BCM5703
®
10/100/1000BASE-T CONTROLLER WITH INTEGRATED TRANSCEIVER
FEATURES
SUMMARY OF BENEFITS
•
Single-chip solution for LAN on Motherboard (LOM) and
•
•
•
•
•
•
400-pin FBGA package
•
3.3V I/Os (5V tolerant)
•
JTAG
network interface card (NIC) applications
•
Integrated 10BASE-T/100BASE-TX/1000BASE-T transceivers
•
10/100/1000 triple-speed MAC
•
Host interfaces
- PCI v2.2—32/64 bits, 33/66 MHz
- PCI-X v1.0—64 bits, 66/100/133 MHz
•
Ultra-deep 96-KB on-chip packet buffer
•
Dual high-speed RISC cores with 16-KB caches
- Programmable, in-line packet classification
•
SMBus 2.0 controller
•
On-chip power circuit controller and Wake on LAN (WOL)
power switching circuit
Performance features:
•
TCP, IP, UDP checksum
•
TCP segmentation
•
CPU task offload
•
Adaptive interrupts
•
Ultra-deep 96-KB packet buffer
Robust manageability:
•
PXE 2.0 remote boot
•
Alert
Standard Format—ASF
1.0 support
•
Wake on LAN
•
Out-of-box (OOB) Wake on LAN
•
Intelligent platform management interface (IPMI), version 1.5
•
Statistic gathering (SNMP MIB II, Ethernet-like MIB, Ethernet
MIB)
•
Comprehensive diagnostic and configuration software suite
•
ACPI 1.1a compliant multiple power modes
Advanced network features:
•
Priority queuing—802.1p layer 2 priority encoding; support for
four priority queues
•
Virtual LANs—802.1q VLAN tagging; support for up to 64
VLANs
•
Jumbo frames (9 KB)
•
802.3x flow control
Advanced server features:
•
Link aggregation—802.3ad, GEC/FEC, Smart Load
Balancing™ (supports heterogeneous teams)
•
Heterogeneous, mixed-speed failover
•
PCI Hot-Plug support
Low-power, 0.13-um CMOS design
•
Industry’s smallest 10/100/1000 MAC+PHY solution—power
•
•
•
•
•
•
•
•
and space optimized for LOM and low-profile NIC
applications
Completely backward-compatible:
•
To existing 10/100 network infrastructure
•
To existing PCI-based desktop and server platforms
Futureproof
•
PCI-X interface, on-chip programmable CPUs, ASF support
Performance focused—optimized for throughput and CPU
utilization
•
Adaptive interrupts
•
PCI-X eliminates PCI bottlenecks
•
Ultra-deep 96-KB packet buffer lowers CPU utilization and
avoids PCI congestion
•
CPU task offloads reduces utilization level of CPU
Robust and highly manageable
•
PXE 2.0, ACPI 1.1a, Wake on LAN, ASF 1.0, IPMI
•
Integrated cable testing—link quality, length, pair skew, pair
polarity, pair swap
Advanced features
•
VLAN, priority queuing, jumbo frames
•
RISC processors for advanced packet classification
Server class reliability, availability, and performance features
•
Link aggregation and load balancing
•
Switch-dependent
•
802.3ad (LACP), generic trunking (GEC/FEC)
•
Switch- and NIC-independent
•
Smart Load Balancing™—unique technology that supports
heterogeneous teams, and can operate with any switch
•
Failover
•
Smart Load Balancing allows heterogeneous failover
•
PCI Hot Plug
Low-power for zero airflow implementations
•
0.13-um CMOS design
•
Advanced power management
Space savings for LOM
•
400-pin FBGA package
•
No external memory
•
Integrated power circuitry
