SERIES

P2BU-XXXXE 1KV ISOLATED 0,25 W UNREGULATED SINGLE OUTPUT DIP8

Available Inputs:

5, 12 and 24 VDC

Available Outputs:

3.3, 5, 7.2, 12, 15 and 18 VDC

Other specifications please enquire.

Electrical Specifications

(Typical at + 25° C, nominal input voltage, rated output current unless otherwise specified)

Input Specifications

Voltage range

Filter

Isolation Specifications

Rated voltage

Leakage current

Resistance

Capacitance

Output Specifications

Voltage accuracy

Ripple and noise (at 20 MHz BW)

Short circuit protection

Line voltage regulation

Load voltage regulation

Temperature coefficient

General Specifications

Efficiency

Switching frequency

Environmental Specifications

Operating temperature (ambient)

Storage temperature

Humidity

Cooling

Physical Characteristics

Dimensions DIP

Weight

Case material

+/- 10 %

Capacitors

1000 VDC

1 mA

Ohm

80 pF typ.

+/- 5 %, max.

100 mV p-p, max.

Momentary

+/- 1,2 % / 1,0 % of Vin

+/- 8 %, load = 20 ~ 100 %

+/- 0,02 % / °C

55 % to 75 %

80 KHz, typ.

- 40° C to + 85° C

- 55 °C to + 125 °C

Up to 90 %, non condensing

Free air convection

12,70 x 10,16 x 6,85 mm

0,50 x 0,40 x 0,27 inches

1,8 g

Non conductive black plastic

Examples of Partnumbers

PART

NO.

INPUT

VOLTAGE

(VDC)

INPUT

CURRENT

NO LOAD

INPUT

CURRENT

FULL

LOAD

OUTPUT

VOLTAGE

(VDC)

OUTPUT

CURRENT

(max. mA)

EFFICIENCY FULL LOAD

(% TYP.)

P2BU-0505E

P2BU-0512E

P2BU-0515E

P2BU-0524E

P2BU-1205E

P2BU-1212E

P2BU-1215E

P2BU-1505E

P2BU-2405E

P2BU-2412E

P2BU-2415E

77.00

70.43

73.53

32.06

29.35

25.00

17.95

16.03

50.00

20.83

16.66

10.42

50.00

20.83

16.66

50.00

20.83

16.66
