbol

Output frequency

Supply voltage

Operating temperature

Frequency tolerance

Current consumption

Stand-by current

Symmetry

Output voltage

Output load condition

Input voltage

Rise time

Fall time

Start-up time

Jitter

Min.

2.7

-20

-50

0.9Vcc

0.8Vcc

-5

Typ.

18.1000

3.3

TBD

Max.

3.6

2.5

2.0

0.1Vcc

0.2Vcc

Unit

MHz

ºC

x10

-6

µA

Conditions / Remarks

T_use

No load condition

ST = GND

50% Vcc Level L_CMOS=<15pF

IOH=-3mA

IOL=3mA

Vcc

T_use

f_tol

Icc

I_std

SYM

L_CMOS

t_str

RMS

p-p

acc

CMOS Load

ST terminal

dBc/Hz

x10

-6

0.2Vcc to 0.8Vcc Level, L_CMOS=15pF

t = 0 at 0.9Vcc

Deterministic Jitter

Random Jitter

δ(RMS of total distribution)

Peak to Peak

Accumulated Jitter(δ) n=2 to 50000

cycles

Off set Frequency: 12kHz to 20MHz

Off set 1Hz

Off set 10Hz

Off set 100Hz

Off set 1kHz

Off set 10kHz

Off set 100kHz

Off set 1MHz

@+25ºC first year

Phase jitter

Phase noise

L(f)

Frequency aging

f_age

1 Page
