First Sensor High Voltage Supply Data Sheet
Part Description MOD501383
Order # 501383
Version 19-02-2013
501383
501381
501382
501385
501384
Features
• Low ripple 10mVpp
• On-board reference source
• Easy adjustment
• Shielded, HF safe package
• 200 V maximum voltage
Description
Precission regulated power module
for PIN diodes with low ripple in
compact package. Output voltage to
be set by external resistor.
Application
• High voltage for PIN-PD
• High voltage for APD
RoHS
2002/95/EC
Absolute maximum ratings
Symbol
T
STG
T
OP
Vcc
Parameter
Storage temp
Operating temp
Supply Voltage
Min
-10
-10
4.75
Max
125
70
5.5
Unit
°C
°C
V
High Voltage Control
200
Output voltage HV out [V]
150
100
50
0
0
20
40
Control resistor Rset [kΩ]
Min
+4.75
Typ
+5.0
29
30
1.244
1
peak to peak
V
cc
= 5 V, R
set
= 0 (for max HV
out
),
R
set
= 60 kΩ (for min HV
out
)
20
50
10
5
15
201
0.5
Max
+5.5
V
HV
[V]=1.244V (1+1000/(6.2+R
set
[kΩ]))
Block diagram
60
Electrical characteristics @ 23°C
Symbol
V
CC
Characteristic
Input voltage
Input current w/o load
Input capacitance
Control Resistor
Internal reference voltage
Set point accuracy
Temperature coefficient
Ripple
Short circuit protected
Output voltage
Output current
Test Condition
V
cc
= 5 V, R
set
= 0, without R
load
HV
out
= 20 V … 200 V
0
Unit
V
mA
µF
kΩ
V
%
ppm/K
mVpp
s
V
mA
R
set
V
REF
T
K
60
HV
out
European, International Sales:
First Sensor AG
Peter-Behrens-Strasse 15
12459 Berlin
Germany
T +49 30 6399 2399
F +49 30 639923-752
sales.opto@first-sensor.com
USA:
First Sensor Inc.
5700 Corsa Avenue #105
Westlake Village
CA 91362 USA
T +1 818 706 3400
F +1 818 889 7053
sales.us@first-sensor.com
First Sensor High Voltage Supply Data Sheet
Part Description MOD501383
Order # 501383
Version 19-02-2013
Application hints
If a potentiometer is used to set the resistance it is advisable to use a large fixed resistor in series with a small potentiometer resistor.
This can reduce the temperature drift of the complete system.
Technical drawing
Mechanical characteristics
Parameter
Length
Width
Height
Volume
Weight
Case material
Disclaimer:
Pin connections
Unit
mm
mm
mm
cm³
g
Part
1
2
3
4
7
8
Symbol
HV
GND
HV
out
Rset
Rset
GND
Vcc
Function
High voltage ground
High voltage output
Resistor
Resistor
Ground
Input Voltage
Parameter
34
24
15
12.2
11
Tinplate
Due to our strive for continuous improvement, specifications are subject to change within our PCN policy according to JESD46C.
First Sensor AG
Peter-Behrens-Strasse 15
12459 Berlin
Germany
T +49 30 6399 2399
F +49 30 639923-752
sales.opto@first-sensor.com
European, International Sales:
USA:
First Sensor Inc.
5700 Corsa Avenue #105
Westlake Village
CA 91362 USA
T +1 818 706 3400
F +1 818 889 7053
sales.us@first-sensor.com
