Extract from the online
catalog
UT 4-TG-P/P
Order No.: 3046168
http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=3046168
Feed-through modular terminal block, Connection type: Screw
connection, Cross section: 0.14 mm² - 6 mm², AWG: 26 - 10, Nominal
current: 20 A, Nominal voltage: 500 V, Length: 57.8 mm, Width: 6.2
mm, Color: gray, Assembly: NS 35/7.5, NS 35/15
Product notes
Commercial data
GTIN (EAN)
sales group
Pack
Customs tariff
Weight/Piece
Catalog page information
4017918975586
A841
50 pcs.
85369010
0.013547 KG
Page 52 (CL-2009)
http://
www.download.phoenixcontact.com
Please note that the data given
here has been taken from the
online catalog. For comprehensive
information and data, please refer
to the user documentation. The
General Terms and Conditions of
Use apply to Internet downloads.
WEEE/RoHS-compliant since:
01/01/2003
Technical data
General
Number of levels
Number of connections
Color
1
2
gray
PHOENIX CONTACT Inc., USA
http://www.phoenixcon.com
Page 1 / 8
Oct 28, 2010
UT 4-TG-P/P
Order No.: 3046168
http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=3046168
Insulating material
Inflammability class acc. to UL 94
Bridge accessories
Dimensions
Width
Length
Height NS 35/7.5
Height NS 35/15
Technical data
Maximum load current
Rated surge voltage
Pollution degree
Surge voltage category
Insulating material group
Connection in acc. with standard
Nominal current I
N
Nominal voltage U
N
Open side panel
Connection data
Conductor cross section solid min.
Conductor cross section solid max.
Conductor cross section stranded min.
Conductor cross section stranded max.
Conductor cross section AWG/kcmil min.
Conductor cross section AWG/kcmil max
Conductor cross section stranded, with ferrule
without plastic sleeve min.
Conductor cross section stranded, with ferrule
without plastic sleeve max.
Conductor cross section stranded, with ferrule
with plastic sleeve min.
Conductor cross section stranded, with ferrule
with plastic sleeve max.
2 conductors with same cross section, solid min.
2 conductors with same cross section, solid max.
PA
V0
3030271 FBS 10-6 32 A
6.2 mm
57.8 mm
47.5 mm
55 mm
20 A (with 6 mm conductor cross section)
6 kV
3
III
I
IEC 60947-7-1
20 A
500 V
nein
2
0.14 mm²
6 mm²
0.14 mm²
6 mm²
26
10
0.14 mm²
4 mm²
0.14 mm²
4 mm²
0.14 mm²
1.5 mm²
PHOENIX CONTACT Inc., USA
http://www.phoenixcon.com
Page 2 / 8
Oct 28, 2010
UT 4-TG-P/P
Order No.: 3046168
http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=3046168
2 conductors with same cross section, stranded
min.
2 conductors with same cross section, stranded
max.
2 conductors with same cross section, stranded,
TWIN ferrules with plastic sleeve, min.
2 conductors with same cross section, stranded,
TWIN ferrules with plastic sleeve, max.
2 conductors with same cross section, stranded,
ferrules without plastic sleeve, min.
2 conductors with same cross section, stranded,
ferrules without plastic sleeve, max.
Type of connection
Stripping length
Internal cylindrical gage
Screw thread
Tightening torque, min
Tightening torque max
Certificates / Approvals
0.14 mm²
1.5 mm²
0.5 mm²
2.5 mm²
0.14 mm²
1.5 mm²
Screw connection
9 mm
A4
M3
0.6 Nm
0.8 Nm
Certification
CSA
Nominal voltage U
N
Nominal current I
N
AWG/kcmil
CUL
Nominal voltage U
N
Nominal current I
N
AWG/kcmil
UL
Nominal voltage U
N
Nominal current I
N
AWG/kcmil
CSA, CUL, UL
300 V
16 A
26-10
300 V
16 A
26-10
300 V
16 A
26-10
PHOENIX CONTACT Inc., USA
http://www.phoenixcon.com
Page 3 / 8
Oct 28, 2010
UT 4-TG-P/P
Order No.: 3046168
http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=3046168
Accessories
Item
Assembly
3022276
CLIPFIX 35-5
Snap-on end bracket, for NS 35/7.5 or NS 35/15 DIN rail, can be
fitted with Zack strip ZB 5 and ZBF 5, terminal strip marker KLM
2 and KLM, parking facility for FBS...5, FBS...6, KSS 5, KSS 6,
width: 5,15 mm, color: gray
DIN rail, material: Copper, unperforated, height 7.5 mm, width 35
mm, length: 2 m
NS 35 DIN rail, height 7.5 mm, length 755 mm
NS35 DIN rail, height 7.5 mm, length 955 mm
NS 35 DIN rail, height 7.5 mm, length 1155 mm
DIN rail, material: Steel, galvanized and passivated with a thick
layer, perforated, height 7.5 mm, width 35 mm, length: 2 m
DIN rail, material: Steel, unperforated, height 7.5 mm, width 35
mm, length: 2 m
DIN rail, deep-drawn, high profile, unperforated, 1.5 mm thick,
material: Aluminum, height 15 mm, width 35 mm, length 2 m
DIN rail, material: Copper, unperforated, 1.5 mm thick, height 15
mm, width 35 mm, length: 2 m
NS 35 DIN rail, perforated, height 15 mm, length 755 mm
NS 35 DIN rail, perforated, height 15 mm, length 955 mm
NS 35 DIN rail, perforated, height 15 mm, length 1155 mm
DIN rail, material: Steel, perforated, height 15 mm, width 35 mm,
length: 2 m
DIN rail, material: Steel, unperforated, height 15 mm, width 35
mm, length: 2 m
DIN rail, material: Steel, unperforated, 2.3 mm thick, height 15
mm, width 35 mm, length: 2 m
Component connector, Nominal current: 6 A, Length: 24 mm,
Width: 5.2 mm, Height: 22 mm, Color: gray
Designation
Description
0801762
1207640
1207653
1207666
0801733
0801681
1201756
1201895
1207679
1207682
1207695
1201730
1201714
1201798
3036796
NS 35/ 7,5 CU UNPERF
2000MM
NS 35/ 7,5 PERF 755MM
NS 35/ 7,5 PERF 955MM
NS 35/ 7,5 PERF 1155MM
NS 35/ 7,5 PERF 2000MM
NS 35/ 7,5 UNPERF 2000MM
NS 35/15 AL UNPERF 2000MM
NS 35/15 CU UNPERF 2000MM
NS 35/15 PERF 755MM
NS 35/15 PERF 955MM
NS 35/15 PERF 1155MM
NS 35/15 PERF 2000MM
NS 35/15 UNPERF 2000MM
NS 35/15-2,3 UNPERF 2000MM
P-CO
Bridges
3030336
3030242
3030255
3030349
3030271
3030365
3032224
FBS 2-6
FBS 3-6
FBS 4-6
FBS 5-6
FBS 10-6
FBS 20-6
FBS 50-6
Plug-in bridge, Number of positions: 2, Color: red
Plug-in bridge, Number of positions: 3, Color: red
Plug-in bridge, Number of positions: 4, Color: red
Plug-in bridge, Number of positions: 5, Color: red
Plug-in bridge, Number of positions: 10, Color: red
Plug-in bridge, Number of positions: 20, Color: red
Plug-in bridge, Number of positions: 50, Color: red
PHOENIX CONTACT Inc., USA
http://www.phoenixcon.com
Page 4 / 8
Oct 28, 2010
UT 4-TG-P/P
Order No.: 3046168
http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=3046168
Plug/Adapter
3032460
3032457
3036783
3038956
3036806
P-CO 1N4007/L-R
P-CO 1N4007/R-L
P-DI
P-FIX
P-FU 5X20
Component connector, Length: 24 mm, Width: 5.2 mm, Height: 22
mm, Color: gray
Component connector, Length: 24 mm, Width: 5.2 mm, Height: 22
mm, Color: gray
Isolating connectors, Length: 10.5 mm, Width: 3.5 mm,
Height: 23.1 mm, Color: orange
Feed-through connector, Length: 10.5 mm, Width: 4 mm,
Color: gray
Fuse plug, Nominal current: 6.3 A, Nominal voltage: 500
V, Width: 6.2 mm, Fuse type: G / 5 x 20, Fuse type: Glass,
Color: black
Fuse plug, Nominal current: 6.3 A, Nominal voltage: 500
V, Width: 6.2 mm, Fuse type: G / 5 x 20, Fuse type: Glass,
Color: black
Fuse plug, Nominal current: 6.3 A, Nominal voltage: 500
V, Width: 6.2 mm, Fuse type: G / 5 x 20, Fuse type: Glass,
Color: black
Fuse plug, Nominal current: 6.3 A, Nominal voltage: 500
V, Width: 6.2 mm, Fuse type: G / 5 x 20, Fuse type: Glass,
Color: black
Fuse plug, Nominal current: 10 A, Nominal voltage: 630 V,
Width: 8.2 mm, Fuse type: G / 6,3 x 32, Fuse type: Glass,
Color: black
Fuse plug, Nominal current: 10 A, Nominal voltage: 250 V,
Width: 8.2 mm, Fuse type: G / 6,3 x 32, Fuse type: Glass,
Color: black
Fuse plug, Nominal current: 10 A, Nominal voltage: 24 V,
Width: 8.2 mm, Fuse type: G / 6,3 x 32, Fuse type: Glass,
Color: black
Fuse plug, Nominal current: 10 A, Nominal voltage: 60 V,
Width: 8.2 mm, Fuse type: G / 6,3 x 32, Fuse type: Glass,
Color: black
Test adapter, Color: gray
Test adapter, Color: red
3036835
P-FU 5X20 LA 250
3036819
P-FU 5X20 LED 24
3036822
P-FU 5X20 LED 60
3046498
P-FU 6,3X32
3046524
P-FU 6,3X32 LA 250
3046508
P-FU 6,3X32 LED 24
3046511
P-FU 6,3X32 LED 60
3030925
3030996
Tools
1205053
PAI-4
PS-6
SZS 0,6X3,5
Actuation tool, for ST terminal blocks, insulated, also suitable
for use as a bladed screwdriver, size: 0.6 x 3.5 x 100 mm, 2-
component grip, with non-slip grip
PHOENIX CONTACT Inc., USA
http://www.phoenixcon.com
Page 5 / 8
Oct 28, 2010
