LESHAN RADIO COMPANY, LTD.

Bias Resistor Transistors

PNP Silicon Surface Mount Transistors

with Monolithic Bias Resistor Network

This new series of digital transistors is designed to replace a single

device and its external resistor bias network. The BRT (Bias Resistor

Transistor) contains a single transistor with a monolithic bias network

consisting of two resistors; a series base resistor and a base-emitter

resistor. The BRT eliminates these individual components by

integrating them into a single device. The use of a BRT can reduce

both system cost and board space. The device is housed in the SOT-23

package which is designed for low power surface mount applications.

MMUN2111LT1 Series

MMUN2111LT1

SERIES

CASE 318, STYLE 6

SOT–23 (TO–236AB)

•

Simplifies Circuit Design

Reduces Board Space

Reduces Component Count

The SOT-23 package can be soldered using wave or reflow. The

modified gull-winged leads absorb thermal stress during soldering

eliminating the possibility of damage to the die.

•

Available in 8 mm embossed tape and reel. Use the Device Number

to order the 7 inch/3000 unit reel. Replace “T1” with “T3” in the

Device Number to order the 13 inch/10,000 unit reel.

MAXIMUM RATINGS

= 25°C unless otherwise noted)

Rating

Collector-Base Voltage

Collector-Emitter Voltage

Collector Current

Symbol

CBO

CEO

Value

100

Unit

Vdc

mAdc

PIN 1

BASE

(INPUT)

PIN 3

COLLECTOR

(OUTPUT)

PIN 2

EMITTER

(GROUND)

MARKINGDIAGRAM

A6x M

A6x = Device Marking

= A – L(See Page 2)

= Date Code

DEVICE MARKING

INFORMATION

See specific marking information in

the device marking table on page 2 of this

THERMAL CHARACTERISTICS

Characteristic

Total Device Dissipation

= 25°C

Derate above 25°C

Thermal Resistance –

Junction-to-Ambient

Thermal Resistance –

Junction-to-Lead

Junction and Storage

Temperature Range

1. FR–4 @ Minimum Pad

2. FR–4 @ 1.0 x 1.0 inch Pad

Symbol

Max

246 (Note 1.)

400 (Note 2.)

1.5 (Note 1.)

2.0 (Note 2.)

508 (Note 1.)

311 (Note 2.)

174 (Note 1.)

208 (Note 2.)

–55 to +150

Unit

°C/W

°C

data sheet.

θJA

θJL

, T

stg

MMUN2111S-1/11
