2SC4109 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> The transistor> 2SC4109

2SC4109: Descriptionswitching regulator applications; CategoryDiscrete semiconductor The transistor; File Size210KB，4 Pages; ManufacturerSANYO; Websitehttp://www.semic.sanyo.co.jp/english/index-e.html

Download Datasheet Parametric View All

2SC4109 Overview

switching regulator applications

2SC4109 Parametric

Parameter Name	Attribute value
Parts packaging code	TO-218
package instruction	FLANGE MOUNT, R-PSFM-T3
Contacts	2
Reach Compliance Code	unknown
Other features	HIGH RELIABILITY
Shell connection	COLLECTOR
Maximum collector current (IC)	16 A
Collector-emitter maximum voltage	400 V
Configuration	SINGLE
Minimum DC current gain (hFE)	10
JEDEC-95 code	TO-218
JESD-30 code	R-PSFM-T3
Number of components	1
Number of terminals	3
Maximum operating temperature	150 °C
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	FLANGE MOUNT
Polarity/channel type	NPN
Maximum power consumption environment	140 W
Maximum power dissipation(Abs)	140 W
Certification status	Not Qualified
surface mount	NO
Terminal form	THROUGH-HOLE
Terminal location	SINGLE
transistor applications	SWITCHING
Transistor component materials	SILICON
Nominal transition frequency (fT)	20 MHz
Base Number Matches	1

Preview

Download Datasheet

View All

SavantIC Semiconductor

Product Specification

Silicon NPN Power Transistors

2SC4109

DESCRIPTION

·With TO-3PN package

·High reliability

·High breakdown voltage

·Fast switching speed

·Wide area of safe operation

APPLICATIONS

·400V/16A switching regulator applications

PINNING

Base

Collector;connected to

mounting base

Emitter

DESCRIPTION

Fig.1 simplified outline (TO-3PN) and symbol

Absolute maximum ratings(Ta=

)

SYMBOL

CBO

CEO

EBO

PARAMETER

Collector-base voltage

Collector-emitter voltage

Emitter-base voltage

Collector current

Collector current-pulse

Base current

Ta=

Collector power dissipation

=25

stg

Junction temperature

Storage temperature

140

150

-55~150

Open emitter

Open base

Open collector

CONDITIONS

VALUE

500

400

2.5

UNIT
