FAN73832 Half-Bridge Gate-Drive IC
February 2007
FAN73832
Features
Half-Bridge Gate-Drive IC
Description
The FAN73832 is a half-bridge, gate-drive IC with shut-
down and programmable dead-time control functions for
driving MOSFETs and IGBTs, operating up to +600V.
Fairchild’s high-voltage process and common-mode
noise canceling technique provide stable operation of
high-side driver under high dv/dt noise circumstances.
An advanced level-shift circuit allows high-side gate
driver operation up to V
S
=-9.8V (typical) for V
BS
=15V.
The UVLO circuits for both channels prevent malfunction
when V
DD
and V
BS
are lower than the specified thresh-
old voltage.
Output drivers typically source/sink 350mA/650mA,
respectively, which is suitable for all kinds of half- and
full-bridge inverters.
Floating Channel for Bootstrap Operation to +600V
Typically 350mA/650mA Sourcing/Sinking Current
Driving Capability for Both Channels
Extended Allowable Negative V
S
Swing to -9.8V for
Signal Propagation at V
DD
=V
BS
=15V
High-Side Output in Phase of IN Signal
Built-in UVLO Functions for Both Channels
Built-in Common-Mode dv/dt Noise Canceling Circuit
Internal 400ns Minimum Dead-Time at R
DT
=20KΩ
Programmable Turn-on Delay-Time Control
(Dead-Time)
Applications
SMPS
Motor Drive Inverter
Fluorescent Lamp Ballast
HID Ballast
8-SOP
8-DIP
Ordering Information
Part Number
FAN73832M
(1)
FAN73832MX
(1)
FAN73832N
Note:
1. These devices passed wave soldering test by JESD22A-111.
Package
8-SOP
8-DIP
Pb-Free
Yes
Operating Temperature Range Packing Method
Tube
-40°C ~ 125°C
Tape & Reel
Tube
© 2006 Fairchild Semiconductor Corporation
FAN73832 Rev. 1.0.2
www.fairchildsemi.com
