PHOTONIC
Silicon Photodiode, Blue Enhanced Solderable Chips
Photoconductive Type PDB-C613 Photovoltaic Type PDB-V613
DETECTORS INC.
PACKAGE DIMENSIONS INCH (mm)
0.393 [9.98] SQ
0.393 [9.98] SQ
6.25 [158.7]
0.393 [9.98] SQ
1.00 [25.4]
0.035 [0.89]
ANODE, RED WIRE
CATHODE, BLACK WIRE
ANODE, BUSS WIRE
0.016 [0.41]
0.014 [0.36]
0.016 [0.41]
0.014 [0.36]
0.016 [0.41]
0.014 [0.36]
BARE CHIP
ACTIVE AREA = 86.4 mm
2
PDB-C613-1
PDB-V613-1
30 GAGE P.V.C. WIRE
30 GAGE BUSS WIRE
PDB-C613-2
PDB-V613-2
PDB-C613-3
PDB-V613-3
FEATURES
Low cost blue enhanced planar diffused
silicon solderable photodiode. The
PDB-V613
cell is designed
Blue enhanced
for low noise, photovoltaic applications. The
PDB-C613
cell is
Photovoltaic type
designed for low capacitance, high speed, photoconductive
Photoconductive type
High quantum efficiency operation. They are available bare, PVC or buss wire leads.
RESPONSIVITY (A/W)
0.7
0.6
0.5
0.4
0.3
0.2
0.1
DESCRIPTION:
APPLICATIONS
Optical encoder
Position sensor
Industrial controls
Instrumentation
ABSOLUTE MAXIMUM RATING
(TA=25
O
C unless otherwise noted)
SYMBOL
V
BR
T
STG
T
O
T
S
I
L
SPECTRAL RESPONSE
0
=1
0%
PARAMETER
Reverse Voltage
Storage Temperature
PDB-C613 PDB-V613
MIN
MAX
MIN
MAX
UNITS
V
O
O
O
75
25
QE
-40 +125 -40 +125
C
C
C
Operating Temperature Range -40 +100 -40 +100
Soldering Temperature
Light Current
+224
500
+224
500
mA
WAVELENGTH (nm)
ELECTRO-OPTICAL CHARACTERISTICS
SYMBOL CHARACTERISTIC
I
SC
I
D
R
SH
TC R
SH
C
J
Short Circuit Current
Dark Current
Shunt Resistance
R
SH
Temp. Coefficient
Junction Capacitance
(TA=25
O
C unless otherwise noted)
TEST CONDITIONS
H = 100 fc, 2850 K
H = 0, V
R
= 5 V*
H = 0, V
R
= 10 mV
H = 0, V
R
= 10 mV
H = 0, V
R
= 5 V**
PDB-C613
.90
1.0
90
.5
1
-8
350
350
940
25
50
1100
180
PDB-V613
.90
1.0
50
1
2
-8
10000
350
940
5
15
3.0 x 10
-13
TYP
3000
1100
100
MIN TYP MAX MIN TYP MAX
UNITS
mA
nA
M
Ω
% /
o
C
pF
nm
nm
V
W/
nS
Hz
λ
range
λ
p
V
BR
N EP
tr
Spectral Application Range Spot Scan
Spectral Response - Peak Spot Scan
Breakdown Voltage
Noise Equivalent Power
Response Time
I = 10
mA
V
R
= 0 V @ Peak
RL = 1 K
Ω
V
R
= 5 V**
3.0 x 10
-13
TYP
50
*VR = 100 mV on Photovoltaic type
**VR = 0 V on Photovoltaic type
