Features
•
Efficient means of shipping or storing ESD sensitive circuit boards and other
items
•
Provides ESD shielding with lid closed; “Faraday Cage” effect restricts
electrostatic charges to exterior
•
For physical protection, convoluted foam secures items, minimizing movement
and reduces stress from physical shock
• No assembly required
•
Convoluted static dissipative <10
11
ohms polyurethane pink foam laminated to
top and fitted in bottom
• Made in the United States of America
--
--
---
D
See reverse side for
available sizes.
---
---
---
L
-
SPECIFICATIONS
Properties
Electrostatic Decay
Surface Resistance
High-Voltage Discharge Resistance
Static Shielding
Current-Carrying Hazard
Corrosivity
Antistat Transfer
Water & Isopropyl Alcohol Extraction
Tests for Antistat Permanence
Sloughing Test
Typical Values
0.01 seconds at 72°F and 11.8% R.H.
1 x 10
5
to < 1 x 10
11
ohms
Failure rate 0/5 (no oxide damage in five consecutive tests)
99.9% attenuation at 10kV; 99.6% attenuation at 30kV
10
3
mA at 110V; 10
3
mA at 220V
Contains 1-3 ppm reducible sulfur
No transfer
Surface resistance 1 x 10
8
to < 1 x 10
9
ohms/square at 74°F
and 36% R.H.
Negligible surface damage at 10 cycles and <5% of surface
damage at 200 cycles in Taber Abrasion Test.
No conductive particles abrased from surface
Complete recyclability of package
Biodegradation in or on moist soil
Conductivity from wall to wall as well as across surface
to assure permanence of the antistatic property
Indefinite
Test Procedures/Method
FED-STD-101, Method 4046
ANSI/ESD STM11.11
Rockwell International Test Report of December 20, 1991
EIA 541, appendix E, capacitive probe test
ESD from A to Z
FED-STD-101, Method 3005 for reducible sulfur
Rockwell International Test Report of January 8, 1992
Rockwell International Test Report of January 8, 1992
ASTM D4060 at 70 rpm with CS-17 abrasive-coated
wheels and 1000 grams load
Rockwell International Test Report of January 8, 1992
Rockwell International Test Report of January 8, 1992
Rockwell International Test Report of January 8, 1992
Recyclability
Biodegradability
Volume Conductivity
Shelf Life
--
--
---
W
Specifications and procedures subject to change without notice.
Made in the
United States of America
CIRCUIT BOARD SHIPPERS
PROTEKTIVE PAK
1350 MONTE VISTA AVENUE, CHINO, CA 91710
PHONE (909) 627-2578
ProtektivePak.com
© 2013 DESCO INDUSTRIES INC.
Employee Owned
DRAWING NUMBER
37050
DATE:
December
2013
Item No.
37050
37051
37080
37081
37052
37053
37054
37055
37082
37083
37056
37057
37084
37085
37058
37059
37060
37061
37062
37063
37064
37065
Size I.D. - L x W x D
4 x 4 x 2-1/8, box only
4 x 4 x 2-1/8, box w/foam
6-3/16 x 6 x 1-1/2, box only
6-3/16 x 6 x 1-1/2, box w/ foam
7 x 5 x 1-1/2, box only
7 x 5 x 1-1/2, box w/ foam
7 x 5 x 2-1/2, box only
7 x 5 x 2-1/2, box w/ foam
7 x 7 x 1-1/2, box only
7 x 7 x 1-1/2, box w/ foam
9 x 7-1/2 x 2-1/2, box only
9 x 7-1/2 x 2-1/2, box w/foam
9 x 9 x 1-1/2, box only
9 x 9 x 1-1/2, box w/foam
10-1/2 x 8-1/2 x 1-1/2, box only
10-1/2 x 8-1/2 x 1-1/2, box w/foam
10-1/2 x 8-1/2 x 2-1/2, box only
10-1/2 x 8-1/2 x 2-1/2, box w/foam
12-1/2 x 10-1/2 x 1-1/2, box only
12-1/2 x 10-1/2 x 1-1/2, box w/foam
12-1/2 x 10-1/2 x 2-1/2, box only
12-1/2 x 10-1/2 x 2-1/2, box w/foam
Item No.
37066
37067
37068
37069
37070
37071
37072
37073
37086
37087
37074•
37075•
37088•
37089•
37076•
37077•
37078
37079
37090•
37091•
37092•
37093•
Size I.D. - L x W x D
14-7/8 x 6-5/8 x 2, box only
14-7/8 x 6-5/8 x 2, box w/foam
15-1/2 x 12-1/2 x 1-1/2, box only
15-1/2 x 12-1/2 x 1-1/2, box w/foam
15-1/2 x 12-1/2 x 2-1/2, box only
15-1/2 x 12-1/2 x 2-1/2, box w/foam
16 x 12-1/4 x 3-1/2, box only
16 x 12-1/4 x 3-1/2, box w/foam
16 x 15 x 3, box only
16 x 15 x 3, box w/foam
18-7/8 x 17-5/8 x 1-3/4, box only
18-7/8 x 17-5/8 x 1-3/4, box w/foam
19 x 19 x 3, box only
19 x 19 x 3, box w/foam
20-1/2 x 15-1/2 x 1-1/2, box only
20-1/2 x 15-1/2 x 1-1/2, box w/foam
20-1/2 x 15-1/2 x 2-1/2, box only
20-1/2 x 15-1/2 x 2-1/2, box w/foam
22 x 15 x 3, box only
22 x 15 x 3, box w/foam
27-3/8 x 24-3/8 x 4, box only
27-3/8 x 24-3/8 x 4, box w/foam
• These items made to order
