D Subminiature
Part numbers with plastic bracket with
grounding bracket and captive nut M3
Shell Layout
size
P/N without pushfit
P/N with pushfit
Combo D
®
/European Version
Part numbers with plastic bracket with
grounding bracket with bushing diam. 3,05
P/N without pushfit
P/N with pushfit
40 A High power 90° – European footprint, size DD, with plastic bracket and grounding bracket
Part numbers with plastic bracket with
grounding bracket with post M3
P/N without pushfit
P/N with pushfit
DD
DD
DD
DD
24W7
36W4
43W2
47W1
DDM-24P7P-1AVN-A191-K87
DDM-36P4P-1AVN-A191-K87
DDM-43P2P-1AVN-A191-K87
DDM-47P1P-1AVN-A191-K87
DDM-24P7P-1AVN-A191-K87-146
DDM-36P4P-1AVN-A191-K87-146
DDM-43P2P-1AVN-A191-K87-146
DDM-47P1P-1AVN-A191-K87-146
DDM-24P7P-1ADN-A191-K87
DDM-36P4P-1ADN-A191-K87
DDM-43P2P-1ADN-A191-K87
DDM-47P1P-1ADN-A191-K87
DDM-24P7P-1ADN-A191-K87-146
DDM-36P4P-1ADN-A191-K87-146
DDM-43P2P-1ADN-A191-K87-146
DDM-47P1P-1ADN-A191-K87-146
DDM-24P7P-1AGN-A191-K87
DDM-36P4P-1AGN-A191-K87
DDM-43P2P-1AGN-A191-K87
DDM-47P1P-1AGN-A191-K87
DDM-24P7P-1AGN-A191-K87-146
DDM-36P4P-1AGN-A191-K87-146
DDM-43P2P-1AGN-A191-K87-146
DDM-47P1P-1AGN-A191-K87-146
For performance class 1 replace A191 with A190.
For performance class 3 delete A191.
For post 4-40 UNC thread replace 1AVN with 1AWN and 1AGN
with 1AJN.
For pushfit 90° hole diameter 3,2 mm replace 146
with 162.
Pin
A
C
B
2,54
3,7
±0,3
8,7
±0,15
q
q
ITT
16
17
18
19
20
21
22
23
24
25
CANNON
26
27
36W4P
28
29
30
31
32
10
°
Ø 3
17,8
±0,2
E
9
10
11
12
13
14
15
13,1
±0,2
D
q
A1
A2
A3
1
2
3
4
5
6
7
8
A4
Ø 0,6
q
For contact cavity arrangements, see page 52.
For pcb hole pattern, see page 68 – 71.
For mounting methods, see page 86 – 87.
For panel cut-outs, see our D Subminiature
catalogue.
2,54
Dimensions
Shell
size
A
±
0,38
66,95
B
±
0,13
52,8
C
±
0,13
61,1
D
±
0,13
11,1
E
±
0,13
15,4
F
±
0,25
10,8
L
+
0,2
W
±
0,4
6,85
DD
0,9
24
Dimensions are mm
Subject to change
W
L
F
