Revision 1.02 (02-16-05)
PRODUCT PREVIEW
2
SMSC USB3300
Hi-Speed USB Host or Device PHY with ULPI Low Pin Interface
General Description
The USB3300 is a stand-alone Hi-Speed USB Physical Layer Transceiver (PHY). The USB3300 uses
a low pin count interface (ULPI) to connect to a ULPI compliant Link layer. The ULPI interface reduces
the UTMI+ interface from 54 pins to 12 pins using a method of in-band signaling and status byte
transfers between the Link and PHY.
This PHY was designed from the start with the ULPI interface. No UTMI to ULPI wrappers are used
in this design which provides a seamless ULPI to Link interface. The result is a PHY with a low latency
transmit and receive time. SMSC’s low latency high speed and full speed receiver provide the option
of re-using existing UTMI Links with a simple wrapper to convert UTMI to ULPI.
The ULPI interface allows the USB3300 PHY to operate as a device, host, or an On-The-Go (OTG)
device. Designs using the USB3300 PHY as a device, can add host and OTG capability at a later date
with no additional pins.
The ULPI interface, combined with SMSC’s proprietary technology, makes the USB3300 the ideal
method of adding Hi-Speed USB to new designs. The USB3300 features an industry leading small
footprint package (5mm by 5mm) with sub 1mm height. In addition the USB3300 integrates all DP and
DM termination resistances and requires a minimal number of external components.
USB3300
CLK
STP
V
BUS
ULPI
LINK
DIR
NXT
DATA[7:0]
ULPI
Digital
Logic
USB 2.0
Analog
w/ OTG
ID
DM
DP
USB
Connector
(Standard
or Mini)
32 Pin QFN
Figure 1 Basic ULPI USB Device Block Diagram
The ULPI interface consists of 12 interface pins; 8 bi-directional data pins, 3 control pins, and a 60
MHz clock. By using the 12 pin ULPI interface the USB3300 is able to provide support for the full range
of UTMI+ Level 3 through Level 0, as shown in Figure 2, "ULPI Interface Features as Related to
UTMI+". This allows USB3300 to work as a HS and FS peripheral and as a HS, FS, and LS Host.
The USB3300 can also, as an option, fully support the On-the-Go (OTG) protocol defined in the On-
The-Go Supplement to the USB 2.0 Specification. On-the-Go allows the USB3300 to function like a
host, or peripheral configured dynamically by software. For example, a cell phone may connect to a
computer as a peripheral to exchange address information or connect to a printer as a host to print
pictures. Finally the OTG enabled device can connect to another OTG enabled device to exchange
information. All this is supported using a single low profile Mini-AB USB connector.
Designs not needing OTG can ignore the OTG feature set.
In addition to the advantages of the leading edge ULPI interface, the use of SMSC’s advanced analog
technology enables the USB3300 to consume a minimum amount of power which results in maximized
battery life for portable applications.
SMSC USB3300
PRODUCT PREVIEW
3
Revision 1.02 (02-16-05)
Hi-Speed USB Host or Device PHY with ULPI Low Pin Interface
ULPI
USB2.0 Peripheral, host controllers, On-the-
Go devices with 12 pin interface
(HS, FS, LS, preamble packet)
UTMI+ Level 3
USB2.0 Peripheral, host controllers, On-the-
Go devices
(HS, FS, LS, preamble packet)
UTMI+ Level 2
USB2.0 Peripheral, host controllers, On-
the-Go devices
(HS, FS, and LS but no preamble packet)
UTMI+ Level 1
USB2.0 Peripheral, host controllers, and
On-the-Go devices
(HS and FS Only)
UTMI+ Level 0
USB2.0 Peripherals Only
USB3300
ADDED FEATURES
USB3500
USB3450
USB3280
USB3250
Figure 2 ULPI Interface Features as Related to UTMI+
Applications
The USB3300 is targeted for any application where a Hi-Speed USB connection is desired and when
board space and interface pins must be minimized.
The USB3300 is well suited for:
■
■
■
■
■
■
■
Cell Phones
MP3 Players
Scanners
External Hard Drives
Still and Video Cameras
Portable Media Players
Entertainment Devices
Revision 1.02 (02-16-05)
PRODUCT PREVIEW
4
SMSC USB3300
Hi-Speed USB Host or Device PHY with ULPI Low Pin Interface
Block Diagram
The USB3300 is a highly integrated USB PHY. It contains a complete Hi-Speed USB2.0 PHY with the
ULPI industry standard interface to support fast time to market for a USB product. The USB3300 is
composed of the functional blocks shown in Figure 3, "USB3300 Block Diagram" below.
