200 V - 1,000 V Three Phase Bridge
9.0 A - 10.0 A Forward Current
70 ns - 3000 ns Recovery Time
3302 - 3310
3302F - 3310F
3302UF - 3310UF
ELECTRICAL CHARACTERISTICS AND MAXIMUM RATINGS
Part Number
Working
Reverse
Voltage
(Vrwm)
Average
Rectified
Current
@TC
(Io)
55°C
Volts
3302
3306
3310
3302F
3306F
3310F
3302UF
3306UF
3310UF
Amps
100°C
Amps
Reverse
Current
@ Vrwm
(Ir)
25°C
µA
100°C
µA
25°C
Volts
Amps
Forward
Voltage
1 Cycle
Surge
Current
tp=8.3ms
(Ifsm)
25°C
Amps
Repetitive
Surge
Current
(Ifrm)
25°C
Amps
Reverse
Recovery
Time
(1)
(Trr)
25°C
ns
°C / W
Thermal
Impd.
(Vf)
u
J-C
200
600
1000
200
600
1000
200
600
1000
10.0
10.0
10.0
10.0
10.0
10.0
9.0
9.0
9.0
7.0
7.0
7.0
7.0
7.0
7.0
6.5
6.5
6.5
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
25
25
25
25
25
25
25
25
25
1.1
1.1
1.2
1.2
1.5
1.5
1.7
1.7
1.7
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
100
100
100
100
100
100
100
100
100
25
25
25
20
20
20
20
20
20
3000
3000
3000
150
150
150
70
70
70
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2
4.2
(1)Trr Testing: If=0.5A, Ir=1.0A, Irr=0.25A *Op. Temp. & Stg. Temp. = -55°C to +150°C Isolation Voltage: 1500V
1.25(31.75)
_
.75
(19.05)
.38(9.65)
.22(5.59)
11
.31
(7.87)
AC
AC
AC
_
+
4-40 THRU
(2 PL)
.19(4.8) (2 PL)
.31(7.9)
.25(6.35)
.094(2.39)
AC AC AC
Aluminum Case
.28(7.11)
+
.45(11.43)
MAX.
1.062(27.0)
