STANDARD RF INDUCTORS - THRU HOLE
10MG
10MGLF
*
PART
NUMBER
10MG100K
10MG120K
10MG150K
10MG180K
10MG220K
10MG270K
10MG330K
10MG390K
10MG470K
10MG560K
10MG680K
10MG820K
10MG101K
TRADITIONAL
Pb
COMPLIANT
RoHS
Wirewound, Non-Magnetic, Molded
L
µH
0.10
0.12
0.15
0.18
0.22
0.27
0.33
0.39
0.47
0.56
0.68
0.82
1.00
Q
MIN
40
40
38
35
33
33
30
30
30
30
28
28
25
TEST FREQ
L&Q
MHz
NON-MAGNETIC COIL FORM
25
25
25
25
25
25
25
25
25
25
25
25
25
SRF
MHz
MIN
680
640
600
550
510
430
410
365
330
300
275
250
230
DCR
OHMS
MAX
0.08
0.09
0.10
0.12
0.14
0.16
0.22
0.30
0.35
0.50
0.60
0.85
1.00
CURRENT
RATING
mA DC
1350
1270
1200
1025
1105
960
815
700
650
545
495
415
385
Suffix “K” for 10% tolerance
Optional tolerance levels available; please contact factory
Custom designs are available to meet your specific requirements; please contact factory
*Add “LF” suffix for RoHS requirement. Example: 10MG100KLF
Gowanda designates a component RoHS-compliant by adding “LF” (lead free) to the part number.
These LF components meet the ≤ .1% lead requirement and they are compatible with 260°C soldering processes.
NOTES:
• Operating Temperature Range:
-55°C to +125°C
• Current Rating is based on 35ºC temperature
rise at an ambient temperature of 90ºC
• Relative Permeabilitry: ≤0.00003 µr
• Medical Grade
• Used in imaging equipment where non-
magnetic inductors are required
• Epoxy encapsulated for environmental
protection and superior strength to withstand all
types of reflow soldering
1.438 ± 0.188
(36.525 ± 4.77)
24 AWG
1.0µH ±10%
MG
0.250 ± 0.010
(6.350 ± 0.25)
0.095 ± 0.008
(2.413 ± 0.20)
• Laser marking is standard
TAPE AND REEL SPECS:
Pcs./Reel maximum:
Pitch between parts:
Inside tape spacing:
Reel diameter
Class:
3500
0.200 in.
2.062 in.
12 in.
1
60/40 coated, copper leads
in. (mm)
One Magnetics Pkwy, Gowanda, NY 14070 • (t) 716-532-2234 • (f) 716-532-2702 • sales@gowanda.com
www.gowanda.com
120413
