30MHz VDSL2 & Vectored VDSL
Transformer
POTS VDSL2 and Vectored Transformer
Compatible with Broadcoms BCM65x00 chipset family
integrating Vectoring Technology
Designed to help Meet ITU K20e Level Testing Requirements
EN60950-1 Functional Isolation Compliant - 250Vrms
RoHS-6 Compliant SMD Product
Available on Tape & Reel
Electrical Specifications @ 25°C - Operating Temperature -40°C to +85°C
Turns Ratio
Leakage
OCL Line
(1-4): (8-5)
Inductance
(1-4) with
with (2-3, 6-7) (1-4) with others
(2-3) shorted
shorted
shorted
10kHz, 100mVrms 100kHz, 100mVrms 100kHz, 100mVrms
±10%
±2%
(uH, Max)
430
100
DCR
(1-4) with(2-3)
shorted
(OHMS Max)
BX4285LNL
1.0
1.4:1
1.4:1
1.0
1.0
LB
12MHz
(dB, Max)
LB
17MHz
(dB, Max)
LB
30MHz
(dB, Max)
THD
30kHz
3.0Vrms
(dB, Min)
-60
-60
Isolation Voltage
Line to Chip
(Vrms, 60Sec)
1500
1500
THD
30kHz
3.0Vrms
(dB, Typical)
@ -40½C
-60
-60
Part
Number
BX4285LNL
BX4286LNL
-45
-45
-42
-42
IL
8MHz ~ 30MHz
(dB Max)
3.5
3.5
-30
-30
Isolation Voltage
(1-3) to (2-4)
(Vrms, 6Sec)
750
750
DCR
Cww
(8-5) with(6-7)
Line to Chip
IL
shorted
100kHz, 100mVrms 300kHz ~ 8MHz
(OHMS Max)
(pF Max)
(dB Max)
1.0
35
0.5
0.5
BX4286LNL
1.0
1.0
35
Notes:
Add “T” suffix to part number to order on Tape & Reel i.e. BX4285LNLT, BX4286LNLT
Mechanical
Schematic
BX4285LNL/BX4286LNL
BX428XLNL
Weight
......................1.4 grams
Tray
..............................100/tray
Tape & Reel.................300/tray
Dimensions:
mm
Unless otherwise specified,
all tolerances are
±
0.1
1
pulseelectronics.com
T696.B (03/14)
