53417-3 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> terminals> 53417-3

53417-3: DescriptionTerminal, 2 mm2, GOLD (50) FINISH, RING TERMINAL; CategoryThe connector terminals; File Size117KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric View All

53417-3 Overview

Terminal, 2 mm2, GOLD (50) FINISH, RING TERMINAL

53417-3 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	TE Connectivity
Reach Compliance Code	unknown
ECCN code	EAR99
Manufacturer's serial number	53417
Terminal and terminal strip types	RING TERMINAL
Conductor cross section	2 mm2
Wire gauge	14 AWG
Base Number Matches	1

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Product Feature Selector

> Product Details

53417-3 Product Details

Live Product Chat

Product View

Radiation Resistant/Pre-Insulated Terminals & Splices

Not EU R oHS or ELV C om plia nt

(

Find R oHS C om plia nt Alte rna te s

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

53417-3

T E I nternal N umber: 5 3 4 1 7 - 3

Product Highlights:

Terminal

Wire Range = 1.25-2.00² [16-14] mm [AWG]

Wire Range = 2050 - 5180 C MA

Body Style = PIDG

Wire Insulation Diameter = 3.81 mm

View all Features

Obsolete

Search for Replacement Parts

View 3D PDF

Documentation & Additional Information

Product Drawings:

TERMINAL, RING TONGUE, PVF2 , P.I.D.G. WIRE SIZE: 16...

(PDF, English)

Catalog Pages/Data Sheets:

RADIATION RESISTANT/150 C PRE-INSULATED TERMINALS AM...

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

AD Format & C ompression Information)

2D Drawing

(DXF, Version R)

3D Model

(IGES, Version R)

3D Model

(STEP, Version R)

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type

= Terminal

Body Style

= PIDG

Wire Insulation Diameter (mm [in])

= 3.81 [0.150]

Stud Size

= 8 [M4]

Finish

= Gold (50)

Tongue Material Thickness (mm [in]) = 0.84 [0.033]

C olor C ode = Blue

Body Material = C opper

Insulation = Yes

Body Related Features:

Wire Range (mm [AWG])

= 1.25-2.00² [16-14]

Wire Range (C MA)

= 2,050 – 5,180

Insulation Sleeve C olor = Natural

Insulation Sleeve Material = PVF2

Insulation Support Sleeve Material = C opper

Industry Standards:

Government/Industry Qualification = No

RoHS/ELV C ompliance

= Not ELV/RoHS compliant

Lead Free Solder Processes

= Not relevant for lead free process

Packaging Related Features:

Packaging Method

= Loose Piece

Other:

Brand = AMP

Additional Information:

Product Line Information
