536710-3 Product Details
Live Product Chat
Product View
2mm Centerline Futurebus+ Connectors
Not re vie we d for R oHS C om plia nce
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
536710-3
T E I nternal N umber: 5 3 6 7 1 0 - 3
Product Highlights:
l
Module Type = Power and Signal
l
144 Signal Positions
l
8 Power Positions
l
Monoblock Hybrid C onnectors
l
144-8 C onfiguration
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Documents are temporarily unavailable. We are working hard to correct the problem. Please try
again later.
Additional Information:
l
Product Line Information
Additional Product Images:
l
Product Photo
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= Monoblock Hybrid C onnectors
l
Post Type
= Press-Fit
l
C omment = An 8 signifies a power section. Pin A-1 would be the first
configuration of the part number. For example, 8-192-8 signifies the
8 power positions starting at Pin-A-1, followed by 192 signal
positions, followed by 8 power positions.
Mechanical Attachment:
l
Module Type
= Power and Signal
l
Number of Power Positions
= 8
l
C onfiguration
= 144-8
l
Mating Post Length (mm [in])
= 6.50 [0.256]
l
Press-Fit Post Style = C ompliant Pin
Electrical Characteristics:
l
Voltage Rating (VAC ) = 30
Termination Related Features:
l
Termination Post Length (mm [in])
= 4.25 [0.167]
Body Related Features:
l
Number of Signal Positions
= 144
l
Sequencing
= No
l
Post Plating
= Tin Lead over Nickel
l
C enterline, Matrix (mm [in]) = 2.00 x 2.00 [.079 x .079]
Contact Related Features:
l
C ontact Base Material = Phosphor Bronze
l
C ontact Mating Area Plating Material = Gold Flash over Palladium
Nickel
Housing Related Features:
l
Housing Material = Liquid C rystal Polymer (LC P)
Industry Standards:
l
RoHS/ELV C ompliance
= Not reviewed for ELV/RoHS compliance
l
Lead Free Solder Processes
= Not reviewed for lead free solder
process
Other:
l
Brand = AMP
