ITEM NO.
1
2
3
4
5
PART NUMBER
50-00426
50-00425
30-00099
24-00057
24-00056
DESCRIPTION
Connector, USB B receptacle
Connector, plug, USB A
Wire, 4C, 1PR + 2C, 28 AWG, UL2725, 30V, 80C, 3.6mm, shielded, VW-1, PVC, 79A, USB 2.0, white
Overmold, jack, USB B
Overmold, plug, USB A
QTY.
1
1
1
1
1
PVC, white
PVC, white
COMPONENT NOTES
100 ±15
3
2
1
4
Drain wire
1
1
4
5
2
4
Drain wire
Wiring diagram
50-00426
1
2
3
4
Shell
Prepared:
Verified:
Notes:
RoHS compliant
Function test: no open, no short circuit, no
intermittent
Description:
Cable, 100 mm, USB B receptacle to USB A male, 28
AWG, 30-00099 wire, white
3
2
tel
fax
Wire Color
Red
White
Green
Black
Drain & Shield
50-00425
1
2
3
4
Shell
Notes:
Cables individually tied and bundled in groups of 10
Functionally equivalent components may be substituted
Revision:
A
A1
A2
Date:
9/21/2011
1/29/2014
11/1/2018
Description:
Initial release
Corrected shield type
Removed label
AW
GL
Digitally signed by AW
Date: 2018.11.01
13:53:38 -07'00'
Digitally signed by GL
Date: 2018.11.02
09:40:06 -07'00'
Dimensions are in
millimeters.
Tolerances:
0.5 mm
X:
X.X:
0.3 mm
X.XX: 0.05 mm
4
1.541.323.3228
1.541.323.4202
Part number:
800
web
877.670.7118
tensility.com
Size:
A
Scale:
10-00776
1:1
1
Sheet 1 of 1
5
To see a custom version of this cable assembly, call Tensility at 541-323-3228 or email engineering@tensility.com
3.6
