Ceramic
Low Pass Filter
DC to 95 MHz
Maximum Ratings
Operating Temperature
Storage Temperature
RF Power Input*
DC Current Input to Output
-55°C to 100°C
-55°C to 100°C
8.5W max. at 25°C
0.5A max. at 25°C
!
NEW
LFCN-95
Features
•
•
•
•
•
•
•
•
•
excellent power handling, 8.5W
small size
7 sections
temperature stable
patent pending
harmonic rejection
VHF/UHF transmitters/receivers
RF suppression for DC lines on PCB
anti-aliasing for A/D converter
CASE STYLE: FV1206
Model
LFCN-95
LFCN-95D
Price
$3.99
$4.49
Qty.
(10-49)
(10-49)
*Passband rating, derate linearly to 3.5W at 100°C ambient.
Applications
Pin Connections
RF IN
RF OUT
GROUND
**RF IN & RF OUT can be interchanged
1**
3**
2,4
Low Pass Filter Electrical Specifications
1
(T
AMB
=25°C)
MODEL
NO.
PASSBAND
(MHz)
(loss < 1 dB)
Max.
LFCN-95
DC-95
Outline Drawing
fco, MHz
Nom.
(loss 3 dB)
Typ.
165
STOP BAND (MHz)
(loss, dB)
f 20
Min.
220
40
Typ.
240-1600
fr 20
Typ.
4500
VSWR (:1)
Stopband
Typ.
20
Passband
Typ.
1.2
NO. OF
SECTIONS
7
1. For Applications requiring DC voltage to be applied to the Input or output, use LFCN-95D (DC Resistance to
ground is 100 Mohms min.)
typical frequency response
ATTENUATION (dB)
40dB
20dB
schematic
RF IN
RF OUT
3dB
1dB
f co f 20
FREQUENCY
fR 20 dB
Typical Performance Data at 25°C
Frequency
(MHz)
1.00
95.00
165.00
185.00
200.00
220.00
240.00
300.00
500.00
700.00
1050.00
1750.00
2750.00
3750.00
4750.00
Insertion Loss
(dB)
0.21
0.89
3.29
6.95
12.69
25.31
40.82
36.40
46.32
61.06
52.77
39.88
28.46
23.85
20.64
VSWR
(:1)
1.05
1.12
2.13
4.41
7.60
10.37
12.18
15.53
29.96
48.26
82.73
62.05
43.44
11.46
19.11
Outline Dimensions (
inch
)
mm
A
.126
3.20
H
.087
2.21
B
.063
1.60
J
.024
0.61
C
.037
0.94
K
.122
3.10
D
.020
0.51
L
.024
0.61
E
.032
0.81
M
.087
2.21
F
.009
0.23
N
.012
0.30
G
.169
4.29
P
wt
.071 grams
1.80
.020
Demo Board MCL P/N: TB-270
Suggested PCB Layout (PL-137)
70
INSERTION LOSS (dB)
60
50
40
30
20
10
0
0
1000
LFCN-95
INSERTION LOSS
1000
LFCN-95
VSWR
100
VSWR
10
1
2000
3000
4000
5000
0
1000
2000
3000
4000
5000
FREQUENCY (MHz)
FREQUENCY (MHz)
Mini-Circuits
®
INTERNET
http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
Distribution Centers
NORTH AMERICA 800-654-7949 • 417-335-5935 • Fax 417-335-5945 • EUROPE 44-1252-832600 • Fax 44-1252-837010
Mini-Circuits
ISO 9001 & ISO 14001
Certified
REV. B
M96263
LFCN-95
ED-11960/3
RVN/AD/CP
050113
