05140
USB004
STEERING DIODE ARRAY
APPLICATIONS
✔
USB Interface Ports
✔
Cellular Phones
✔
Video
✔
Handheld Electronics
✔
Personal Computers
IEC COMPATIBILITY
(EN61000-4)
✔
61000-4-2 (ESD): Air - 15kV, Contact - 8kV
✔
61000-4-4 (EFT): 40A - 5/50ns
SOT-143
FEATURES
✔
ESD Protection > 40 kilovolts
✔
225 Milliwatt Continuous Power Dissipation
✔
Provides Two (2) Lines of Protection
✔
Low Leakage Current < 1.0µA
✔
Ultra Low Capacitance: 3pF Typical
✔
RoHS Compliant in Lead-Free Versions
MECHANICAL CHARACTERISTICS
✔
Molded JEDEC SOT-143
✔
Weight 9 milligrams (Approximate)
✔
Available in Tin-Lead or Lead-Free Pure-Tin Plating(Annealed)
✔
Solder Reflow Temperature:
Tin-Lead - Sn/Pb, 85/15: 240-245°C
Pure-Tin - Sn, 100: 260-270°C
✔
Flammability Rating UL 94V-0
✔
8mm Tape and Reel Per EIA Standard 481
✔
Marking: Marking Code
PIN CONFIGURATION
V
N
1
4
V
P
I/O 1
2
3
I/O 2
05140.R7 6/06
1
www.protekdevices.com
USB004
DEVICE CHARACTERISTICS
MAXIMUM RATINGS
@ 25°C Unless Otherwise Specified
PARAMETER
Operating Temperature
Storage Temperature
Continuous Power Dissipation
Repetitive Peak Forward Current @ tp = 5µs, F = 50kHz (Pin 2-3)
SYMBOL
T
J
T
STG
P
PC
I
FRM
VALUE
-55°C to 150°C
-55°C to 150°C
225
700
UNITS
°C
°C
mW
mA
ELECTRICAL CHARACTERISTICS PER LINE
PART
NUMBER
DEVICE
MARKING
CODE
REPETITIVE
PEAK
REVERSE
VOLTAGE
(See Note 1)
@ 10µA
V
RRM
VOLTS
20
@ 25°C Unless Otherwise Specified
MAXIMUM
DIODE
FORWARD
VOLTAGE
@ 20mA
V
F
VOLTS
0.95
MAXIMUM
CAPACITANCE
(See Note 3 )
MAXIMUM
REVERSE
LEAKAGE
CURRENT
(See Note 2)
V
RRM
@ 5V
I
R
µA
1
C
j
pF
USB004
PSA
6
Note 1:
V
P
- V
N
= 20V.
Note 2:
V
P
- V
N
= 5.5V.
Note 3:
Between Line and Ground - V
P
= 5V, f = 1MHz, V
I/O
= 2.5V, V
N
= 0V.
10
I
F
- Forward Current - A
FIGURE 1
PEAK FORWARD CURRENT VS FORWARD VOLTAGE
I
F
- Forward Current - mA
110
90
70
50
30
10
800
FIGURE 2
LOW FORWARD CURRENT VS FORWARD VOLTAGE
8
6
4
2
0
0
1
2
3
4
5
6
7
8
9
10
V
F
- Forward Voltage - V
840
880
920
960
1000
V
F
- Forward Voltage - mV
05140.R7 6/06
2
www.protekdevices.com
USB004
SOT-143 PACKAGE OUTLINE & DIMENSIONS
PACKAGE OUTLINE
SOT-143
A
G
L
B
S
J
DIM
PACKAGE DIMENSIONS
MILLIMETERS
MIN
MAX
2.80
1.20
0.84
0.39
0.79
1.78
0.013
0.08
0.46
0.445
0.72
2.11
3.04
1.39
1.14
0.50
0.93
2.03
0.10
0.15
0.60
0.60
0.83
2.48
INCHES
MIN
MAX
0.110
0.047
0.033
0.015
0.031
0.070
0.0005
0.003
0.018
0.0175
0.028
0.083
0.120
0.055
0.045
0.020
0.037
0.080
0.004
0.006
0.024
0.024
0.033
0.098
K
F
D
H
C
R
MOUNTING PAD
TYPICAL
DIM Millimeters Inches
1
2
3
4
5
6
7
8
9
10
1
1
2.85
2.00
1.80
1.90
1.05
2.75
1.20
0.80
0.85
0.85
0.85
0.112
0.079
0.071
0.075
0.041
0.108
0.047
0.031
0.033
0.033
0.033
A
B
C
D
F
G
H
J
K
L
R
S
NOTES
1
2
10
4
5
11
6
1. Dimensioning and tolerances per ANSI Y14.5M, 1985.
2. Controlling Dimension: Inches
3. Dimensions are exclusive of mold flash and metal burrs.
TAPE & REEL ORDERING NOMENCLATURE
1. Surface mount product is taped and reeled in accordance with EIA-481.
2. Suffix-T7 = 7 Inch Reel - 3,000 pieces per 8mm tape, i.e.,
USB004-T7.
3. Suffix-T13 = 13 Inch Reel - 10,000 pieces per 8mm tape,
i.e.,
USB004-T13.
4. Suffix - LF = Lead-Free, Pure-Tin Plating, i.e.,
USB004-LF-T7.
3
7
8
9
Outline & Dimensions: Rev 2 - 6/06, 06011
Tape & Reel Specifications (Dimensions in millimeters)
Reel Dia.
178mm (7”)
Tape Width
8mm
A0
B0
K0
D
E
F
W
P0
P2
P
tmax
0.25
3.10 ± 0.10 2.70 ± 0.10 1.35 ± 0.10 1.50 ± 0.10 1.75 ± 0.10 3.50 ± 0.05 8.00 ±0.30 4.00 ±0.10 2.00 ±0.05 4.00 ±0.10
P0
t
D
P2
10 Pitches Cumulative
Tolerance on Tape. ± 0.2
E
Top cover tape
A0
K0
B0
F
W
P
User Direction of Feed
COPYRIGHT © ProTek Devices 2003
SPECIFICATIONS: ProTek reserves the right to change the electrical and or mechanical characteristics described herein without notice (except JEDEC).
DESIGN CHANGES: ProTek reserves the right to discontinue product lines without notice, and that the final judgement concerning selection and specifications is
the buyer’s and that in furnishing engineering and technical assistance, ProTek assumes no responsibility with respect to the selection or specifications of such
products.
ProTek Devices
2929 South Fair Lane, Tempe, AZ 85282
Tel: 602-431-8101 Fax: 602-431-2288
E-Mail: sales@protekdevices.com
Web Site: www.protekdevices.com
www.protekdevices.com
05140.R7 6/06
3
