BA782S and BA783S
Bandswitching Diodes
SOD-323
.012 (0.3)
Cathode Band
Pad Layout SOD-323
.112 (2.85)
.100 (2.55)
.076 (1.95)
.065 (1.65)
Top View
Dimensions in inches
and (millimeters)
0.055
(1.40)
0.062
(1.60)
0.047 (1.20)
.059 (1.5)
.004 (0.1)
max.
.043 (1.1)
.049 (1.25)
max.
.010 (0.25)
min.
Features
• Silicon Epitaxial Planar Diode Switches
• For electric bandswitching in radio and TV tuners
in the frequency range of 50...1000 MHz. The
dynamic forward resistance is constant and very
small over a wide range of frequency and forward
current. The reverse capacitance is also small and
largely independent of the reverse voltage.
• These diodes are also available in SOD-123 case
with the type designations BA782 and BA783.
.006 (0.15)
max.
Mechanical Data
Case:
SOD-323 plastic case
Weight:
approximately 0.004g
Cathode Band Color:
Blue
Packaging Codes/Options:
D5/10K per 13” reel (8mm tape), 30K/box
D6/3K per 7” reel (8mm tape), 30K/box
Maximum Ratings and Thermal Characteristics
Ratings at 25°C ambient temperature unless otherwise specified.
Parameter
Reverse Voltage
Forward Continuous Current at T
amb
= 25°C
Junction Temperature
Storage Temperature Range
Symbol
V
R
I
F
T
j
T
S
Value
35
100
125
–55 to +125
Unit
V
mA
°C
°C
5/8/00
BA782S and BA783S
Bandswitching Diodes
Electrical Characteristics
Parameter
Forward Voltage
Leakage Current
BA782
BA783
BA782
BA783
Capacitance
Series Inductance across Case
BA782
BA783
Ratings at 25°C ambient temperature unless otherwise specified.
Symbol
V
F
I
R
Test Condition
I
F
= 100mA
V
R
= 20V
f = 50...1000MHz, I
F
= 3mA
Min
—
—
—
—
—
—
—
—
—
—
Typ
—
—
—
—
—
—
—
—
—
2.5
Max
1
50
0.7
1.2
0.5
0.9
1.5
1.25
1.2
—
Unit
V
nA
Ω
Dynamic Forward Resistance
r
f
f = 50...1000MHz, I
F
= 10mA
V
R
= 1V, f = 1MHz
C
tot
L
S
V
R
= 3V, f = 1MHz
—
pF
nH
Ratings and
Characteristic Curves
(T
A
= 25°C unless otherwise noted)
